ALONEFIRE SV140 365nm UV Flashlight Instruction Manual

1. Продукт бүтүп калдыview

The ALONEFIRE SV140 is a powerful 365nm UV flashlight designed for professional and general use. It features a high-quality 10*4-core 365nm UV LED light source, delivering an impressive 60 watts of power and 8000mW luminous output. Equipped with a black UV filter lens, it effectively filters ambient light to provide a purer and more powerful ultraviolet beam. The flashlight includes a digital LCD screen for real-time power level display and is USB-C rechargeable, also offering power bank functionality to charge other devices.

Image 1.1: The ALONEFIRE SV140 365nm UV Flashlight, showcasing анын бекем дизайны.

2. Коопсуздук маалыматы

WARNING: Ultraviolet (UV) light can be harmful to eyes and skin. Always follow these safety guidelines:

• Көздү коргоо: Always wear the provided UV protective glasses when operating the flashlight. Never look directly into the UV light beam.
• Теринин таасири: Avoid prolonged direct exposure of skin to the UV light.
• Балдар: Балдардын колу жетпеген жерде сактаңыз. Бул оюнчук эмес.
• Жылуулук: The flashlight may generate heat during extended use. Handle with care.

Image 2.1: The ALONEFIRE SV140 flashlight shown with the included UV protective glasses and charging cables. The glasses are essential for safe operation.

3. Пакеттин мазмуну

Пакетиңизде бардык буюмдар бар экенин текшериңиз:

• ALONEFIRE SV140 365nm UV Flashlight
• 4 x High-capacity Rechargeable Lithium-Ion Batteries
• UV Protective Glasses
• USB-C заряддоо кабели

4. Орнотуу

4.1 Батареяны орнотуу

The ALONEFIRE SV140 flashlight requires four 18650 Lithium-Ion batteries. Ensure the batteries are inserted with the correct polarity as indicated inside the battery compartment. The flashlight is designed to operate with these specific batteries for optimal performance and safety.

4.2 Алгачкы заряддоо

Before first use, fully charge the flashlight. Connect the provided USB-C charging cable to the flashlight's Type-C port and plug the other end into a compatible USB power adapter (not included). The digital LCD display will show the charging progress. A full charge typically takes approximately 6 hours.

Image 4.1: The digital LCD display on the ALONEFIRE SV140, indicating the current battery charge level. This display is active during use and charging.

5. Операция

5.1 Күйгүзүү/өчүрүү

Press the main power button located on the side of the flashlight to turn the UV light on or off. The digital display will activate upon power-on, showing the current battery percentage.

5.2 Тышкы түзмөктөрдү кубаттоо (Power Bank функциясы)

The SV140 can function as a power bank to charge other USB-powered devices. Open the protective cover over the USB-A output port. Connect your device's charging cable to the USB-A port on the flashlight. The flashlight will begin charging your device. This feature allows for convenient charging on the go.

Image 5.1: The ALONEFIRE SV140 demonstrating its power bank capability by charging a smartphone. The USB-A output port is visible.

5.3 Black UV Filter Lens

The integrated hard toughened black filter optical lens is designed to block visible light, ensuring that only the pure 365nm UV light is emitted. This enhances the clarity and effectiveness of fluorescence detection.

Image 5.2: A diagram illustrating how the black UV filter lens works to filter out undesired ambient light, making the UV output purer.

6. Тиркемелер

The ALONEFIRE SV140 UV Flashlight is suitable for a wide range of applications where the detection of fluorescent substances is required:

• Pet Urine and Stains: Detect invisible pet urine stains on carpets, rugs, and furniture.
• Мышыктын сары курттарын аныктоо: Aid in identifying fungal infections on pets.
• Currency and Document Authentication: Verify security features on banknotes, passports, and other official documents.
• Скорпионду аныктоо: Scorpions fluoresce under 365nm UV light, making them easier to spot in dark environments.
• Минералдык жана асыл таштарды текшерүү: Observe fluorescence in various minerals and gemstones.
• Resin and Glue Curing: Accelerate the curing process of UV-sensitive resins and glues.
• Агышты аныктоо: Identify leaks in HVAC systems, automotive fluids, and plumbing when used with fluorescent dyes.

Сүрөт 6.1: Мисample of the UV flashlight being used for pet urine detection on a carpet, revealing otherwise invisible stains.

Image 6.2: A visual comparison of mineral samples under different lighting conditions: normal light, 395nm UV light, and 365nm UV light, highlighting the superior fluorescence activation with 365nm UV.

7. Техникалык тейлөө

• Тазалоо: Кол чырактын корпусун жумшак менен сүртүңүз, гamp кездеме. Абразивдүү тазалагычтарды же эриткичтерди колдонбоңуз.
• Линзага кам көрүү: Gently clean the UV filter lens with a lens cleaning cloth to maintain optimal light output.
• Сактагыч: Store the flashlight in a cool, dry place away from direct sunlight and extreme temperatures. If storing for extended periods, remove the batteries.
• Батареяга кам көрүү: Recharge batteries regularly, even if not in use, to prolong their lifespan. Avoid fully discharging the batteries.

8. Кыйынчылыктарды

• Кол чырак күйбөй жатат:
  • Батареялар туура полярдуулук менен туура орнотулганын текшериңиз.
  • Check battery charge level on the LCD display. Recharge if necessary.
  • Verify that the battery compartment cap is securely tightened.
• кубаттоо маселелери:
  • USB-C кабели фонарикке жана кубат булагына туура туташтырылганын текшериңиз.
  • Try a different USB power adapter or cable.
  • Заряддоо портунда таштанды же зыяндын бар-жоктугун текшериңиз.
• Weak UV Output:
  • Батареялар толук заряддалганын текшериңиз.
  • Clean the UV filter lens for any smudges or dirt.

9. Техникалык шарттар

10. Кепилдик жана колдоо

The ALONEFIRE SV140 UV Flashlight comes with a limited warranty. For specific warranty terms and conditions, please refer to the product packaging or contact ALONEFIRE customer support. If you encounter any issues or have questions regarding your product, please reach out to the retailer or manufacturer for assistance.
