1. Киришүү
This manual provides essential information for the safe and efficient operation, installation, and maintenance of your Einhell GE-PP 1100 N-A Stainless Steel Pressure Pump. Please read these instructions carefully before using the product and keep them for future reference. Proper use and adherence to safety guidelines will ensure optimal performance and longevity of the pump.
1-сүрөт: The Einhell GE-PP 1100 N-A Stainless Steel Pressure Pump. This image displays the pump's cylindrical body, primarily red and silver, with a handle at the top and a perforated intake at the bottom.
2. Коопсуздук нускамалары
Жаракат алуунун жана зыяндын алдын алуу үчүн ар дайым төмөнкү коопсуздук чараларын сактаңыз:
- Ensure the power supply matches the pump's specifications.
- Do not operate the pump with damaged cables or plugs.
- Never lift the pump by its power cable.
- Балдарды жана уруксатсыз адамдарды иштеп жаткан насостон алыс кармаңыз.
- Disconnect the pump from the power supply before any maintenance or cleaning.
- The pump is designed for pumping clear water only. Do not use it for flammable, corrosive, or explosive liquids.
- Иштеп жаткан учурда адекваттуу вентиляцияны камсыз кылыңыз.
3. Продукт бүтүп калдыview
The Einhell GE-PP 1100 N-A is a robust stainless steel pressure pump designed for various water transfer applications, such as emptying rainwater butts, reservoirs, or garden fountains. It features an automatic function that turns the device on and off based on water demand. The pump is constructed with durable materials and incorporates important safety features.
Негизги өзгөчөлүктөрү:
- Автоматтык күйгүзүү/өчүрүү функциясы: The pump activates and deactivates automatically with water demand.
- Multi-level Pump Wheel System: Provides an extra-high supply pressure for efficient water delivery.
- Дат баспас болоттон жасалган Casing: Бышыктыгын жана коррозияга туруктуулугун камсыз кылат.
- High-Quality Mechanical Seal: Contributes to a long service life.
- Кургак чуркоодон коргоо: Safeguards the pump from damage if the water supply is interrupted.
- Overload Switch: Моторду ысып кетүүдөн сактайт.
- Easily Accessible Hose Connection: Located on the pump top for convenient setup.
2-сүрөт: The 'AUTO ON/OFF' indicator on the pump. This image highlights the automatic control feature, which allows the pump to start and stop based on water demand.
3-сүрөт: Icon representing dry running protection. This symbol indicates the pump's safety feature that prevents damage when water levels are insufficient.
4. Техникалык шарттар
| Спецификация | Нарк |
|---|---|
| Модел | GE-PP 1100 NA |
| Power Source | Электр зымдары |
| Ватtage | 1100 Вт |
| Тtage | 230 V |
| Максималдуу агым ылдамдыгы | Саатына 6000 литр |
| Максималдуу көтөрүү бийиктиги | 12 Meters (Immersion depth up to 12 meters) |
| Maximum Delivery Pressure | 4.5 бар |
| Максималдуу жеткирүү бийиктиги | 45 метр |
| Продукциянын өлчөмдөрү (L x W x Y) | 5.91" x 5.51" x 19.29" (болжол менен 15см x 14см x 49см) |
| Элемент Салмагы | 8.7 килограмм (19.14 фунт) |
| Материал | Дат баспаган болот |
| Электр кабелинин узундугу | 15 метр |
4-сүрөт: Icon indicating a maximum delivery height of 45 meters. This graphic illustrates the vertical distance the pump can effectively push water.
5-сүрөт: Icon indicating a maximum flow rate of 6000 liters per hour. This image represents the volume of water the pump can move in one hour.
6-сүрөт: Icon indicating a high pressure pump with 4.5 bar. This graphic shows a pressure gauge, signifying the pump's capability to generate significant water pressure.
5. Орнотуу
Follow these steps for proper installation and setup of your pressure pump:
- Пакеттен чыгаруу: Carefully remove the pump from its packaging and inspect for any signs of damage.
- Жайгашкан жери: Position the pump in a stable location within the water source. Ensure the pump is fully submerged and stands upright. The minimum operating space required is approximately 17 cm x 17 cm.
- Шланг туташтыруу: Connect a suitable hose to the pressure connection (33.3 mm / 1" female thread) located on the top of the pump. Secure the connection to prevent leaks.
- Кубат туташуу: Plug the pump into a grounded electrical outlet that matches the specified voltage (230V). Ensure the power cable is not kinked or damaged.
7-сүрөт: Diagram illustrating the minimum operating space required for the pump. This image shows the pump submerged in water, indicating a minimum diameter of 17 cm for proper function.
8-сүрөт: Жакын план view of the pressure connection with stainless steel insert. This image details the threaded outlet where the discharge hose is attached.
6. Иштөө нускамалары
The Einhell GE-PP 1100 N-A pump is designed for user-friendly operation with its automatic features.
- Алгачкы ишке киргизүү: Once the pump is correctly installed and submerged, connect it to the power supply. The pump will automatically prime itself.
- Автоматтык иштетүү: The pump's integrated automatic function will detect water demand. When a tap or valve connected to the pump is opened, the pump will start. When the tap or valve is closed, the pump will automatically shut off after a short delay.
- Кургак чуркоодон коргоо: The pump is equipped with dry running protection. If the water level drops too low, the pump will automatically switch off to prevent damage. It will restart once sufficient water is available.
- Үзгүлтүксүз колдонуу: For immersion depths up to 12 meters, the pump can operate continuously, providing a consistent water supply.
9-сүрөт: A man lowering the Einhell pump into a well in a garden setting. This image demonstrates the typical use case of the pump for garden irrigation or water transfer from a source.
7. Техникалык тейлөө
Үзгүлтүксүз техникалык тейлөө насосуңуздун узак мөөнөттүү жана натыйжалуу иштешин камсыз кылат.
- Тазалоо: Periodically clean the pump's intake screen to prevent blockages. Disconnect power before cleaning.
- Кышкы сактоо: Before the first frost, completely drain the pump of water to prevent freezing damage. Store the pump in a dry, frost-free location.
- Текшерүү: Regularly inspect the power cable and hose connections for wear or damage. Replace any damaged parts immediately.
10-сүрөт: Close-up of the pump's intake screen at the bottom. This image shows the perforated filter designed to prevent large debris from entering the pump mechanism.
11-сүрөт: Cross-section diagram of the pump's internal components. This illustration provides a view of the multi-level pump wheel system and other internal mechanisms.
8. Кыйынчылыктарды
Бул бөлүмдө насосуңуз менен кездешиши мүмкүн болгон жалпы көйгөйлөр каралат.
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Насос иштебейт | Электр энергиясы жок Overload switch tripped Кургак чуркоодон коргоо иштетилди | Электр байланышын жана сактагычты текшериңиз Насостун муздаганына уруксат бериңиз, анан кайра иштетиңиз Ensure sufficient water level |
| Төмөн басым же агымдын ылдамдыгы | Intake screen blocked Hose kinked or too small diameter Системада аба | Clean intake screen Check hose for kinks, use appropriate diameter Ensure pump is fully submerged and system is primed |
| Насос үзгүлтүксүз иштейт | Системада агып кетүү Automatic function malfunction | Бардык туташууларды жана түтүктөрдүн агып кетүүсүн текшериңиз Көйгөй чечилбесе, кардарларды колдоо кызматына кайрылыңыз |
| Pump switches off frequently | Low water level (dry running protection) Overheating (overload switch) | Адекваттуу суу менен камсыз кылуу Allow pump to cool, check for blockages |
9. Кепилдик жана колдоо
For warranty information and customer support, please refer to the documentation provided with your purchase or visit the official Einhell webсайт. Ар кандай кепилдик дооматтары үчүн сатып алганыңыздын далилин сактаңыз.
If you encounter issues not covered in this troubleshooting guide, please contact Einhell customer service for assistance. When contacting support, have your model number (GE-PP 1100 N-A) and serial number ready.
