David Clark DC ONE-X ENC Headset Instruction Manual

1. Киришүү

The David Clark DC ONE-X ENC Headset is engineered for superior comfort, durability, and advanced technology. It features Hybrid Electronic Noise Cancellation (ENC) and Bluetooth connectivity, designed to provide clear communication and a comfortable experience during extended use. This manual provides essential information for the proper setup, operation, and maintenance of your headset.

• Hybrid Electronic Noise Cancellation: Advanced technology for effective noise reduction.
• Санариптик сигналды иштетүү: Ensures high-fidelity audio for clear communication.
• Bluetooth зымсыз технологиясы: Seamless connectivity to smart devices for calls and audio.
• Жеңил дизайн: Magnesium alloy suspension and leatherette ear seals for enhanced comfort.

2. Орнотуу

2.1 Таңгактан чыгаруу жана алгачкы текшерүү

Carefully remove the headset and all accessories from the carrying case. Inspect for any visible damage. The package includes the headset and ear cushions.

Image: The David Clark DC ONE-X ENC Headset folded for storage in its protective carrying case.

2.2 Батареяны орнотуу

The headset requires 2 AA batteries. Locate the battery compartment on the control module. Insert the batteries, ensuring correct polarity. The power indicator light will illuminate upon activation.

Image: The control module of the DC ONE-X headset, featuring controls for volume, ANC, Bluetooth, and a mute switch. The battery compartment is typically located on the back or side of this module.

2.3 Гарнитураны ыңгайлуулук үчүн тууралоо

• Баш боосун жөндөө: Extend or retract the headband slides to achieve a comfortable fit on your head. The adjustable headband ensures a secure yet light fit, minimizing pressure during long flights.
• Микрофондун жайгашуусу: The microphone boom is flexible and can be adjusted to either the left or right side of the headset. Position the microphone approximately 1/4 inch from your lips for optimal voice transmission.
• Кулак мөөрлөрү: The plush leatherette ear seals are designed for comfort and effective passive noise reduction. Ensure they form a good seal around your ears.

Image: The flexible microphone boom of the DC ONE-X headset, shown being adjusted. The microphone can be positioned on either side of the headset for user preference.

3. Иштөө нускамалары

3.1 Powering On/Off and ANC Control

• Күйгүзүү: Press and hold the power button on the control module until the indicator light turns green.
• ANC Levels: Use the ANC switch to select between High, Medium, or Low noise cancellation settings based on your environment.
• Өчүрүү: Press and hold the power button until the indicator light flashes orange and then turns off.
• Батарея көрсөткүчү: The indicator light will flash green for sufficient battery, orange for low battery, and red when batteries are critically low and about to shut off.

3.2 Bluetooth байланышы

The DC ONE-X features Bluetooth wireless technology for connecting to compatible devices such as smartphones and tablets. This allows for seamless integration of phone calls and audio playback into your headset experience.

• Жупташтыруу: Activate Bluetooth on your device and put the headset into pairing mode (refer to the control module for specific pairing instructions, usually a dedicated Bluetooth button). Select 'DC ONE-X' from your device's Bluetooth list.
• Функционалдык: Once paired, you can make/receive calls and listen to audio. The headset automatically lowers audio volume for incoming radio communications, ensuring you don't miss critical information.

3.3 Volume and Mute Controls

• Үндү көзөмөлдөө: Adjust the volume using the dedicated controls on the control module.
• Mute/Mix/Off Switch: This switch allows you to mute the microphone, mix auxiliary audio, or turn off the microphone.

4. Техникалык тейлөө

• Тазалоо: жумшак колдонуу, damp cloth to clean the headset. Avoid harsh chemicals.
• Кулак жаздыктары: Replace ear cushions as needed to maintain comfort and acoustic seal.
• Сактагыч: Store the headset in its provided carrying case when not in use to protect it from damage.

Image: The compact carrying case for the David Clark DC ONE-X headset, designed for protection and portability.

5. Кыйынчылыктарды

• Аудио жок/Үзгүлтүктүү аудио: Check all cable connections, ensure batteries are fresh and correctly installed, and verify headset is powered on.
• Микрофон өткөрбөй жатат: Ensure the microphone is properly connected and not muted. Check for any obstructions.
• Начар ызы-чууну жокко чыгаруу: Verify ear seals are properly seated and not worn. Adjust ANC level to High if needed.
• Bluetooth жупташтыруу маселелери: Ensure the headset is in pairing mode and within range of your device. Forget previous pairings on your device and try again.
• Fail-Safe Operation: The headset is designed with a fail-safe capability, ensuring basic communication functionality even if the active electronics fail or batteries run out. This provides a crucial backup in critical situations.

6. Техникалык шарттар

7. Расмий продукт Video

8. Кепилдик жана колдоо

David Clark products are known for their ruggedness and excellent customer service. While specific warranty details are not provided in this document, David Clark is recognized for prioritizing customer satisfaction and support.

For any issues, technical assistance, or warranty inquiries, please contact David Clark customer support directly. Refer to the official David Clark webакыркы байланыш маалыматы үчүн сайт же продукт таңгак.
