Weiser Fairfax акылдуу ачкычынын кирүү жана бекиткич туткасы боюнча колдонмо

1. Киришүү

This manual provides comprehensive instructions for the installation, operation, and maintenance of your Weiser Fairfax Smart Key Entrance and Deadbolt Knobset. Please read these instructions carefully before beginning installation or use to ensure proper function and security.

The Weiser Fairfax combination cylinder and deadbolt set is designed for door thicknesses ranging from 1-3/8" to 1-3/4". It features a universal latch that fits all standard doors and incorporates Weiser's "Securitishield" for increased strength and durability.

2. Продукт бүтүп калдыview жана өзгөчөлүктөрү

The Weiser Fairfax Smart Key Entrance and Deadbolt Knobset offers enhanced security and convenience with its innovative features.

• SmartKey кайра ачкыч технологиясы: Allows you to re-key your lock quickly and easily without removing it from the door. This technology provides advanced security against common break-in techniques.
• Өркүндөтүлгөн коопсуздук: Features a full 1" projection deadbolt, a 1/4" hardened steel, free-turning roller, and heavy-duty mounting screws. The lock cylinder uses two steel balls to resist drilling attacks.
• Туруктуу курулуш: Made with nickel and steel components, ensuring long-lasting performance.
• Universal Latch: Designed to fit all standard door preparations.
• Adjustable Door Thickness: Compatible with doors 1-3/8" to 1-3/4" thick.

Продукт компоненттери

Пакет төмөнкү компоненттерди камтыйт:

• Exterior Locking Knobset
• Жалгыз цилиндр Deadbolt
• Ачкычтар
• Монтаждоочу жабдык

This image displays the complete set, including the exterior knob with keyway and the single cylinder deadbolt, both in a satin nickel finish.

This image highlights the keyway and the satin nickel finish of the knob.

Бул view shows the depth and design of the knob from the side.

This image shows the internal mechanism and mounting plate of the knob.

3. Орнотуу жана орнотуу

Before installation, ensure your door is prepared with standard bore holes for both the knobset and deadbolt. Refer to the Fairfax Dimensions image for specific measurements.

3.1 Эшик даярдоо

Verify that your door thickness is between 1-3/8" and 1-3/4". The universal latch is designed to fit standard backsets (2-3/8" or 2-3/4").

This diagram provides key measurements for the Fairfax knobset, including the overall height (A), projection from the door (B), and knob diameter (C).

3.2 Орнотуу кадамдары

1. Latch орнотуу: Insert the latch into the door edge, ensuring the bevel faces the door frame. Secure with screws.
2. Strike Plate орнотуу: Attach the strike plate to the door frame, aligning it with the latch bolt.
3. Install Exterior Knob: Insert the exterior knob assembly through the door bore hole, ensuring the spindle aligns with the latch mechanism.
4. Install Interior Knob: Place the interior knob assembly over the spindle and secure it to the exterior assembly using the provided screws.
5. Deadbolt Latch орнотуу: Insert the deadbolt latch into the door edge, ensuring the bolt extends correctly. Secure with screws.
6. Install Deadbolt Cylinder: Insert the exterior deadbolt cylinder through the upper bore hole.
7. Install Interior Deadbolt Thumbturn: Attach the interior thumbturn assembly, aligning it with the cylinder tailpiece. Secure with screws.
8. Сыноо операциясы: Close the door and test both the knobset and deadbolt with the key and thumbturn to ensure smooth operation.

For detailed visual instructions, refer to the full installation guide included in your product packaging.

4. Иштөө нускамалары

4.1 Кулпуну ачуу жана ачуу

• From Exterior (Knob): Insert the key and turn to lock or unlock the knob.
• From Interior (Knob): Turn the knob to open the door. The knob may have a push-button or turn-button for locking from the inside, depending on the specific model variant.
• From Exterior (Deadbolt): Insert the key and turn to extend or retract the deadbolt.
• From Interior (Deadbolt): Turn the thumbturn to extend or retract the deadbolt.

4.2 SmartKey кайра ачкычтоо

The SmartKey technology allows you to re-key your lock to a new key in seconds. This is useful if you've recently moved, lost keys, or wish to use one key for multiple Weiser SmartKey locks.

1. Учурдагы ачкычты киргизүү: Insert your currently working key fully into the lock cylinder.
2. ачкыч: Turn the key 90 degrees clockwise (to the 3 o'clock position).
3. SmartKey куралын киргизүү: While holding the key in the 90-degree position, insert the SmartKey reset tool firmly into the small hole next to the keyway. You will feel a click.
4. Учурдагы ачкычты алып салуу: Remove the current key while keeping the reset tool inserted.
5. Жаңы ачкыч киргизүү: Insert the new key fully into the cylinder.
6. SmartKey куралын алып салуу: Remove the SmartKey reset tool.
7. Turn New Key: Turn the new key 90 degrees counter-clockwise (back to the 12 o'clock position).
8. Жаңы ачкычты сыноо: Remove the new key and test it to ensure it operates the lock correctly.

This diagram illustrates how to use the SmartKey reset tool and a new key to re-key your lock, making previous keys obsolete.

This image details the robust security measures integrated into the SmartKey cylinder, providing protection against various forced entry methods.

5. Техникалык тейлөө

Proper maintenance will ensure the longevity and smooth operation of your Weiser lockset.

• Тазалоо: Сырткы беттерин жумшак, гamp кездеме. Абразивдүү тазалоочу каражаттардан же эриткичтерден алыс болуңуз, анткени алар капталга зыян келтириши мүмкүн.
• Майлоо: If the lock mechanism feels stiff, apply a small amount of graphite lubricant or a silicone-based spray lubricant into the keyway and moving parts. Do not use oil-based lubricants, as they can attract dirt.
• Бурама тыгыздыгы: Periodically check and tighten all mounting screws to ensure the lockset remains securely fastened to the door. Do not overtighten.

6. Кыйынчылыктарды

If you encounter issues not listed here or if the suggested solutions do not resolve the problem, please contact Weiser customer support.

7. Техникалык шарттар

8. Кепилдик жана колдоо

Weiser products are backed by a limited lifetime mechanical and finish warranty, and a 1-year electronics warranty (if applicable). For specific warranty details and terms, please refer to the warranty card included with your product or visit the official Weiser webсайт.

For technical support, replacement parts, or warranty claims, please contact Weiser Customer Service:

• Webсайт: www.weiserlock.com
• Телефон: Вейзерге кайрылыңыз webаймактык байланыш номерлери үчүн сайт.

Please have your product model number (9GACS74510-018) and purchase date available when contacting support.
