Introduction
This manual provides detailed instructions for the installation, operation, and maintenance of your NORDRIVE N15021 Quadra Steel Roof Bars. Please read this manual thoroughly before installation and use to ensure safety and optimal performance.
The NORDRIVE N15021 Quadra roof bars are designed for robust and secure transport of various loads on your vehicle's roof. They feature a durable steel profile with anti-slip and anti-scratch PVC coating, and a graduated scale for quick positioning.
Коопсуздук маалыматы
Always adhere to the maximum load capacity of 75 kg for these roof bars. Do not exceed the vehicle manufacturer's recommended roof load capacity. Distribute the load evenly. Secure all loads properly to prevent shifting during transit. Regularly check the tightness of all fasteners, especially after the first few kilometers of driving and periodically thereafter.
Do not modify the roof bars. Use only original NORDRIVE parts and accessories. Driving with roof bars may affect vehicle handling, especially in strong winds or when cornering. Adjust driving speed accordingly.
Компоненттер бүттүview
The NORDRIVE N15021 Quadra Steel Roof Bars consist of the following main components:
- Two steel roof bar profiles (127 cm length)
- Rubber profile for sealing the lower groove
- Mounting feet (requires separate Evos Set or Rail Kit Steel depending on vehicle type)
- Fixing kit (specific to vehicle, if using Evos Set)
Image: The two NORDRIVE N15021 Quadra steel roof bars, black in color, with end caps. These are the main components of the roof bar system.
Image: A cross-sectional diagram of the roof bar profile, showing dimensions of 60 mm width and 30 mm height. This illustrates the robust design of the steel bar.
Орнотуу жана орнотуу
Installation of the NORDRIVE N15021 Quadra roof bars requires additional components depending on your vehicle's roof type:
- For vehicles with standard roof (no rails): Сизге керек болот Evos Set (universal) жана а specific fixing kit унааңыздын модели үчүн.
- For vehicles with integrated roof rails: Сизге керек болот Rail Kit Steel (universal).
Жалпы орнотуу кадамдары:
- Prepare the Roof Bars: Insert the rubber profile into the lower groove of each steel bar. This seals the groove after mounting and helps reduce wind noise.
- Attach Mounting Feet: Depending on your chosen mounting kit (Evos Set or Rail Kit Steel), attach the appropriate mounting feet to the roof bars. The bars feature a graduated scale for precise positioning of the feet.
- Унаадагы орду: Carefully place the assembled roof bars onto your vehicle's roof. Ensure correct orientation and spacing as per your vehicle's manual or the specific fixing kit instructions.
- Унаанын коопсуздугу: Use the specific fixing kit or Rail Kit Steel to securely fasten the roof bars to your vehicle. Follow the instructions provided with your mounting kit for tightening torque specifications.
- Акыркы текшерүү: After installation, gently pull on the roof bars to ensure they are firmly attached. Drive a short distance (e.g., 5-10 km) and then re-check all fasteners for tightness.
Image: A diagram illustrating the mounting feet for the NORDRIVE roof bars, showing the height (80 mm) and adjustable span (S = 80-111 cm). This indicates how the feet connect to the roof bar and adapt to different vehicle widths.
Image: Another diagram of the mounting feet, specifically for the L-size bars, showing an adjustable span (L = 100-136 cm). This highlights the adaptability of the system to various vehicle roof widths.
Иштөө нускамалары
Once installed, your NORDRIVE Quadra roof bars are ready for use. Always ensure that any load placed on the bars is:
- Within the maximum load capacity of 75 kg.
- Evenly distributed across both bars.
- Securely fastened using appropriate straps or tie-downs.
- Not obstructing the driver's view or vehicle lights.
When carrying loads, be mindful of increased vehicle height and potential changes in vehicle dynamics. Avoid sudden maneuvers and reduce speed, especially in windy conditions or on uneven roads.
Техникалык тейлөө
To ensure the longevity and safe operation of your NORDRIVE N15021 Quadra roof bars, follow these maintenance guidelines:
- Үзгүлтүксүз текшерүү: Periodically inspect the roof bars, mounting feet, and all fasteners for signs of wear, damage, or corrosion.
- Тыюулугун текшерүү: Re-tighten all bolts and screws as necessary, especially after long journeys or carrying heavy loads.
- Тазалоо: Clean the roof bars with mild soap and water. Avoid abrasive cleaners or solvents that could damage the PVC coating.
- Сактагыч: If removing the roof bars for extended periods, store them in a dry, cool place away from direct sunlight.
Проблемаларды чечүү
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Roof bars feel loose after installation. | Бекиткичтер жетиштүү деңгээлде бекемделген эмес. | Re-tighten all mounting bolts according to the specific fixing kit instructions. Perform a final check after driving. |
| Ашыкча шамалдын ызы-чуусу. | Rubber profile not properly seated or missing. Incorrect bar positioning. | Ensure the rubber profile is fully inserted into the lower groove. Verify correct bar spacing and position. |
| Аксессуарларды бекитүү кыйынчылыгы. | Incompatible accessories or incorrect attachment method. | Ensure accessories are compatible with Quadra steel bars. Refer to accessory instructions for proper attachment. |
Техникалык шарттар
- Модел: NORDRIVE N15021 Quadra
- Материал: Robust Steel with PVC coating
- Узундугу: 127 cm (L-size)
- Profile Өлчөмдөрү: 60 мм (туурасы) x 30 мм (бийиктиги)
- Максималдуу жүктөө жөндөмдүүлүгү: 75 kg (check vehicle manufacturer's limit)
- Элемент Салмагы: 4.16 кг
- Өндүрүүчү: Lampa
- Түсү: Кара
- Унаа тейлөө түрү: Машина
- Fit түрү: Universal (with appropriate mounting kit)
Кепилдик маалымат
NORDRIVE products are manufactured to high standards and come with a manufacturer's warranty against defects in materials and workmanship. Please retain your proof of purchase for warranty claims. For specific warranty terms and conditions, refer to the documentation provided with your purchase or contact NORDRIVE customer support.
Кардарларды колдоо
For further assistance, technical support, or spare parts, please contact your NORDRIVE retailer or visit the official NORDRIVE website. When contacting support, please have your product model number (N15021) and purchase details ready.
Өндүрүүчү: Lampa S.p.A.
Бренд: NORDRIVE
