IMIPAW 4L Automatic Pet Feeder with Dual Bowls (Model IP-DU4LD) - Instruction Manual

Introduction

Thank you for choosing the IMIPAW 4L Automatic Pet Feeder. This device is designed to provide a convenient and reliable feeding solution for your small to medium-sized pets, ensuring they receive their meals on schedule. With app control and dual bowls, managing your pet's diet has never been easier. Please read this manual carefully before use to ensure proper operation and maintenance.

Продукт бүттүview жана компоненттер

The IMIPAW 4L Automatic Pet Feeder is equipped with features to ensure fresh and timely meals for your pets. It includes a secure food container, a dual-bowl system, and smart controls.

Сүрөт: All accessories included with the IMIPAW Automatic Pet Feeder: feeder unit, dual bowls, food divider, support, power cable, and power adapter.

Негизги өзгөчөлүктөрү:

• 4L сыйымдуулугу: Large food storage suitable for small to medium pets.
• Dual Bowls: Allows two pets to eat simultaneously or provides separate food and treat options.
• APP көзөмөлү: Manage feeding schedules and portions remotely via a smartphone application.
• 5G | 2.4G WiFi Support: Ensures stable and fast connection for remote feeding.
• Anti-Jamming Mechanism: Designed to prevent food blockages.
• Freshness Lock: Includes a desiccant bag to keep food fresh.
• Кош энергия менен камсыздоо: Operates with a 5V DC adapter and backup D-cell batteries.
• Тазалоо оңой: Removable components for thorough cleaning.

Жайгашуу

Follow these steps to assemble and prepare your IMIPAW Automatic Pet Feeder for use.

Сүрөт: Six-step visual guide for assembling and setting up the IMIPAW Automatic Pet Feeder.

1. Компоненттерди таңгактан чыгаруу: Carefully remove all parts from the packaging. Ensure all accessories listed in the Product Overview section are present.
2. Assemble Bowls: Attach the dual bowls to the base of the feeder. Ensure they are securely in place.
3. Install Food Divider: Insert the food divider into the dispenser chute if you intend to feed two pets or separate food types.
4. Fill Food Container: Open the lid of the food container. Pour dry pet food (kibble size 2-10mm) into the container. Do not overfill.


   Сүрөт: Food being poured into the transparent container of the IMIPAW Automatic Pet Feeder.
5. Коопсуз капкак: Close the lid firmly to maintain food freshness. The lid is designed with a freshness lock and a desiccant bag compartment.


   Сүрөт: Close-up of the feeder's lid with a desiccant bag for freshness.

6. Туташуу кубаты: Connect the 5V DC power adapter to the feeder and plug it into a wall outlet. For backup power, install 3 D-cell batteries (not included) in the battery compartment at the bottom of the feeder.

Колдонмону орнотуу жана туташуу

Control your IMIPAW Pet Feeder remotely by connecting it to the PetTech app on your smartphone.

1. Колдонмону жүктөп алыңыз: Scan the QR code below or search for "PetTech" in your smartphone's app store (iOS or Android) and download it.


   Сүрөт: QR code for PetTech app download and initial app screens for adding a device. You can also find the app at https://a.smart321.com/Petrtdv1peartV152.
2. Түзмөк кошуу: Open the PetTech app. Tap "Add Device" or the "+" icon to begin the pairing process. Select "Pet Feeder (2.4GHz & 5GHz)" from the list of devices.


   Сүрөт: App interface showing device selection and WiFi options.

3. Түзмөктү баштапкы абалга келтирүү: Follow the in-app instructions to reset the feeder. This typically involves unplugging and replugging the device, then pressing and holding the RESET button for 5 seconds until the indicator light flashes slowly.
4. WiFi'га туташуу: Enter your WiFi network password. The feeder supports both 2.4GHz and 5GHz WiFi bands. Ensure your phone is connected to the same network.


   Сүрөт: App screen for entering WiFi password and connecting to the network.

5. Толук туташуу: The app will search for and connect to the device. Once connected, you can customize the device name.

Иштөө нускамалары

The IMIPAW Automatic Pet Feeder offers both manual and scheduled feeding options.

Кол менен тамактандыруу:

To dispense food immediately, use the manual feed option in the PetTech app. Select the desired number of portions and confirm. Food will be dispensed into the bowls.

Scheduling Meals:

Set up a personalized feeding schedule to ensure your pet receives consistent meals throughout the day.

Сүрөт: Scientific feeding program example with scheduled meals and portion sizes.

1. Access Meal Plan: In the PetTech app, navigate to the "Meal Plan" section.
2. Add Schedule: Tap "Add" to create a new feeding schedule.
3. Убакытты коюу: Choose the desired feeding time (e.g., 05:00 AM).
4. Күндөрдү тандоо: Select the days of the week for this feeding time (e.g., Sun, Mon, Fri).
5. Choose Portions: Specify the number of portions to be dispensed for this meal (1-20 portions per meal, up to 200 portions daily).
6. Save Schedule: Tap "Save" to activate the schedule. Repeat for all desired meal times.


   Сүрөт: Customized feeding schedule with multiple time slots.

The feeder will automatically dispense food according to your programmed schedule, even if your phone is not connected to the internet, as long as the feeder has power.

Тейлөө жана тазалоо

Regular cleaning ensures hygiene and extends the life of your pet feeder.

1. Бөлүп салуу: Unplug the feeder and remove any remaining food. Disassemble the food container, lid, food divider, and bowls.


   Сүрөт: Disassembled components of the feeder ready for cleaning.

2. Жуу компоненттери: The lid, food container, food divider, and bowls are removable and can be washed with water and mild detergent. Rinse thoroughly.


   Сүрөт: Disassembled parts of the feeder being washed in a kitchen sink. Эскертүү: Do not wash the main base unit.
3. Таза база: Негизги базаны жарнама менен сүртүңүзamp кездеме. Базаны сууга батырбаңыз.
4. Кылдат кургатуу: Ensure all components are completely dry before reassembling and refilling with food.
5. Replace Desiccant: Replace the desiccant bag in the lid every 1-2 months to maintain food freshness. Compatible desiccant bags can be found using ASIN B0DMDRHVMV.

Электр камсыздоо

The IMIPAW Automatic Pet Feeder features a dual power supply system to ensure uninterrupted feeding for your pets.

Сүрөт: Dual power options: 5V DC adapter and 3 D-cell batteries.

• Негизги күч: The feeder operates using a 5V DC power adapter connected to a standard electrical outlet.
• Камдык күч: For protection against power outages, the feeder can be powered by 3 D-cell batteries (not included). Install these in the battery compartment at the bottom of the unit. The feeder will automatically switch to battery power if the main power is interrupted.


  Сүрөт: Battery compartment and power adapter connection.

Проблемаларды чечүү

If you encounter issues with your IMIPAW Automatic Pet Feeder, please refer to the following common solutions:

• Азык берүүчү тамакты бербейт:
  • Check if the power adapter is securely plugged in and the outlet is working.
  • Ensure batteries are installed correctly and have sufficient charge if using backup power.
  • Verify that the food container has enough kibble and that the kibble size is between 2-10mm.
  • Check for any food blockages in the dispenser chute. Clean if necessary.
  • Confirm the feeding schedule is correctly set in the app and enabled.
• App not connecting to the feeder:
  • Ensure your smartphone's WiFi is enabled and connected to a 2.4GHz or 5GHz network.
  • Make sure the feeder is within range of your WiFi router.
  • Try resetting the feeder and re-pairing it with the app (refer to "App Installation and Connection" section).
  • Restart your smartphone and the PetTech app.
• Жаңы бойдон калбаган азыктар:
  • Капкактын бекем жабылгандыгын текшериңиз.
  • Check if the desiccant bag needs replacement.

If the problem persists, please contact IMIPAW customer support for assistance.

Техникалык шарттар

Кепилдик жана колдоо

This IMIPAW Automatic Pet Feeder is covered by a 1 жылдык кепилдик. Our customer service team is available to answer your questions and provide timely support. In case of any product issues, please contact us for a free replacement or a full refund.

For returns within 30 days of receipt due to a change of mind, please consult our help page on returns. If you have received a defective or damaged product, please consult our help page on defective items. For specific information on purchases made on the Marketplace, please consult our help page on Marketplace purchases.
