LAVOR NJ EXTRA 145 WPS High-Pressure Washer User Manual

Introduction

Thank you for choosing the LAVOR NJ EXTRA 145 WPS High-Pressure Washer. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new pressure washer. Please read these instructions carefully before first use and keep them for future reference.

The LAVOR NJ EXTRA 145 WPS is a cold water pressure washer designed for domestic use, ideal for cleaning paths, terraces, garden furniture, bicycles, and vehicles. It features a unique Washing Programs System (WPS) to optimize cleaning results for various surfaces.

Коопсуздук маалыматы

ЭСКЕРТҮҮ: Бардык коопсуздук эскертүүлөрүн жана нускамаларын окуңуз. Эскертүүлөрдү жана нускамаларды аткарбоо электр шокуна, өрткө жана/же олуттуу жаракатка алып келиши мүмкүн.

• Ар дайым коопсуздук көз айнегин, кол капты жана угууну коргоочу каражаттарды кошо алганда, тиешелүү жеке коргонуу каражаттарын кийиңиз.
• Суу агымын эч качан адамдарга, жаныбарларга, электр жабдууларына же басымдуу жуугуч машинанын өзүнө багыттабаңыз.
• Электр энергиясы продуктунун этикеткасындагы спецификацияларга дал келишин текшериңиз.
• Эгерде электр шнуру же башка маанилүү бөлүктөр бузулган болсо, басымдуу жуугуч машинаны иштетпеңиз.
• Балдарды жана үй жаныбарларын операциядан алыс кармаңыз.
• Кандайдыр бир тейлөө же тазалоо иштерин аткаруудан мурун ар дайым кубат менен камсыздоону ажыратыңыз.
• Use only original Lavor spare parts and accessories.

Продукт бүттүview

Familiarize yourself with the components of your LAVOR NJ EXTRA 145 WPS pressure washer.

1-сүрөт: Main unit of the LAVOR NJ EXTRA 145 WPS Pressure Washer, showing the integrated hose reel, control dial, and wheels for portability.

Негизги компоненттер:

• Негизги блок: Houses the motor, pump, and control panel.
• Шланг ролик: Integrated for convenient storage of the high-pressure hose.
• WPS Control Dial: Selects cleaning programs (SOFT, MEDIUM, HARD).
• Жогорку басымдагы мылтык: For directing the water jet.
• High-Pressure Hose (6 meters): Connects the unit to the gun.
• Lances:
  • Turbo Nozzle Lance: For rotating jet, powerful cleaning.
  • Variojet Nozzle Lance: Adjustable jet for various tasks.
  • ECO Nozzle Lance: For efficient water usage.
• Foam System: With tank for detergent application.
• Щеткалар: Rotating and fixed brushes for scrubbing surfaces.
• Terrace Cleaner: Specialized attachment for cleaning large flat surfaces.

2-сүрөт: The WPS (Washing Programs System) indicator, showing options for SOFT, MEDIUM, and HARD cleaning modes.

Орнотуу жана чогултуу

1. Таңгактан чыгаруу жана алгачкы текшерүү:

Carefully remove all components from the packaging. Check for any damage during transit. Ensure all listed accessories are present.

2. Attaching the High-Pressure Hose:

1. Unwind the 6-meter high-pressure hose from the integrated reel.
2. Connect one end of the high-pressure hose to the outlet on the pressure washer unit. Ensure it is securely tightened.
3. Connect the other end of the high-pressure hose to the high-pressure gun using the quick-connect fitting.

3. Connecting to Water Supply:

1. Бакча түтүгүн (берилбейт) басымдуу жуугучтагы суу кирүүчү жерге туташтырыңыз.
2. Бакча түтүгүнүн экинчи учун суу кранына туташтырыңыз.
3. Ensure the water supply is turned on fully before starting the pressure washer. The maximum water inlet temperature should not exceed 40°C (104°F).

4. Кубат булагына туташуу:

Plug the power cord into a suitable grounded electrical outlet. Ensure the power supply matches the voltage and frequency specified on the product label (1900 Watt power consumption).

Иштөө нускамалары

1. Starting the Pressure Washer:

1. Бардык туташуулардын (суу, түтүк, электр) бекем орнотулганын текшериңиз.
2. Суу менен камсыздоону толугу менен күйгүзүңүз.
3. Press the trigger on the high-pressure gun to purge air from the system until a steady stream of water emerges.
4. Turn the main power switch on the unit to the "ON" position. The pump will start.

2. Using the WPS (Washing Programs System):

The WPS dial allows you to select the optimal cleaning program for different surfaces:

• ЖУМШАК: For delicate surfaces such as wooden decks, painted surfaces, or garden furniture.
• ОРТО: For vehicles, plastic garden furniture, or plastered walls.
• КАТЫН: For powerful cleaning of asphalt, stone, or concrete surfaces.

Rotate the WPS dial on the front of the unit to select the desired program before starting your cleaning task.

3-сүрөт: A user demonstrating the pressure washer for cleaning a car, suitable for the MEDIUM WPS setting.

3. Attaching and Using Accessories:

To change lances or brushes, ensure the pressure washer is turned off and the water supply is disconnected. Press the quick-release button on the gun, remove the current attachment, and insert the desired one until it clicks securely into place.

• Турбо форсункасынын түтүгү: Provides a rotating, concentrated jet for stubborn dirt. Use with caution on delicate surfaces.
• Variojet Nozzle Lance: Allows adjustment of the spray pattern from a narrow pencil jet to a wide fan spray.
• ECO Nozzle Lance: Designed for water-efficient cleaning.
• Foam System: Fill the tank with appropriate pressure washer detergent. Attach to the gun to apply foam for pre-soaking or deep cleaning.
• Rotating and Fixed Brushes: Ideal for scrubbing surfaces like car wheels or garden furniture.
• Terrace Cleaner: Connect this attachment for efficient and splash-free cleaning of large patio or deck areas.

4-сүрөт: A user cleaning a car wheel with a rotating brush attachment, demonstrating effective use of accessories.

5-сүрөт: A user cleaning a grill with a fixed brush attachment, highlighting the versatility of the included tools.

4. Automatic Stop System:

The pressure washer is equipped with an Automatic Stop System. This system automatically turns off the pump when the trigger on the gun is not engaged. This saves energy and extends the lifespan of the pump. The pump will restart automatically when the trigger is pressed again.

5. Өчүрүү:

1. Негизги кубат которгучун "OFF" абалына буруңуз.
2. Суу менен камсыздоону өчүрүңүз.
3. Системадагы калган басымды чыгаруу үчүн жогорку басымдагы тапанчанын триггерин басыңыз.
4. Disconnect the high-pressure hose from the water inlet and the gun.
5. Электр шнурын электр розеткасынан сууруп алыңыз.

Тейлөө жана сактоо

1. Жалпы тазалоо:

After each use, clean the exterior of the pressure washer with a damp cloth. Remove any dirt or debris from the nozzles and filters. Ensure no water remains in the pump or hose during freezing temperatures.

2. Water Inlet Filter:

Regularly check and clean the water inlet filter to prevent blockages and ensure optimal performance. A clogged filter can reduce water flow and damage the pump.

3. Сактоо:

Store the pressure washer in a dry, frost-free environment. Drain all water from the pump, hose, and accessories before storing, especially in cold climates, to prevent damage from freezing. Use the integrated hose reel for tidy storage of the high-pressure hose.

Проблемаларды чечүү

Техникалык мүнөздөмөлөр

Кепилдик жана колдоо

Lavor products are manufactured to high-quality standards. This product comes with a standard manufacturer's warranty. Please refer to the warranty card included in your packaging for specific terms and conditions.

Spare parts for this model are available for a period of 10 years from the date of purchase, ensuring long-term usability and support for your investment.

For technical assistance, spare parts, or warranty claims, please contact your authorized Lavor dealer or visit the official Lavor website for customer service contact information. When contacting support, please have your model number (NJ EXTRA 145 WPS) and serial number ready.
