SYLVANIA Lumalux жогорку басымдагы натрий HID лампочкасы 70 Вт (Модель 67504) Instruction Manual

1. Продукт бүтүп калдыview

The SYLVANIA Lumalux High Pressure Sodium (HPS) HID Light Bulb is designed for best-in-class illumination in various applications. This 70W ED17 bulb provides 4000 lumens with a warm 1900K color temperature, ideal for areas requiring robust and long-lasting lighting.

1.1-сүрөт: SYLVANIA Lumalux 70W High Pressure Sodium HID Light Bulb. This image shows the clear glass bulb with its internal arc tube and medium screw base.

Common applications include atriums, flood lighting, industrial lighting, commercial lighting, retail lighting, lobbies, parking lots, and security lighting.

2. Коопсуздук маалыматы

• Always disconnect power before installing or replacing the bulb.
• Лампанын ват болушун камсыз кылыңызtage and type match the fixture's ballast requirements. Incorrect matching can lead to bulb failure or damage to the fixture.
• Handle the bulb with care to avoid breakage. Do not touch the glass with bare hands, as oils can reduce bulb life. Use a clean cloth or gloves.
• This bulb operates at high temperatures. Allow the bulb and fixture to cool completely before handling.
• Dispose of used bulbs according to local regulations, as they may contain mercury.

3. Орнотуу жана орнотуу

Proper installation is crucial for the performance and longevity of your SYLVANIA Lumalux HID bulb.

1. Шайкештикти текшерүү: Ensure your fixture is designed for High Pressure Sodium (HPS) bulbs and that its ballast is compatible with a 70W ED17 bulb with an E26 Medium Base. The bulb's ANSI Code is M47/O.
2. Электр энергиясын өчүрүү: Turn off the power to the fixture at the circuit breaker before beginning installation.
3. Эски лампочканы алып салуу (эгер бар болсо): If replacing an old bulb, allow it to cool completely. Unscrew the old bulb counter-clockwise.
4. Жаңы лампочканы орнотуу: Carefully screw the new SYLVANIA Lumalux bulb into the E26 Medium Base socket by turning it clockwise until snug. Do not overtighten.
5. Күчтү калыбына келтирүү: Лампа коопсуз орнотулгандан кийин, өчүргүчтөгү арматурага электр кубатын кайтарыңыз.

3.1-сүрөт: Bulb dimensions for the SYLVANIA Lumalux 70W HID Light Bulb. The bulb measures approximately 5.43 inches in length and 2.13 inches in diameter, with a 1.02-inch medium base.

4. Иштөө нускамалары

The SYLVANIA Lumalux 70W HID bulb provides immediate and consistent illumination once power is supplied.

• Алгачкы от алдыруу: Upon first use or after a power interruption, the bulb may take a few minutes to reach full brightness and color stability. This is normal for High Pressure Sodium lamps.
• Кайра күйгүзүү: If the bulb is turned off, it requires a cool-down period before it can re-ignite. This typically takes 5-10 minutes.
• Түс температурасы: This bulb produces a Soft White light with a color temperature of 1900 Kelvin, characteristic of High Pressure Sodium lamps.
• Жарыктык: The bulb delivers 4000 lumens, providing significant illumination for large areas.

4.1-сүрөт: Example of SYLVANIA High Pressure Sodium lighting in a parking lot, demonstrating its effectiveness for large outdoor spaces.

4.2-сүрөт: Street lighting application using SYLVANIA High Pressure Sodium bulbs, providing reliable illumination for public areas.

4.3-сүрөт: SYLVANIA High Pressure Sodium lighting maintaining visibility on a foggy street, highlighting its performance in challenging conditions.

5. Техникалык тейлөө

The SYLVANIA Lumalux HID bulb is designed for long-term, low-maintenance operation.

• Тазалоо: Periodically clean the exterior of the bulb and fixture with a soft, dry cloth to ensure optimal light output. Ensure power is off and the bulb is cool before cleaning.
• Күтүлгөн өмүр узактыгы: This bulb has an average rated life of 24,000 hours, significantly reducing the frequency of replacements.
• Өмүрдүн аягы: As the bulb approaches the end of its life, it may exhibit flickering or a change in light output. Replace the bulb when these signs become apparent.

6. Кыйынчылыктарды

If your SYLVANIA Lumalux HID bulb is not functioning as expected, consider the following common issues and solutions:

• Лампочка күйбөйт:
  • Шаймандын кубат булагы иштеп турганын текшериңиз.
  • Лампанын розеткага бекем сайылганын текшериңиз.
  • Verify that the bulb and ballast are compatible. An incompatible ballast will prevent the bulb from igniting.
  • If the bulb was recently turned off, allow 5-10 minutes for it to cool down before attempting to re-ignite.
  • Inspect the bulb for any visible damage or breakage.
• Bulb flickers or cycles on and off:
  • This can indicate the bulb is nearing its end of life and needs replacement.
  • Ensure the fixture's wiring is secure and there are no loose connections.
  • Туура томду текшериңизtage supply to the fixture.
• Reduced light output:
  • The bulb may be dirty; clean it as described in the Maintenance section.
  • Reduced light output can also be a sign of an aging bulb.

Эгер көйгөйдү чечүү кадамдары маселени чечпесе, кардарларды колдоо кызматына кайрылыңыз.

7. Техникалык шарттар

8. Кепилдик жана колдоо

For warranty information, customer questions, or support regarding your SYLVANIA Lumalux HID Light Bulb, please contact LEDVANCE customer service.

• Customer Support (US & Canadian): 1-800-LIGHTBULB (1-800-544-4828)
• Өндүрүүчү: LEDVANCE
