Kerbl Automatic Chicken Door Control Unit Instruction Manual

1. Киришүү

The Kerbl Automatic Chicken Door Control Unit (Model 70550) is designed to automate the opening and closing of chicken coop doors, flaps, or sliders. This system offers flexible control options including light-sensor based operation, time-based scheduling, and manual control, ensuring convenience and safety for your poultry.

Figure 1: The Kerbl Automatic Chicken Door Control Unit, showing its display and control buttons.

2. Коопсуздук маалыматы

• Always ensure the power supply is disconnected before performing any installation or maintenance.
• The unit is equipped with safety features: if the slider encounters resistance (e.g., an animal) during closing, the process will stop and resume after the obstruction is removed.
• A time delay for the light signal prevents unwanted opening due to lightning or brief changes in light conditions.
• The device automatically shuts off if the motor is overloaded.
• Keep the unit and its components out of reach of children and animals.

3. Пакеттин мазмуну

Сураныч, пакетиңизде төмөнкү компоненттердин бардыгы бар экенин текшериңиз:

• Control unit with integrated motor and wiring
• 230 V mains adapter
• 4 x AA батарейкалар
• Жарык сенсору
• 4 reversible pulleys
• Колдонмо

Figure 2: The product packaging, indicating included components and features.

4. Орнотуу

Follow these steps to set up your automatic chicken door control unit:

1. Mounting the Control Unit: Choose a suitable location on your chicken coop wall, protected from direct weather exposure if possible. Ensure it is positioned correctly relative to the door/slider.
2. Installing the Door/Slider: If not already installed, mount the chicken door or slider (available separately in two sizes) according to its own instructions. Ensure it moves freely.
3. Attaching Pulleys: Install the four reversible pulleys to guide the lifting string from the control unit to the chicken door. Position them to allow smooth, unobstructed movement of the string.


Figure 3: The control unit mounted on the side of a chicken coop, with pulleys guiding the string for the door.

4. Connecting the String: Thread the lifting string through the pulleys and attach it securely to the chicken door/slider. Ensure the string is taut but allows full range of motion for the door.

Figure 4: A complete setup showing the chicken coop, automatic door, and the Kerbl control unit installed.
5. Электр камсыздоо: The unit can be powered by either the 230 V mains adapter or the 4 x AA batteries. You can also use both power sources in parallel to ensure operation during power outages. Connect the chosen power source to the control unit.
6. Жарык сенсорунун жайгашуусу: Position the light sensor in an area that accurately reflects the ambient light conditions for your desired opening/closing times. Avoid placing it in direct sunlight or constant shadow.

5. Иштөө нускамалары

The automatic chicken door offers multiple operating modes:

5.1. Light-Dependent Control

This mode uses the light sensor to automatically open the door at dawn and close it at dusk. A configurable time delay for the light signal prevents premature opening or closing due to sudden light changes (e.g., lightning).

5.2. Time-Dependent Control

You can program specific opening and closing times. This mode allows for different schedules on weekdays and weekends, providing flexibility for your flock's routine.

5.3. Кол менен башкаруу

The door can be opened or closed manually directly on the unit via its buttons, or through an external button connected to the unit (if applicable).

5.4. Иштөөдөгү коопсуздук өзгөчөлүктөрү

• Тоскоолдуктарды аныктоо: If the slider encounters resistance from an animal or other object during closing, the motor will stop. The process will then resume once the obstruction is cleared, preventing injury to animals.
• Мотордун ашыкча жүктөлүшүнөн коргоо: The unit is designed to automatically shut off if the motor experiences an overload, protecting the device from damage.

6. Техникалык тейлөө

To ensure optimal performance and longevity of your Kerbl Automatic Chicken Door Control Unit, regular maintenance is recommended:

• Тазалоо: Periodically clean the control unit and the door/slider mechanism to remove dirt, dust, and debris that could impede operation. Use a soft, damp кездеме. Абразивдүү тазалагычтарды колдонбоңуз.
• String and Pulley Inspection: Regularly check the lifting string for fraying or wear. Inspect the pulleys to ensure they rotate freely and are not obstructed. Replace worn components as necessary.


Сүрөт 5: Жакын пландан view of the red reversible pulleys, essential for smooth door operation.

• Батареяны текшерүү: If using battery power, check the battery level periodically and replace all four AA batteries when indicated or when performance degrades.
• Door/Slider Movement: Ensure the chicken door/slider itself moves smoothly within its tracks without sticking or excessive friction. Lubricate tracks if necessary, using animal-safe lubricants.

7. Кыйынчылыктарды

If you encounter issues with your automatic chicken door, refer to the following common problems and solutions:

8. Техникалык шарттар

• Модел: 70550
• Бренд: Kerbl
• Материал: Пластик
• Макс. Көтөрүү жөндөмдүүлүгү: Болжол менен 2.5 кг (5.5 фунт)
• Min. Lifting Capacity: 0.5 кг (1.1 фунт)
• Макс. Көтөрүү бийиктиги: 600 мм (23.6 дюйм)
• Электр камсыздоо: 230 V mains operation or 4 x AA batteries (can be used in parallel)
• Продукциянын өлчөмдөрү: Approximately 20 x 20 x 20 cm (7.9 x 7.9 x 7.9 inches); 860 g (1.9 lbs)
• Түсү: Жашыл
• Сунушталган түрлөр: All bird sizes

9. Кепилдик жана колдоо

This Kerbl Automatic Chicken Door Control Unit comes with a үч жылдык кепилдик сатып алынган күндөн тартып.

For technical support, troubleshooting assistance, or warranty claims, please contact your retailer or Kerbl customer service. Please have your model number (70550) and proof of purchase ready when contacting support.
