Intex Krystal Clear Sand Filter Pump & Saltwater System

Introduction

This manual provides essential information for the safe and efficient operation, installation, and maintenance of your Intex Krystal Clear Sand Filter Pump & Saltwater System. Please read all instructions carefully before use to ensure proper function and longevity of the product.

Image: The Intex Krystal Clear Sand Filter Pump and Saltwater System, showing the sand filter tank, pump, and control unit.

Маанилүү коопсуздук маалыматы

ЭСКЕРТҮҮ: Бул нускамаларды аткарбоо олуттуу жаракатка же өлүмгө алып келиши мүмкүн.

• Always disconnect the power cord from the electrical outlet before performing any maintenance or servicing.
• Бул шайман физикалык, сезүү же акыл-эс жөндөмү начар же тажрыйбасы жана билими жок адамдар үчүн, эгерде алардын коопсуздугуна жооптуу адам тарабынан көзөмөлсүз же шайманды колдонуу боюнча көрсөтмө болбосо, колдонууга арналбайт.
• Балдар шайман менен ойнобошу үчүн аларды көзөмөлгө алуу керек.
• The appliance must be supplied by a residual current device (RCD) having a rated residual operating current not exceeding 30 mA.
• Шайман жерге туташтырылган розеткага туташтырылышы керек.
• Электр шнурун көмбөңүз. Шнурду чөп чапкычтар, чөп кыркуучу машиналар же башка жабдуулар зыян келтирбей турган жерге коюңуз.
• To reduce the risk of electric shock, do not use extension cords, timers, plug adapters, or converter plugs to connect the unit to electric supply; provide a properly located outlet.
• Ensure the system is placed on a firm, level surface.

Пакеттин мазмуну

Бардык компоненттер бар экенин жана бузулбаганын текшериңиз:

• Sand Filter Tank with Multi-Port Valve
• Filter Pump Motor
• Saltwater System Electrolytic Cell
• Санариптик таймер менен башкаруу панели
• Two (2) 1.5-inch (38mm) Connector Hoses
• HydroAeration Technology Inlet Fitting
• 25-foot (7.6m) Power Cord with Built-in GFCI
• Басым өлчөгүч
• Чыпкалоочу себет
• Колдонуучунун колдонмосу (бул документ)

Орнотуу жана орнотуу

1. Сайтты тандоо

Choose a level, firm location for the filter pump and saltwater system. It should be at least 10 feet (3 meters) from the pool and accessible for maintenance. Ensure the location is protected from direct sunlight and extreme weather conditions.

2. Ассамблея

1. Place the filter tank on its base.
2. Install the multi-port valve onto the top of the filter tank, ensuring a secure seal.
3. Connect the pump motor to the filter tank.
4. Connect the saltwater system electrolytic cell to the pump outlet.
5. Attach the two 1.5-inch connector hoses between the system and your pool's inlet and outlet fittings.
6. Install the HydroAeration Technology inlet fitting into your pool's return jet.

Image: Diagram showing key features of the sand filter pump, including the pressure gauge, multi-port valve, control panel, and strainer basket.

3. Фильтр медианы кошуу

This system uses sand as a filter medium. Refer to the product specifications for the correct type and amount of sand required. Carefully add the sand to the filter tank, ensuring the standpipe is centered.

4. Электр байланышы

Connect the 25-foot power cord with the built-in GFCI to a properly grounded electrical outlet. Do not use extension cords.

Операция

1. Multi-Port Valve Functions

The multi-port valve allows you to select different operating modes:

• Чыпка: Normal filtering mode. Water flows through the sand and back to the pool.
• Артка жуу: Cleans the sand filter by reversing water flow.
• Чайкоо: Used after backwashing to settle the sand.
• Кайра жүгүртүү: Circulates water without filtering (e.g., for chemical mixing).
• Агызуу: Бассейнден түз сууну агызып жиберет.
• Жабык: Чыпкага болгон бардык агымды өчүрөт.

Сүрөт: жакын план view of the multi-port valve on top of the sand filter, showing the handle and various settings.

2. Saltwater System Operation

The integrated saltwater system generates natural chlorine from salt added to the pool water, reducing the need for packaged chlorine. Ensure proper salt levels are maintained for optimal performance.

• Add pool-grade salt to your pool water according to the manual's recommendations based on your pool volume.
• Allow the salt to dissolve completely before activating the saltwater system.
• Use the control panel to set the desired operating hours for chlorine generation. The 24-hour digital timer allows for automatic on/off cycles.

Image: Visual representation of the Krystal Clear Sand Filter Pump and Saltwater System highlighting its convenience, reduced chemical use, and inexpensive maintenance.

3. HydroAeration Technology

This patented technology enhances water circulation and clarity by injecting air into the water, which causes fine particles to cluster together for more effective filtration. It also increases freshness by generating negative ions.

Image: A close-up of the water inlet jet in a pool, demonstrating the HydroAeration Technology with visible bubbles.

Image: Graphic illustrating the benefits of HydroAeration Technology: Advanced Circulation, Improved Clarity, and Increased Freshness within a pool.

Техникалык тейлөө

1. Backwashing the Sand Filter

Backwash the filter when the pressure gauge reading increases by 3-5 PSI (0.2-0.34 BAR) above its clean operating pressure, or when pool water clarity decreases. This typically occurs every 1-2 weeks depending on usage.

1. Насосту өчүрүп, электр розеткасынан ажыратыңыз.
2. Көп порттуу клапанды "BACKWASH" ​​абалына коюңуз.
3. Reconnect power and turn on the pump. Backwash until the water in the sight glass is clear (approx. 2-3 minutes).
4. Насосту өчүрүп, электр розеткасынан ажыратыңыз.
5. Көп порттуу клапанды "RINSE" абалына коюңуз.
6. Reconnect power and turn on the pump. Rinse for approximately 30-60 seconds.
7. Насосту өчүрүп, электр розеткасынан ажыратыңыз.
8. Көп порттуу клапанды кайра "ФИЛЬТ" абалына коюңуз.
9. Reconnect power and turn on the pump for normal operation.

2. Salt Cell Cleaning

The electrolytic cell may accumulate scale over time, reducing its efficiency. Clean the cell regularly, especially if the "Service" indicator light illuminates.

• Turn off the system and disconnect power.
• Remove the electrolytic cell from the system.
• Inspect the plates for scale buildup. If present, clean with a solution of 1 part muriatic acid to 4 parts water. Always add acid to water, never water to acid.
• Rinse thoroughly with fresh water before reinstallation.

3. Strainer Basket Cleaning

Periodically check and clean the strainer basket located in the pump housing to remove debris and ensure optimal water flow.

• Насосту өчүрүп, электр розеткасынан ажыратыңыз.
• Open the strainer basket lid.
• Себетти алып, бошотуңуз.
• Rinse the basket and replace it, ensuring the lid is securely fastened.

Проблемаларды чечүү

Техникалык шарттар

Image: Graphic detailing the sand filter pump specifications: System Flow Rate, Voltage, Max. Water Capacity, and GFCI Plug with power cord length.

Image: The Intex Sand Filter Pump and Saltwater System with its overall dimensions labeled: 25.6 inches height, 27.8 inches length, and 19.5 inches width.

Кепилдик жана колдоо

Intex products are manufactured with the highest quality materials and workmanship. All Intex products have been inspected and found free of defects prior to leaving the factory. Intex warrants this Krystal Clear Sand Filter Pump & Saltwater System for a period of one (1) year from the date of retail purchase.

For warranty claims or technical support, please contact Intex Customer Service. Keep your original purchase receipt as proof of purchase.

For more information, visit the official Intex webсайтка же продуктунун таңгагында көрсөтүлгөн байланыш маалыматына кайрылыңыз.
