Introduction
This manual provides detailed instructions for the ASHATA Desktop Barcode Scanner (Model B0GGZSVXTN). Please read this manual thoroughly before using the device to ensure proper operation, optimal performance, and longevity of the product. Keep this manual for future reference.
Коопсуздук маалыматы
- Сканерди экстремалдык температурага, нымдуулукка же тике күн нуруна калтырбаңыз.
- Avoid dropping the device from heights greater than 1.5 meters, although it is designed to be drop-proof up to this height.
- Do not attempt to disassemble or modify the scanner. This will void the warranty and may cause damage.
- Туташуу үчүн берилген USB кабелин гана колдонуңуз.
- Штрих-коддун так окулушун камсыз кылуу үчүн сканерлөө терезесин таза кармаңыз.
Продукт бүттүview
The ASHATA Desktop Barcode Scanner is a high-performance device designed for efficient and accurate scanning of 1D and 2D barcodes. It features a CMOS sensor, auto-recognition capabilities, and voice prompts for successful scans.
Figure 1: ASHATA Desktop Barcode Scanner in use, highlighting its sensitive barcode scanning and convenient checkout features.
Figure 2: The scanner's ability to read various barcodes, including those on digital displays.
Figure 3: High-Definition Camera details, showing decoding speed and density.
Figure 4: Real-Person Voice Prompts indicating a successful scan.
Figure 5: Stable Structure, Shockproof and Drop-proof design.
Сүрөт 6: Продукциянын өлчөмдөрү.
Жайгашуу
Follow these steps to set up your ASHATA Desktop Barcode Scanner:
- Аппаратты таңгактан чыгаруу: Сканерди жана бардык аксессуарларды таңгактан кылдаттык менен чыгарып алыңыз.
- Connect Power/Data Cable: Insert the USB cable into the designated port on the scanner. Connect the other end of the USB cable to an available USB port on your computer or POS system.
- Системаны таануу: Your operating system should automatically detect and install the necessary drivers for the scanner. This may take a few moments.
- Жайгашкан жери: Place the scanner on a stable, flat surface in a convenient location for scanning. Ensure the scanning window is unobstructed.
- Баштапкы сыноо: Open a text editor or a compatible application and scan a known barcode to confirm proper functionality.
Иштөө нускамалары
The ASHATA Desktop Barcode Scanner is designed for ease of use with its auto-induction feature.
- Автоматтык сканерлөө: The scanner features an auto-induction mode. Simply place the barcode within the scanning window. The scanner will automatically detect the barcode and initiate the scan.
- Barcode Placement: Position the barcode flat and centered within the scanning window for optimal reading. The large scanning window provides flexibility for various barcode sizes and orientations.
- Үн чакыруу: Upon a successful scan, the device will emit a "Scan Successful" voice prompt, confirming that the barcode has been read.
- Колдоого алынган штрихкоддор: The scanner supports all universal 1D and 2D barcodes, whether printed on labels, paper, or displayed on mobile/computer screens.
Техникалык тейлөө
Сканериңиздин узак иштөөсүн жана оптималдуу иштешин камсыз кылуу үчүн төмөнкү тейлөө көрсөтмөлөрүн аткарыңыз:
- Сканерлөө терезесин тазалоо: Regularly clean the scanning window with a soft, lint-free cloth. For stubborn smudges, slightly dampen the cloth with water or a mild, non-abrasive cleaner. Do not spray liquids directly onto the scanner.
- Жалпы тазалоо: Сканердин сыртын кургак же бир аз кургак чүпүрөк менен сүртүңүзamp чаңды жана кирди тазалоо үчүн кездеме.
- Сактагыч: When not in use for extended periods, store the scanner in a clean, dry environment away from direct sunlight and extreme temperatures.
Проблемаларды чечүү
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Сканер жооп бербей жатат | Loose USB connection; Power issue; Driver not installed. | Check USB cable connection; Try a different USB port; Restart computer; Verify driver installation in device manager. |
| Штрих-кодду окуй албай жатат. | Barcode damaged/unclear; Scanning window dirty; Incorrect barcode placement; Unsupported barcode type. | Ensure barcode is clear and undamaged; Clean scanning window; Adjust barcode position; Confirm barcode type is 1D/2D. |
| Үн эскертүүсү жок | Voice prompt feature disabled (if configurable); Internal error. | Ensure scanner is functioning correctly; If problem persists, contact support. |
Техникалык шарттар
| Модел | B0GGZSVXTN |
| Decoding Type | 640x480 CMOS |
| Жарык булагы | Ак LED |
| Barcode Contrast | ≥20% |
| Резолюция | ≥4mil/0.1mm |
| Supported Code System | All 1D/2D Universal Barcodes |
| Кабелдин узундугу | 1.5 м / 4.92 фут |
| Продукт өлчөмү | 11 x 9.5 x 6.6 cm / 4.33 x 3.74 x 2.6 in |
| Продукт Салмагы | 198 г / 6.98 унция |
| Guard Grade | IP42 |
| Drop Proof | 1.5 м |
| Интерфейс | USB/RS232 (Wired Version) |
Кепилдик жана колдоо
ASHATA products are manufactured to high quality standards. For warranty information or technical support, please refer to the documentation included with your purchase or contact your retailer. Please have your product model number (B0GGZSVXTN) available when contacting support.
