BOSSIN MSG-TP-NE-FT00 Gaming Chair Instruction Manual

1. Киришүү

Thank you for choosing the BOSSIN MSG-TP-NE-FT00 Big and Tall Gaming Chair. This manual provides essential information for the safe and efficient assembly, operation, and maintenance of your new chair. Please read these instructions carefully before use and retain them for future reference.

Figure 1: BOSSIN MSG-TP-NE-FT00 Gaming Chair (Tiffany Blue variant)

2. Коопсуздук маалыматы

• Өрт коркунучу: Keep the chair away from open flames and heat sources.
• Нымдуулуктун таасири: Avoid exposing the chair to water or excessive moisture.
• Салмак сыйымдуулугу: 400 фунттан (181 кг) ашпаңыз.
• Ассамблея: Ensure proper assembly according to the instructions to prevent instability and injury.
• Текшерүү: Regularly inspect the chair for any loose parts, damage, or wear before each use. Discontinue use if any issues are found.

3. Пакеттин мазмуну

Before assembly, please verify that all components are present and undamaged. The package includes:

• Стулдун аркасы
• Seat Base with Footrest Mechanism
• Колтуктар (2)
• Жылдыз базасы
• Дөңгөлөктөр (5)
• Gas Lift Cylinder with Cover
• Механизм плитасы
• Белди колдоочу жаздык (массаж функциясы менен)
• Баштык үчүн жаздык
• Аппараттык комплект (бурамалар, шайбалар, алты бурчтуу ачкыч)
• Instruction Manual

4. Орнотуу жана чогултуу

Assembly is straightforward. Follow these steps carefully:

1. Жылдыздардын базасына роликтерди тиркөө: Insert each of the five casters into the holes at the end of the star base legs until they click securely into place.
2. Газ көтөргүчтү орнотуу: Place the gas lift cylinder into the center hole of the star base. Cover it with the telescopic plastic cover.
3. Механизмдин пластинасын отургучтун негизине бекитиңиз: Align the mechanism plate with the pre-drilled holes on the underside of the seat base. Secure it using the provided screws and Allen wrench. Ensure the front of the mechanism faces the front of the seat.
4. Колтуктарды бекитүү: Secure the armrests to the seat base using the designated screws. Ensure they are firmly attached.
5. Connect Backrest to Seat Base: Align the backrest with the brackets on the seat base. Secure it using the provided screws.
6. Газ көтөргүчкө отургуч топтомун орнотуу: Чогултулган отургучту газ көтөргүч цилиндрге этияттык менен орнотуңуз, анын борборлоштурулганын жана туруктуу экенин текшериңиз.
7. Attach Headrest and Lumbar Pillows: Secure the headrest pillow to the top of the backrest using its straps. Attach the lumbar support pillow to the lower backrest using its straps. The lumbar pillow can be adjusted vertically for optimal comfort.

Figure 2: Assembled chair with headrest and lumbar support

5. Иштөө нускамалары

5.1. Бийиктигин тууралоо

To adjust the chair's height, pull the lever located on the right side of the seat upwards while applying or releasing your body weight. Release the lever at your desired height.

5.2. Backrest Recline

To recline the backrest, pull the lever on the left side of the seat upwards and lean back. Release the lever to lock the backrest in your preferred position. The chair offers a wide range of recline angles for various activities.

Figure 3: Chair in a reclined position

5.3. Бут тирөөчтүн иштеши

The integrated footrest can be extended for added comfort. Pull the footrest handle located under the front of the seat outwards. Flip the padded section over and extend it to your desired length. To retract, push the footrest back under the seat.

Figure 4: Chair with footrest extended for relaxation

5.4. Бел массажынын функциясы

The lumbar support pillow features a massage function. Connect the USB cable from the pillow to a compatible USB power source (e.g., computer, power bank). The massage function will activate, providing gentle vibration for lower back comfort. Disconnect the USB cable to turn off the massage function.

6. Техникалык тейлөө

• Тазалоо: Wipe the faux leather surfaces with a soft, damp кездеме. Катуу химиялык заттардан же абразивдүү тазалагычтардан алыс болуңуз.
• Үзгүлтүксүз текшерүү: Мезгил-мезгили менен бардык бурамалар менен болттордун бекемдигин текшерип туруңуз. Керек болсо кайра тартыңыз.
• Стулду жылдыруу: Отургучту жылдырып жатканда, анын түбүнө же полуна зыян келтирбөө үчүн аны сүйрөп отурбай, көтөрүңүз.

7. Кыйынчылыктарды

• Отургуч титиреп жатат: Check all assembly screws and bolts to ensure they are securely tightened. Ensure the casters are fully inserted into the star base.
• Бийиктигин тууралоо иштебей жатат: Verify that the gas lift lever is fully engaged and that the gas lift cylinder is correctly installed in the star base and seat mechanism.
• Жөлөнгүчтүн арткы бөлүгү чалкалап/бекилип турбайт: Ensure the recline lever is functioning correctly and not obstructed. Check for any foreign objects in the recline mechanism.
• Footrest Not Extending/Retracting Smoothly: Inspect the footrest rails for any obstructions or damage. Apply a small amount of silicone lubricant if necessary.
• Массаж функциясы иштебейт: Ensure the USB cable is securely connected to both the lumbar pillow and a working USB power source. Try a different USB port or power source.

8. Техникалык шарттар

9. Кепилдик жана колдоо

For warranty information or technical support, please refer to the contact details provided with your purchase documentation or visit the official BOSSIN website. Please have your model number (MSG-TP-NE-FT00) and purchase date available when contacting support.

10. Продукт видеолору

No official seller videos are available for embedding in this manual. For additional product demonstrations, please refer to the product page on Amazon or the manufacturer's webсайт.
