Liebherr GNP 2303 Upright Freezer Instruction Manual

1. Продукт бүтүп калдыview

The Liebherr GNP 2303 is an upright freezer designed for efficient and reliable food preservation. This model features NoFrost technology, which prevents ice build-up and eliminates the need for manual defrosting. With a generous capacity of 185 liters, it offers ample space for frozen goods, organized across multiple drawers. The appliance is designed for freestanding installation and includes features like VarioSpace for flexible storage and energy-efficient operation.

1-сүрөт: Фронт view of the Liebherr GNP 2303 upright freezer. This image shows the appliance in its white finish with the door handle on the left side and the control panel located at the top.

2. Коопсуздук маалыматы

Please read these safety instructions carefully before installing or operating your appliance. Failure to follow these instructions may result in electric shock, fire, or injury.

• Электр коопсуздугу: Ensure the appliance is connected to a properly grounded power outlet. Do not use extension cords or multiple socket adapters. Disconnect the appliance from the power supply before cleaning or maintenance.
• Вентиляция: The appliance requires adequate ventilation to operate efficiently and safely. Do not block ventilation openings. Maintain specified clearances around the appliance as detailed in the installation section.
• Күйүүчү материалдар: Жардыргыч заттарды же күйүүчү отунду камтыган буюмдарды (мисалы, аэрозолдук кутулар) шаймандын ичинде сактабаңыз.
• Балдар жана аялуу адамдар: Бул шайманды 8 жаштан жогорку балдар жана физикалык, сезүү же акыл-эс жөндөмү начар же тажрыйбасы жана билими жок адамдар колдонсо болот, эгерде алар көзөмөлгө алынган болсо же шайманды коопсуз колдонуу боюнча нускама алган болсо жана келтирилген коркунучтарды түшүнсө. . Балдар шайман менен ойнобошу керек. Тазалоо жана колдонуучу тейлөөнү балдар көзөмөлсүз жасабашы керек.
• Зыян: Do not operate the appliance if it is damaged. Contact authorized service personnel for repairs.
• Жоюу: Dispose of the appliance in an environmentally responsible manner, in accordance with local regulations. The appliance contains refrigerants and insulation gases that require special handling.

3. Орнотуу жана орнотуу

Proper installation is crucial for the optimal performance and longevity of your freezer.

3.1 Пакеттен чыгаруу

• Carefully remove all packaging materials, including protective films and transport safeguards.
• Inspect the appliance for any transport damage. If damaged, do not connect it to the power supply and contact your supplier immediately.

3.2 Орнотуу

• Place the appliance on a firm, level floor. Use the adjustable feet to level the appliance if necessary.
• Ensure adequate ventilation. Maintain a minimum distance of 5 cm (2 inches) from walls and other appliances on all sides to allow for proper air circulation. Do not cover ventilation openings.
• Avoid direct sunlight and proximity to heat sources such as ovens, radiators, or dishwashers, as this will increase energy consumption.

3.3 Электрдик туташуу

• Туташуудан мурун, томtagТехникалык маалымат тактасында көрсөтүлгөн e жана жыштык сиздин үйүңүздүн электр энергиясы менен дал келет.
• Шайманды туура орнотулган жана жерге туташтырылган розеткага туташтырыңыз.
• Allow the appliance to stand upright for at least 4 hours before connecting it to the power supply. This allows the refrigerant to settle.

3.4 Алгачкы тазалоо

• Before first use, clean the interior and all accessories with lukewarm water and a mild detergent. Dry thoroughly.

4. Иштөө нускамалары

4.1 Күйгүзүү жана температураны орнотуу

• Plug the appliance into the power socket. The display on the control panel will illuminate.
• Use the temperature control buttons on the display to set the desired freezing temperature. The recommended temperature for long-term storage of frozen food is -18°C (0°F).
• Allow the freezer to operate for several hours (approximately 4-6 hours) before placing food inside, to ensure it reaches the set temperature.

4.2 Жаңы тамак-ашты тоңдуруу

• For optimal freezing, activate the SuperFrost function (if available) approximately 24 hours before placing fresh food into the freezer. This rapidly lowers the temperature to ensure quick freezing and preserves food quality.
• Place fresh food in the upper drawers or on the freezing shelf. Do not place warm food directly into the freezer.
• The freezing capacity of this appliance is 16 kg per 24 hours. Do not exceed this amount to maintain optimal freezing performance.

4.3 Сактоо боюнча көрсөтмөлөр

• VarioSpace: This feature allows you to remove drawers and glass shelves to create larger storage spaces for bulky items.
• Суусузданууну жана жыттын жайылышын алдын алуу үчүн тамак-ашты ар дайым жабык идиштерде же тоңдургуч баштыктарда сактаңыз.
• Label all frozen items with the date of freezing to ensure proper rotation and consumption within recommended storage times.
• The appliance is equipped with 6 drawers for organized storage.

4.4 эшик сигнализациясы

• If the freezer door is left open for an extended period, an audible alarm will sound to alert you. Close the door to silence the alarm.

5. Техникалык тейлөө жана кам көрүү

5.1 Интерьерди тазалоо

• Тазалоодон мурун шайманды кубаттан ажыратыңыз.
• Clean the interior regularly with lukewarm water and a mild, pH-neutral detergent. Avoid abrasive cleaners or solvents.
• Remove all drawers and shelves for thorough cleaning. Dry all parts thoroughly before replacing them.

5.2 Сырты тазалоо

• Wipe the exterior surfaces with a soft cloth and a mild detergent.
• Clean the condenser coils at the back of the appliance periodically (e.g., once a year) with a soft brush or vacuum cleaner to ensure efficient operation.

5.3 NoFrost технологиясы

• The Liebherr GNP 2303 features NoFrost technology, which automatically prevents ice build-up in the freezer compartment. This means manual defrosting is not required.

5.4 During Power Failure

• In case of a power failure, keep the freezer door closed to maintain the internal temperature for as long as possible. The storage time in case of power failure is approximately 24 hours.
• Эшикти керексиз ачпаңыз.

6. Кыйынчылыктарды

Кардарларды тейлөө кызматына кайрылуудан мурун, төмөнкү жалпы маселелерди жана чечимдерди текшериңиз:

If the problem persists after performing these checks, please contact authorized customer service.

7. Техникалык шарттар

8. Кепилдик жана Кардарларды колдоо

Your Liebherr appliance comes with a manufacturer's warranty. Please refer to the warranty card provided with your appliance for specific terms and conditions, including the warranty period and coverage details.

For technical assistance, spare parts, or service requests, please contact Liebherr customer support. Contact information can typically be found on the Liebherr official webсайтында же продуктуңузга кошулган документтерде.

When contacting support, please have your appliance model number (GNP 2303) and serial number ready. The serial number is usually located on the rating plate inside the appliance.
