myTouchSmart Programmable Indoor Digital Timer Instruction Manual

Introduction

The myTouchSmart Plug-In Digital Timer is designed to help you save time, money, and energy by automating the scheduling of your indoor lights, lamps, small appliances, electronics, and seasonal lighting. This timer allows you to set specific ON/OFF times, choose from convenient presets, or utilize a custom countdown feature to suit your daily schedule and needs. It features a single polarized outlet, a large digital display, and blue LED indicators for active programs, ensuring ease of use and reliable performance.

Жайгашуу

Setting up your myTouchSmart Digital Timer is straightforward. Follow these steps to get started:

1. Плагин: Insert the timer into a standard indoor wall outlet. Ensure it is securely plugged in.
2. Учурдагы убакытты коюу: Use the up and down arrow buttons (▲ жана ▼) to scroll and set the current time on the digital display.
3. Программанын жөндөөлөрү: You can choose from preset options or set custom ON/OFF times.

Image: Fast, Easy Setup Guide. This image illustrates the two main steps for setting up the timer: scrolling to set the current time and then setting custom ON/OFF times or choosing presets.

Image: Timer Plugged In. The myTouchSmart Digital Timer is shown plugged into a standard wall outlet, with a red canister and wooden spoon in the foreground, indicating indoor use.

Иштөө нускамалары

The myTouchSmart Digital Timer offers various programming options for flexible control:

• Custom ON/OFF Times: Use the "my on time" and "my off time" buttons to set specific daily turn-on and turn-off times. You can create up to two distinct custom daily ON/OFF times.
• Daily Presets:
  • Evening (5pm-12am): Automatically turns on in the evening and off at midnight.
  • Morning (5am-8am): Automatically turns on in the morning and off after a few hours.
  • All Night (6pm-6am): Keeps the connected device on throughout the night.
• Артка саноо функциясы: Use the "countdown" button to set a specific duration (up to 24 hours in 1-minute intervals) after which the connected device will turn off.

Image: Programming Options. This image highlights the custom ON/OFF time buttons, simple daily preset options (Evening, Morning, All Night), and the custom countdown feature on the timer's interface.

Image: Display and Button Functions. This image details the digital display, indicating clock vs. countdown mode, and points out the scroll buttons for time setting, custom ON/OFF time buttons, and the active program indicator.

Өзгөчөлүктөрү

• Energy and Cost Savings: Automate your lighting and appliance schedules to reduce energy consumption and save on electricity bills.
• Versatile Scheduling: Offers both custom daily ON/OFF times and three convenient daily presets (Evening, Morning, All Night) for various needs.
• Артка саноо таймери: Set a countdown from 1 minute up to 24 hours for temporary control.
• Single Polarized Outlet: Equipped with one polarized outlet located on the right side of the timer.
• Кеңири шайкештик: Works with LED, CFL, Incandescent, and Halogen bulbs, including dimmable LED and CFL bulbs.
• Digital Display & LED Indicators: Features a large digital display for easy reading and blue LED indicator lights to show active programs.
• Камдык батарея: An internal backup battery preserves your settings during power outages or if the timer is temporarily disconnected from the outlet.

Image: Schedule Indoor Devices. This image highlights the versatility of the timer for scheduling various indoor devices, including lamps, small appliances, electronics, and seasonal lighting.

Image: Deters Crime. This image shows the timer being used to automate lights, creating the impression of an occupied home to deter potential intruders.

Техникалык тейлөө

To ensure the longevity and optimal performance of your myTouchSmart Digital Timer, follow these simple maintenance guidelines:

• Тазалоо: Тазалоодон мурун таймерди розеткадан сууруп коюңуз. Сыртын сүртүү үчүн жумшак, кургак чүпүрөктү колдонуңуз. Суюк тазалоочу каражаттарды же абразивдүү материалдарды колдонбоңуз.
• Сактагыч: Таймерди көпкө чейин колдонбогондо, аны салкын, кургак жерде, күндүн түз нурунан жана өтө жогорку температурадан алыс сактаңыз.
• Экологиялык шарттар: This timer is designed for indoor use only. Avoid exposing it to moisture, humidity, or extreme temperatures.

Проблемаларды чечүү

If you encounter issues with your myTouchSmart Digital Timer, consider the following common solutions:

• Timer Not Turning On/Off:
  • Ensure the timer is securely plugged into a working outlet.
  • Verify that the connected appliance or light is properly plugged into the timer's outlet and is in working condition.
  • Check that the programmed ON/OFF times or preset options are correctly set and active (indicated by blue LED lights).
• Электр кубаты өчкөндөн кийин жөндөөлөр жоголдуtage:
  • The timer has a backup battery designed to retain settings during brief power interruptions. If settings are lost, the battery may be depleted or the power outage was prolonged. Re-program the desired settings.
• Дисплей иштебейт:
  • Ensure the timer is receiving power. If the display remains blank, try plugging it into a different outlet.

Техникалык шарттар

Кепилдик жана колдоо

The myTouchSmart Digital Timer comes with a Бир жылдык чектелген кепилдик өндүрүүчүдөн.

For detailed information, troubleshooting, or support, please refer to the official user guide:

Колдонуучунун колдонмосун жүктөп алуу (PDF)

Ошондой эле, өндүрүүчүнүн кеңсесине барсаңыз болот webкөбүрөөк маалымат алуу үчүн сайт: jascoproducts.com
