Aputure Amaran AL-F7 LED Video Light

1. Киришүү

The Aputure Amaran AL-F7 is a compact and versatile LED video light designed for various photographic and videographic applications. It features 256 high-CRI LED lights, offering a strong output and a wide color temperature range. The AL-F7 provides precise brightness and color temperature controls, multiple charging options, and a lightweight, portable design.

This manual provides detailed instructions for the safe and effective use of your Amaran AL-F7 LED video light. Please read it thoroughly before operation and retain it for future reference.

2. Коопсуздук маалыматы

To prevent damage to the product or injury to yourself or others, always observe the following basic safety precautions:

• Продукцияны бөлүктөргө бөлбөңүз же өзгөртпөңүз. Уруксатсыз өзгөртүүлөр анын бузулушуна же иштебей калышына алып келиши мүмкүн.
• Продукцияны суудан жана башка суюктуктардан алыс кармаңыз. Нымдуу кол менен иштетпеңиз.
• Do not block the ventilation openings. Overheating can damage the device.
• Avoid direct eye exposure to the LED light. The light is very bright and can cause temporary vision impairment.
• Use only recommended power sources and accessories.
• Балдар жетпеген жерде сактаңыз.

3. Пакеттин мазмуну

Төмөндө тизмеленген нерселердин баары пакетиңизге камтылганын текшериңиз:

• Amaran AL-F7 LED Video Light
• Hot-shoe mounting ball head
• Канвас сумка
• USB Type-C charging cable (may vary by region)
• User Manual

4. Продукт бүтүп калдыview

Familiarize yourself with the components and controls of your Amaran AL-F7.

4.1 Front Panel (LED Array)

Сүрөт 1: Алдыңкы view of the AL-F7 LED panel, displaying the light-emitting diodes.

4.2 Rear Panel (Display and Battery Mount)

Figure 2: Rear panel of the AL-F7, featuring the LCD screen, battery mount, and control interface.

• LCD дисплей: Shows brightness percentage, color temperature (CT), and battery status.
• Control терүү: Used to adjust brightness and color temperature. Press to switch between modes.
• Батарея плитасы: Compatible with Sony NP-F series batteries for portable power.

4.3 Side Panels (Controls and Ports)

3-сүрөт: Каптал view showing the power switch and control dial.

4-сүрөт: Каптал view displaying the D-Tap input, 1/4" mounting point, and USB Type-C port.

• Кубат которгучу: Бирдикти күйгүзөт же өчүрөт.
• D-Tap Input: For external power supply (e.g., V-mount battery).
• USB Type-C порту: For charging and powering the unit.
• 1/4" Screw Threads: Located on three sides for versatile mounting options.

5. Орнотуу

5.1 Powering the AL-F7

The Amaran AL-F7 can be powered using one of three methods:

1. Sony NP-F Series Battery: Attach a compatible NP-F battery to the battery plate on the rear of the unit.
2. USB Type-C: Connect a USB Type-C cable from a power bank or USB power adapter to the USB-C port on the side.
3. D-Tap: Connect a D-Tap cable from a compatible power source (e.g., V-mount battery) to the D-Tap input.

Ensure the power source provides sufficient voltage and current for stable operation.

5.2 Mounting the AL-F7

The AL-F7 features 1/4" screw threads on three sides for flexible mounting. Use the included hot-shoe mounting ball head to attach the light to a camera's hot shoe or a light stand with a 1/4" screw.

Figure 5: AL-F7 mounted on a camera rig, demonstrating a typical setup.

1. Screw the hot-shoe mounting ball head into one of the 1/4" threads on the AL-F7.
2. Secure the ball head to your camera's hot shoe or a light stand.
3. Adjust the angle of the light using the ball head.

6. Иштөө

6.1 Күйгүзүү/өчүрүү

Locate the power switch on the side of the unit. Flip the switch to the 'ON' position to power on the light. Flip it to 'OFF' to power off.

6.2 Жарыктыкты жөндөө

After powering on, the LCD display will show the current brightness percentage. Rotate the control dial to adjust the brightness from 1% to 100%. The AL-F7 offers stepless control for fine-tuning.

6.3 Түс температурасын жөндөө

To switch to color temperature adjustment mode, press the control dial. The display will show the current color temperature in Kelvin (K). Rotate the control dial to adjust the color temperature within the range of 3200K to 9500K. Press the dial again to switch back to brightness adjustment.

The AL-F7's maximum output is achieved at approximately 5500K, which corresponds to daylight balanced light.

6.4 Эстутум функциясы

The AL-F7 features a built-in memory function that automatically stores the last brightness and color temperature settings used. When the light is powered on again, it will recall these settings.

7. Техникалык тейлөө

• Тазалоо: Жарыкты тазалоо үчүн жумшак, кургак чүпүрөктү колдонуңуз. Катуу химиялык заттарды же абразивдүү материалдарды колдонбоңуз.
• Сактагыч: Store the light in a cool, dry place, away from direct sunlight and extreme temperatures. Use the provided canvas bag for protection during transport and storage.
• Батареяга кам көрүү: If using NP-F batteries, follow the manufacturer's guidelines for charging and storage to prolong battery life.

8. Кыйынчылыктарды

9. Техникалык шарттар

10. Кепилдик жана колдоо

Aputure products are covered by a limited warranty. For detailed warranty information, please refer to the warranty card included with your product or visit the official Aputure webсайт. Сатып алуу квитанциясын кепилдик дооматтары үчүн сатып алуунун далили катары сактаңыз.

For technical support, service, or inquiries, please contact Aputure customer service through their official website or authorized distributors. Do not attempt to repair the unit yourself, as this may void your warranty.
