Olympus Pen EE-3 жарым кадрлуу 35 мм камера үчүн колдонмо

Introduction

The Olympus Pen EE-3 is a compact half-frame 35mm camera, designed for ease of use and portability. It captures two images on a single 35mm film frame, effectively doubling the number of exposures per roll. This manual will guide you through the setup, operation, and care of your camera to ensure optimal performance and enjoyment.

Продукт бүттүview

The Pen EE-3 features a fixed 28mm f/3.5 lens, automatic exposure control, and a robust plastic/composite body. Its half-frame design allows for more shots per roll of film, making it an economical and fun choice for everyday photography.

Негизги компоненттер

• Объектив: Fixed 28mm f/3.5 lens.
• Viewтапкыч: Оптикалык viewfinder for framing your shots.
• Жабык баскычы: Activates the shutter to take a photograph.
• Film Advance Wheel: Used to advance the film to the next frame after each shot.
• Film Rewind Knob: Used to rewind the film back into its cassette when the roll is finished.
• Экспозиция өлчөгүч: Integrated light meter for automatic exposure settings.
• Штатив орнотуу: Standard 3/8-16 or 1/4-20 thread for mounting on a tripod.

Сүрөт 1: Алдыңкы view of the Olympus Pen EE-3 camera, showing the lens and viewтапкыч.

2-сүрөт: Жогорку view of the Olympus Pen EE-3 camera, highlighting the film advance wheel and shutter button.

3-сүрөт: Төмөнкү view of the Olympus Pen EE-3 camera, showing the tripod mount and "Made in Japan" engraving.

Жайгашуу

Фильм жүктөлүүдө

1. Open the camera back by sliding the latch on the side of the camera downwards.
2. Place a 35mm film cassette into the film chamber on the left side.
3. Плёнканын жетегин оң жактагы кармоочу катушкага тартып, аны уячалардын бирине салыңыз.
4. Advance the film slightly using the film advance wheel to ensure it is securely engaged.
5. Камераны артка бекитилгенче бекем жабыңыз.
6. Advance the film two or three times, pressing the shutter button each time, until the frame counter shows '1'. This ensures the exposed film leader is wound onto the take-up spool.

4-сүрөт: Арткы view of the Olympus Pen EE-3 with the camera back open, showing the film chamber and take-up spool.

Battery Installation (Not Applicable)

The Olympus Pen EE-3 is a fully mechanical camera and does not require batteries for its core functions or light meter. It operates without external power.

Иштөө нускамалары

Taking a Photograph

1. Look through the optical viewкадрыңызды түзүү үчүн тапкыч.
2. The camera's automatic exposure system will set the appropriate shutter speed (1/40 or 1/200 sec) and aperture (f/3.5) based on available light.
3. Press the shutter button gently but firmly to take the picture.
4. After each shot, turn the film advance wheel until it stops to move to the next frame. The frame counter will indicate the current frame number.

Rewinding Film

1. Once you have taken all the pictures on the roll (the film advance wheel will no longer turn), locate the film rewind button on the bottom of the camera.
2. Press and hold the film rewind button.
3. Turn the film rewind knob (usually on the top left of the camera) clockwise until you feel the tension release, indicating the film has fully rewound into the cassette.
4. Open the camera back and remove the film cassette.

Техникалык тейлөө

• Keep the lens clean using a soft, lint-free cloth and lens cleaning solution.
• Store the camera in a dry, dust-free environment when not in use.
• Камераны экстремалдык температурага же нымдуулукка дуушар кылуудан алыс болуңуз.
• Regularly check the film chamber for any dust or debris that could affect film quality.

Проблемаларды чечүү

Жалпы маселелер

• Light Leaks: If your photos show streaks of light, inspect the camera back seals for wear or damage. These may need to be replaced.
• Тасма өнүкпөй жатат: Ensure the film leader is properly engaged with the take-up spool. If the film is at the end of the roll, it will also stop advancing.
• Shutter Not Firing: Check if the film advance wheel has been fully turned. The shutter will not fire if the film is not advanced.

Техникалык шарттар

Кепилдик жана колдоо

For information regarding warranty coverage or technical support, please refer to the documentation provided at the time of purchase or contact Olympus customer service directly. Specific warranty terms may vary based on region and retailer.
