1. Киришүү
Thank you for choosing the VONROC 1800W Paint/Cement Mixer. This powerful tool is designed for efficient mixing of various materials, from light liquids like paint and lacquer to heavier substances such as cement, mortar, adhesive, and plaster. This manual provides essential information for safe operation, setup, maintenance, and troubleshooting to ensure optimal performance and longevity of your mixer.
2. Жалпы коопсуздук нускамалары
Бул электр шайманын иштетүүдөн мурун ар дайым бардык коопсуздук эскертүүлөрүн жана нускамаларын окуп, түшүнүңүз. Эскертүүлөрдү жана нускамаларды аткарбоо электр шокуна, өрткө жана/же олуттуу жаракатка алып келиши мүмкүн.
- Жумуш аймагынын коопсуздугу: Иштеген жериңизди таза жана жарыктандырыңыз. Башаламан же караңгы жерлер кырсыкка чакырат. Жарылуучу чөйрөдө, мисалы, күйүүчү суюктуктар, газдар же чаң бар жерде электр шаймандарын иштетпеңиз.
- Электр коопсуздугу: Электр шайманынын сайгычтары розеткага дал келиши керек. Эч качан сайгычты эч кандай жол менен өзгөртпөңүз. Шымды кыянаттык менен пайдаланбаңыз. Эч качан шнурду электр шайманын алып жүрүү, тартуу же электр розеткасынан сууруп алуу үчүн колдонбоңуз. Шнурды ысыктан, майдан, курч жээктерден же кыймылдуу бөлүктөрдөн алыс кармаңыз.
- Жеке коопсуздук: Always wear appropriate personal protective equipment (PPE) including safety glasses, hearing protection, and gloves. Dress properly; do not wear loose clothing or jewelry. Keep hair and clothing away from moving parts.
- Электр куралын колдонуу жана сактоо: Электр аспапты күчтөп албаңыз. Колдонмоңуз үчүн туура электр шайманын колдонуңуз. Оңдоолорду жасоодон, аксессуарларды алмаштыруудан же электр шаймандарын сактоодон мурда вилканы кубат булагынан ажыратыңыз. Бош турган электр шаймандарын балдар жетпеген жерде сактаңыз.
- Specific Mixer Safety: Ensure the agitator is securely fastened before operation. Always immerse the agitator in the material before starting the mixer to prevent splashing. Use both hands to maintain control of the mixer during operation.
3. Продукт бүтүп калдыview
The VONROC PM502AC mixer is engineered for durability and ease of use, featuring a robust 1800W motor and ergonomic design.
Image 3.1: The VONROC 1800W Paint/Cement Mixer in operation.
This image displays the main unit of the VONROC 1800W Paint/Cement Mixer, showing its green and black housing, dual ergonomic handles, and the attached mixing paddle submerged in a grey material, indicating its use for mixing. The design emphasizes stability and control during operation.
Негизги өзгөчөлүктөрү:
- 1800W күчтүү мотор: Delivers optimal results even with heavy materials.
- Эки ылдамдык орнотуулары: Allows selection of the optimal power and speed combination for various materials.
- Жумшак баштоо функциясы: Prevents jerky starts and reduces material splashing.
- Constant Speed Electronics: Maintains consistent motor speed under load.
- Ашыкча жүктөн коргоо: Enhances durability and reliability for long-term safe operation.
- Эргономикалык туткалары: Wide and comfortable handles provide optimal grip and control.
- 3-meter Rubber Cable: камсыз кылат ample freedom of movement during use.
Image 3.2: Key features of the VONROC 1800W Paint/Cement Mixer.
This diagram highlights the main features of the VONROC mixer: an 1800W motor for optimal results, soft start to prevent splashing, overload protection for durability, and two speed settings for versatility with various materials.
4. Орнотуу жана чогултуу
Before first use, ensure all components are present and undamaged. The mixer typically comes with the main unit and a detachable agitator paddle.
- Пакеттен чыгаруу: Carefully remove all contents from the packaging. Retain packaging for future storage or transport.
- Attaching the Agitator: Align the threaded end of the agitator shaft with the mixer's spindle. Rotate the agitator clockwise until it is securely tightened. Use the provided wrench if necessary to ensure a firm connection.
- Кубат туташуу: Ensure the mixer's power switch is in the 'OFF' position. Plug the 3-meter power cable into a suitable grounded electrical outlet (230 Volts).
5. Иштөө нускамалары
The VONROC mixer is designed for efficient mixing of various materials. Always prepare your materials and work area before starting.
Материалды даярдоо:
- Ensure the mixing container is stable and large enough to prevent overflow during mixing.
- Add the material to be mixed according to its specific instructions.
Ылдамдыкты жөндөө:
The mixer features two mechanical speed settings and electronic variable speed control to match the material's consistency and type.
Image 5.1: Adjusting speed settings based on material.
This image illustrates the two available speed settings for the mixer. Speed 1 operates between 180-400 RPM, suitable for lighter materials, while Speed 2 operates between 300-700 RPM, ideal for heavier or thicker mixtures. Users can adjust the speed based on the material type and desired consistency.
- Speed 1 (180 - 400 rpm): Recommended for lighter, less viscous materials such as paint, lacquer, or thin plaster.
- Speed 2 (300 - 700 rpm): Suitable for heavier, more viscous materials like cement, mortar, thick adhesives, or wallpaper paste.
- Use the electronic variable speed control dial to fine-tune the RPM within the selected mechanical speed range.
Mixing Procedure:
- Select the appropriate speed setting for your material.
- Эргономикалык туткаларды колдонуп, миксерди эки колуңуз менен бекем кармаңыз.
- Immerse the agitator paddle fully into the material before switching on the mixer.
- Press the power switch to start the mixer. The soft start function will ensure a smooth ramp- өйдө.
- Slowly move the agitator through the material, ensuring thorough mixing from the bottom up and around the sides of the container.
- Continue mixing until the desired consistency is achieved and no lumps remain.
- Before removing the agitator from the material, switch off the mixer and allow the paddle to stop rotating completely.
Image 5.2: Versatility for various mixing tasks.
This image demonstrates the mixer's versatility, showing its application for mixing paint and lacquers, filler and plasterwork, cement mortar, and various adhesives and pastes. The 2-stage motor makes it suitable for a wide range of materials.
Image 5.3: Achieving lump-free mixtures.
This image shows a person using the VONROC mixer to thoroughly mix cement in a large bucket, emphasizing the tool's ability to create a perfect, lump-free mixture, which is crucial for quality work.
6. Техникалык тейлөө жана кам көрүү
Regular maintenance ensures the longevity and safe operation of your VONROC mixer.
- Тазалоо: After each use, disconnect the mixer from the power supply. Clean the agitator paddle immediately after use to prevent material from hardening on it. Use water and a brush for water-based materials, or appropriate solvents for oil-based materials. Wipe the main unit with a damp кездеме. Катуу химиялык заттарды же абразивдүү тазалагычтарды колдонбоңуз.
- Сактагыч: Store the mixer in a dry, secure place, out of reach of children. Ensure the power cord is neatly coiled and not kinked.
- Текшерүү: Periodically inspect the power cord for any damage. Check the agitator for wear or bending. If any damage is found, do not use the tool and contact customer support for repair or replacement.
7. Кыйынчылыктарды
Бул бөлүмдө аралаштыргычыңызда кездешүүсү мүмкүн болгон жалпы көйгөйлөр каралат.
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Миксер иштебейт. | No power supply; Power switch off; Overload protection activated. | Check power connection; Ensure switch is ON; Allow mixer to cool down, then restart. |
| Motor runs but agitator does not turn. | Agitator not properly attached; Agitator jammed. | Securely fasten agitator; Disconnect power, clear any obstruction. |
| Excessive splashing during mixing. | Agitator not fully immersed; Speed too high for material. | Ensure agitator is fully immersed before starting; Reduce speed setting. |
| Миксер ысып кетет. | Continuous heavy load; Blocked ventilation. | Reduce load or take breaks; Ensure ventilation slots are clear. |
8. Техникалык шарттар
Refer to the following specifications for your VONROC PM502AC mixer:
- Модель номери: PM502AC
- Өндүрүүчү: ВОНРОК
- Күч: 1800 Ватт
- Тtage: 230 вольт
- Ылдамдык 1: 180 - 400 об/мин
- Ылдамдык 2: 300 - 700 об/мин
- Agitator Diameter: 140 мм
- Agitator Tool Length: 600 мм
- Продукциянын өлчөмдөрү (L x W x Y): 24 x 32 x 40 см
- Салмагы: 6.26 килограмм
- Кабелдин узундугу: 3 метр
9. Кепилдик жана колдоо
VONROC products are manufactured to high-quality standards. For warranty information, product support, or to inquire about spare parts, please refer to the documentation included with your purchase or visit the official VONROC webсайт. Ар кандай кепилдик дооматтары үчүн сатып алганыңыздын далилин сактаңыз.
