Schellenberg 20615 Maxi Standard Tubular Motor for Roller Shutters, 15 Nm - Instruction Manual

1. Киришүү

This manual provides detailed instructions for the safe and efficient installation, operation, and maintenance of your Schellenberg 20615 Maxi Standard Tubular Motor. Please read this manual thoroughly before beginning any procedures to ensure proper use and to prevent damage or injury.

Негизги өзгөчөлүктөрү:

• Suitable for light to extra-heavy roller shutters.
• Comes ready for installation with an adapter and wall bracket.
• Features an adapter with a large contact surface for optimal power transmission.
• Equipped with mechanical end point adjustment.
• Includes a rangefinder with colored screws (yellow and white) for easy adjustment.

2. Коопсуздук нускамалары

ЭСКЕРТҮҮ: Failure to follow these safety instructions could result in electric shock, fire, and/or serious injury.

• Орнотуудан, техникалык тейлөөдөн же оңдоодон мурун электр менен камсыздоонун өчүрүлгөнүн текшериңиз.
• Орнотуу жергиликтүү электр эрежелерине ылайык квалификациялуу электрик тарабынан аткарылышы керек.
• Do not allow children to play with the motor or controls.
• Иштөө учурунда колдоруңузду жана кенен кийимдериңизди кыймылдуу бөлүктөрдөн алыс кармаңыз.
• Do not operate the motor if any part is damaged or malfunctioning.
• This motor is designed for roller shutters. Do not use it for other purposes.
• The motor is rated IP44, providing protection against solid objects larger than 1mm and splashing water from any direction.

3. Пакеттин мазмуну

Төмөндө тизмеленген нерселердин баары пакетиңизге камтылганын текшериңиз:

• Schellenberg 20615 Maxi Standard Tubular Motor (15 Nm)
• Adapter for roller shutter shaft
• Дубал кашаа
• End stop adjustment tool (rangefinder with colored screws)
• Mounting hardware (screws, pins)
• Instruction Manual

Image 3.1: Complete package contents including the tubular motor, adapter, wall bracket, end stop adjustment tool, and mounting hardware.

4. Техникалык шарттар

Сүрөт 4.1: Детальдуу view of the Schellenberg 20615 motor with key dimensions highlighted.

5. Орнотуу

The Schellenberg 20615 motor is designed for easy integration into existing roller shutter systems with 60 mm octagonal shafts. Ensure all safety precautions are followed before proceeding.

5.1 Preparing the Roller Shutter

1. Disconnect power to the roller shutter system at the main circuit breaker.
2. Remove the existing roller shutter mechanism from the octagнегизги вал.
3. Ensure the roller shutter box is clean and free of debris.

5.2 Installing the Tubular Motor

1. Attach the provided adapter to the motor head. The adapter ensures optimal power transmission to the roller shutter shaft.
2. Slide the tubular motor into the 60 mm octagonal shaft. Ensure it fits snugly.
3. Secure the motor and shaft assembly using the wall bracket and mounting hardware.
4. Connect the motor's electrical wires (brown, blue, black, green/yellow) to the appropriate power supply and control switch, following local electrical codes.

Сүрөт 5.1: Жакын пландан view of the Schellenberg 20615 motor head, showing the wiring connections and adjustment screws.

6. Операция

Once installed, the motor can be operated via a wall switch or a compatible remote control (sold separately).

6.1 Setting End Stops (Mechanical Adjustment)

The motor features mechanical end stop adjustment. Use the provided adjustment tool (rangefinder) to set the upper and lower limits of the roller shutter's travel.

1. Locate the two adjustment screws on the motor head (often colored yellow and white).
2. Use the adjustment tool to turn the screws. One screw controls the upper limit, the other controls the lower limit.
3. Operate the roller shutter up and down to test the limits. Adjust as necessary until the desired positions are reached. Turning the screw in one direction extends the travel, while turning it in the other shortens it.

Image 6.1: A hand using the adjustment tool to set the mechanical end stops on the tubular motor. The screws are typically located on the motor head.

6.2 Using a Wall Switch

Press the "Up" button to raise the roller shutter and the "Down" button to lower it. Pressing the button again during movement will stop the shutter.

Image 6.2: A person operating a wall-mounted switch to control the roller shutter.

7. Техникалык тейлөө

The Schellenberg tubular motor is designed for long-term, maintenance-free operation. However, periodic checks can help ensure its longevity and optimal performance.

• Жылдык текшерүү: Annually inspect the roller shutter and motor for any signs of wear, damage, or loose connections.
• Тазалоо: Keep the roller shutter and the area around the motor free from dust and debris. Do not use abrasive cleaners or solvents.
• Майлоо: The motor itself does not require lubrication. Ensure the roller shutter guides are clean and allow smooth movement.
• Кесиптик кызмат: For any complex issues or repairs, contact a qualified service technician. Do not attempt to disassemble the motor.

8. Кыйынчылыктарды

If you encounter problems with your Schellenberg tubular motor, refer to the following common issues and solutions:

9. Кепилдик жана колдоо

Schellenberg products are manufactured to high-quality standards and are backed by a manufacturer's warranty. For specific warranty terms and conditions, please refer to the warranty card included with your product or visit the official Schellenberg webсайт.

For technical support, troubleshooting assistance, or spare parts, please contact Schellenberg customer service:

• Өндүрүүчү: Alfred Schellenberg GmbH
• Дарек: An den Weiden 31, D-57078 Siegen, Germany
• Кардарларды тейлөө: +49 (0)271/89056-444
• Электрондук почта: service@schellenberg.de
• Webсайт: www.schellenberg.de
