KEMPER 90655 4800W Gas Pizza Oven Instruction Manual

1. Киришүү

Thank you for choosing the KEMPER 90655 Gas Pizza Oven. This manual provides essential information for the safe and efficient operation of your new appliance. Please read all instructions carefully before assembly, installation, and use. Keep this manual for future reference.

This high-performance gas pizza oven features a durable stainless steel structure and a refractory stone for authentic pizza cooking. With a powerful 4800W output, it can reach temperatures up to 400°C, allowing for quick and efficient cooking. The integrated piezo ignition ensures easy startup, and the thermocouple safety system provides peace of mind during operation.

2. Маанилүү коопсуздук нускамалары

ЭСКЕРТҮҮ: Бул көрсөтмөлөрдү аткарбоо өрткө, жарылууга же көмүртек кычкылы менен ууланууга алып келиши мүмкүн, бул мүлккө зыян келтирүүгө, жеке жаракат алууга же өлүмгө алып келиши мүмкүн.

• Сыртта гана колдонуу: Бул шайман сыртта колдонуу үчүн гана иштелип чыккан. Үйдө же жабык жайларда иштебеңиз.
• Газ түрү: Use only butane or propane gas as specified. Ensure the gas cylinder is compatible and correctly connected.
• Агышуу тести: Always perform a leak test on all gas connections before initial use and after any gas cylinder change. Use a soapy water solution; never use an open flame.
• Вентиляция: Ensure adequate ventilation around the appliance. Do not obstruct ventilation openings.
• Ысык беттер: The oven and its components become extremely hot during operation. Use heat-resistant gloves and exercise extreme caution to prevent burns.
• Балдар жана үй жаныбарлары: Keep children and pets away from the appliance during operation and while it is cooling down.
• Күйүүчү материалдар: Keep the oven clear of flammable materials, gasoline, and other flammable vapors and liquids.
• Thermocouple Safety: The oven is equipped with a thermocouple safety device that automatically cuts off the gas supply if the flame extinguishes. If the flame goes out, wait 5 minutes before attempting to re-ignite.
• Көзөмөл: Шайманды колдонууда эч качан кароосуз калтырбаңыз.
• Тейлөө: Do not modify the appliance. All maintenance and repairs should be performed by a qualified service technician.

3. Пакеттин мазмуну

Таңгактан чыгарганда бардык буюмдардын бар экенин жана жакшы абалда экенин текшериңиз:

• KEMPER 90655 Gas Pizza Oven Unit (Stainless Steel Structure)
• Refractory Cooking Stone
• Pizza Spatula
• User Manual
• Gas Connection Components (for screw-in or nipple type connections)

Эгерде кандайдыр бир тетиктер жок болсо же бузулуп калса, дароо сатуучуңузга кайрылыңыз.

4. Орнотуу жана чогултуу

The KEMPER 90655 Gas Pizza Oven is designed for easy assembly. Follow these steps to set up your oven:

1. Таңылганын ачуу: Бардык компоненттерди таңгактан кылдаттык менен алып салыңыз. Келечекте сактоо же ташуу үчүн таңгактарды сактаңыз.
2. Жайгашкан жери: Place the oven on a stable, non-combustible surface outdoors, away from any flammable materials or structures. Ensure there is adequate clearance around the oven for ventilation and safe operation.
3. Insert Refractory Stone: Carefully slide the refractory cooking stone into the designated slot inside the oven. Ensure it is seated correctly and level.
4. Газ менен камсыздоону туташтыруу:
   • Газ баллонунун клапаны жабык экенине ынаныңыз.
   • Connect the gas regulator hose to the oven's gas inlet. The oven supports double gas connections (screw-in or nipple type). Ensure a secure fit.
   • Connect the other end of the regulator hose to your butane or propane gas cylinder.
5. Perform Leak Test:
   • Суюк идиш самын менен сууну бирдей бөлүктөрдөн турган эритмени аралаштырыңыз.
   • Газ баллондун клапанын ачыңыз.
   • Apply the soapy solution to all gas connections (oven inlet, regulator, cylinder valve).
   • If bubbles appear, there is a leak. Close the gas cylinder valve immediately and tighten the connections. Repeat the leak test until no bubbles are observed.
   • If a leak persists, do not use the oven and contact customer support.

5. Иштөө нускамалары

Follow these steps for safe and effective operation of your KEMPER Gas Pizza Oven:

1. Ачык газ менен камсыздоо: Ensure the gas cylinder valve is fully open.
2. От алдыруу: Turn the control knob to the 'ON' position and press the piezo ignition button repeatedly until the burner ignites. You should hear a click and see a flame. If the burner does not ignite after several attempts, turn the control knob to 'OFF', wait 5 minutes, and try again.
3. Алдын ала ысытуу: Once ignited, close the oven door and allow the oven to preheat. The oven heats rapidly, reaching approximately 350°C in about 20 minutes, and a maximum of 400°C. Monitor the temperature using the thermometer on the exterior lid. Adequate preheating of the refractory stone is crucial for a crispy pizza crust.
4. Бышыруу:
   • Once the desired temperature is reached, use the provided pizza spatula to carefully place your pizza onto the hot refractory stone. The oven can accommodate up to two pizzas simultaneously.
   • Close the oven door to maintain heat.
   • Cooking times will vary depending on the pizza thickness and toppings, but typically a pizza will cook in approximately 3 minutes. Rotate the pizza halfway through cooking for even results.
   • Use the pizza spatula to remove the cooked pizza.
5. Өчүрүү: After cooking, turn the control knob to the 'OFF' position. Close the gas cylinder valve. Allow the oven to cool completely before cleaning or moving.

6. Тамак жасоо боюнча кеңештер

• Камырды даярдоо: For best results, use a high-quality pizza dough. A thin crust will cook faster and crispier.
• Топингдер: Avoid overloading your pizza with toppings, as this can lead to uneven cooking and a soggy crust.
• Flour the Spatula: Lightly flour your pizza spatula before placing the pizza on it to prevent sticking and ensure a smooth transfer to the hot stone.
• Кылдаттык менен алдын ала жылытыңыз: Do not rush the preheating process. A properly heated stone is key to a perfectly cooked pizza.
• Эксперимент: Cooking times and temperatures can vary. Experiment with different settings and rotation techniques to find what works best for your preferred pizza style.

7. Продукциянын сүрөттөрү

8. Тазалоо жана тейлөө

Үзгүлтүксүз тазалоо жана тейлөө пицца мешиңиздин узак жана оптималдуу иштешин камсыздайт.

• Муздатуу: Always ensure the oven is completely cool before attempting any cleaning or maintenance.
• Тышкы тазалоо: Дат баспас болоттон жасалган сыртын жарнама менен сүртүңүзamp кездеме жана жумшак жуугуч. Абразивдүү тазалагычтардан же бетти тырмап алуучу сүргүчтөн алыс болуңуз.
• Refractory Stone: The refractory stone will naturally darken with use. Do not use soap or detergents on the stone, as it is porous and will absorb them, affecting the taste of food. Scrape off any burnt-on food residue with a plastic scraper or stiff brush. For stubborn stains, you can gently scrape with a metal spatula. The high heat of the oven will naturally sanitize the stone during operation.
• Оттор: Periodically check the burner ports for any blockages (e.g., food debris, insect nests). Use a soft brush or compressed air to clear them.
• Сактагыч: When not in use for extended periods, store the oven in a dry, protected area. Disconnect the gas cylinder and store it according to its manufacturer's instructions.

9. Кыйынчылыктарды

If you encounter issues with your KEMPER Gas Pizza Oven, refer to the following common problems and solutions:

10. Техникалык шарттар

11. Кепилдик жана колдоо

Specific warranty information for the KEMPER 90655 Gas Pizza Oven may vary by region and retailer. Please refer to your purchase documentation or contact your point of sale for details regarding warranty coverage.

For technical support, spare parts inquiries, or any other assistance, please contact KEMPER customer service or visit the official KEMPER website. Information regarding spare parts availability is currently not provided in detail.
