1. Киришүү
This manual provides essential information for the safe and proper installation, operation, and maintenance of your MAAX Exhibit Acrylic Right-Hand Bathtub. Please read this manual thoroughly before beginning installation or use, and retain it for future reference.
The MAAX Exhibit bathtub is designed for alcove installation, featuring a right-hand drain location. It boasts a minimalist aesthetic with discreet armrests and a textured floor for enhanced safety. An integrated tiling flange simplifies installation, and an integrated skirt with an access panel (if equipped with a system) allows for easy maintenance.
2. Коопсуздук маалыматы
Always adhere to local plumbing and building codes. Professional installation is recommended. Ensure the subfloor can support the weight of the bathtub when filled with water and a person.
- Do not use abrasive cleaners or harsh chemicals on the acrylic surface.
- Ensure proper ventilation in the bathroom to prevent mold and mildew.
- Always test water temperature before entering the bathtub to prevent scalding.
- Keep children supervised when near the bathtub.
- The textured floor is designed to reduce slips, but caution should always be exercised.
Бул продукт сизди Калифорния штатында рак жана тубаса кемтиктер же башка репродуктивдик зыян келтирүүчү химиялык заттарга дуушар кылышы мүмкүн. Көбүрөөк маалымат алуу үчүн төмөнкүгө өтүңүз www.P65Warnings.ca.gov.
3. Продукциянын өзгөчөлүктөрү
- Rectangular shape bathtub for alcove installation.
- Features a right-hand drain location.
- Integrated tiling flange for simplified installation and waterproofing.
- Minimalist design with discreet, comfortable armrests.
- Textured floor for enhanced slip resistance.
- Integrated skirt with an optional access panel for system maintenance (if applicable).
4. Орнотуу жана орнотуу
Installation should be performed by a qualified professional in accordance with all local plumbing and building codes. Ensure the installation area is level and structurally sound to support the bathtub's weight when filled.
4.1 Алдын ала орнотуу текшерүү тизмеси
- Бардык компоненттер бар экенин жана бузулбаганын текшериңиз.
- Confirm rough-in dimensions match the bathtub specifications.
- Ensure adequate access for plumbing connections.
4.2 Орнотуу кадамдары (Жалпы көрсөтмөлөр)
- Prepare the alcove: Ensure walls are plumb and square, and the floor is level.
- Install drain assembly: Connect the drain and overflow according to manufacturer instructions and local codes.
- Position the bathtub: Carefully place the bathtub into the alcove, ensuring the integrated tiling flange is properly aligned with the wall studs.
- Secure the bathtub: Fasten the bathtub to the wall studs through the tiling flange.
- Connect plumbing: Connect the water supply lines to the faucet (if applicable) and verify all connections are watertight.
- Seal edges: Apply a high-quality silicone sealant around the perimeter of the bathtub where it meets the walls and floor.
- Test for leaks: Fill the bathtub with water and check for any leaks around the drain and overflow.

Image: MAAX Exhibit Bathtub installed in a bathroom setting, showcasing its right-hand drain and the integrated skirt. The bathtub is positioned under a window, highlighting its alcove installation.

Сүрөт: Кеңири view of the MAAX Exhibit Bathtub in a bathroom, illustrating its minimalist design and how it integrates into a modern bathroom environment. The image shows the full length of the tub and its surrounding wall and floor.
5. Иштөө нускамалары
The MAAX Exhibit bathtub is designed for simple operation.
- Ensure the drain stopper is closed before filling.
- Turn on the hot and cold water faucets to achieve desired water temperature.
- Ваннаны ыӊгайлуу деңгээлге чейин толтуруңуз, агызуучу дренаждан ашпоо керек.
- After use, open the drain stopper to empty the bathtub.

Image: A close-up, top-down perspective of the MAAX Exhibit Bathtub, clearly showing the right-hand drain and overflow assembly, along with the textured floor and discreet armrests.
6. Техникалык тейлөө
Proper care and maintenance will ensure the longevity and appearance of your MAAX Exhibit bathtub.
6.1 Cleaning the Bathtub
- Clean the acrylic surface regularly with a soft cloth or sponge and a non-abrasive, mild liquid cleaner specifically designed for acrylic or fiberglass bathtubs.
- Тазалагандан кийин таза суу менен жакшылап чайкаңыз.
- Avoid using abrasive cleaners, scouring pads, steel wool, or harsh chemicals (e.g., acetone, paint thinner, strong acids/bases) as these can damage the acrylic finish.
6.2 Drain and Overflow Maintenance
- Чачтын жана таштандылардын топтолушун алдын алуу үчүн, мезгил-мезгили менен дренаждык тыгынды алып салып, тазалап туруңуз.
- If equipped with an access panel, periodically check for any leaks or issues with the plumbing connections.
7. Кыйынчылыктарды
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Жай агызуу | Дренаждагы чачтар же калдыктар. | Remove and clean drain stopper. Use a drain snake if necessary. Avoid chemical drain cleaners on acrylic. |
| Суу агып чыгат | Loose plumbing connections; damaged sealant. | Check all plumbing connections and tighten if loose. Reapply silicone sealant if damaged. Consult a plumber if leaks persist. |
| Беттик сызаттар | Абразивдүү тазалоо же курч нерселер. | Use a fine grit sandpaper (e.g., 1000-2000 grit) followed by a plastic polish for minor scratches. For deep scratches, professional repair may be required. |
| Dull Finish | Residue buildup; improper cleaning. | Clean with a non-abrasive cleaner. Use an acrylic polish to restore shine. |
8. Техникалык шарттар
| Атрибут | Деталь |
|---|---|
| Модель номери | 105519-R-000-001 |
| Бренд | MAAX |
| Материал | Акрил |
| Түс | Ак |
| Продукциянын өлчөмдөрү (L x W x Y) | 59.75 дюйм x 30 дюйм x 17.75 дюйм |
| Элемент Салмагы | 155 фунт |
| Кубаттуулугу | 76 галлон |
| Дренаждын жайгашкан жери | Right-Hand |
| Орнотуу түрү | Alcove |
| UPC | 623163544763 |

Image: The MAAX Exhibit Bathtub integrated into a bathroom with a glass shower enclosure, showing how it can be part of a shower-tub combination. This view highlights the overall bathroom design and the tub's fit.
9. Кепилдик жана колдоо
For specific warranty details and customer support, please refer to the official MAAX website or contact MAAX customer service directly. Keep your proof of purchase for warranty claims.
MAAX contact information can typically be found on their official webсайтында же продуктунун таңгагында.
