NEBULA Cosmos Max 4K UHD Projector D2150 User Manual

1. Introduction and Overview

The NEBULA Cosmos Max 4K UHD Projector D2150 delivers a true cinema experience with stunning 4K UHD resolution. Enjoy immersive 360° true 3D audio powered by Dolby Digital Plus and Sound Dimension. This projector features Android TV 9.0, providing access to over 5000 apps for endless entertainment. Advanced image technologies like HDR10 and HLG ensure sensational visuals, while automatic and manual keystone correction, along with 3-second autofocus, simplify setup. The Cosmos Max is designed for a premium home theater and entertainment experience.

2. Кутуда эмне бар

• NEBULA Cosmos Max Projector
• Алыстан башкаруу
• Quick Start Guide
• Кубаттуу адаптер

3. Продукциянын өзгөчөлүктөрү

• True Cinema Experience: Watch your favorite movies, sports events, games, and more in astonishing quality with Cosmos Max’s 4K UHD image.
• A New Dimension of Sound: With Dolby Digital Plus and Sound Dimension, Cosmos’s speakers have been optimized to deliver 360° of true 3D audio.
• Adjustable Image Size: Change the size of Cosmos Max’s image without ever having to move the projector courtesy of the built-in digital zoom. Max out your movies at 150 inches, or scale things down for a more intimate affair—all with a simple tap of the remote.
• Upscale Everything: Cosmos Max breathes new life into your old DVDs, videos, and even live TV broadcasts thanks to Hybrid Log Gamma (HLG). It automatically detects when you’re watching non-HDR content and upscales it in real-time so everything you watch looks sensational.
• Чексиз көңүл ачуу: Whether you want to indulge in an ice-cream-fueled Prime Video binge or watch the big game via the ESPN app, Cosmos has you covered. Choose from over 5000 apps including Hulu, Disney+, HBO, and many more with Android TV. Note: For peak performance, please update to the latest firmware.

4. Орнотуу колдонмосу

4.1 Initial Power On & Placement

Place the Nebula Cosmos Max projector on a stable, flat surface. Connect the power adapter to the projector and a power outlet. Press the power button on the device or remote to turn it on.

4.2 Keystone Correction & Focus Adjustment

The projector supports Auto (Vertical ±40°) and Manual (Horizontal ±40°) keystone correction. If the projected image is tilted, turn off auto keystone correction via "Settings > Projector Settings > Keystone Correction" and then adjust manually. To trigger autofocus, slightly move the device or press the "focus" button on the remote.

Image: Nebula Cosmos Max projecting a large, clear image onto a wall, demonstrating its adjustable image size feature.

4.3 Installing Apps (e.g., Netflix)

To install apps like Netflix, go to the Google Play Store. Издөө and install the "Nebula Manager" app. Once installed, open "Nebula Manager" and install Netflix through it. For better navigation within Netflix, it is recommended to install the "Nebula Connect" app on your phone (from Google Play Store or Apple App Store) and use its mouse mode.

Image: Screenshot of the Nebula Manager app interface on the projector screen, highlighting the Netflix icon for installation.

4.4 Connecting iOS Devices (iPhone, iPad, MacBook)

To connect your iOS device, install the "AirScreen" app from the Google Play Store on your projector. Ensure both your Nebula Cosmos Max and your iOS device are connected to the same Wi-Fi network.

Image: Screenshot of the AirScreen app interface on the projector screen, illustrating the steps to connect iOS devices for screen mirroring.

4.5 Playing Media from USB Flash Drive

To play movies or other media from a USB flash drive, install a file management app (e.g., File Explorer, File Manager) and a video player from the Google Play Store. Then, you can access and play content stored on your USB flash drive.

Image: Screenshot of a file management app on the projector screen, displaying content from a connected USB drive.

5. Иштөө нускамалары

5.1 Android TV багыттоо

Use the provided remote control to navigate the Android TV 9.0 interface. Access your favorite apps, search for content, and manage settings directly from the home screen.

Image: The Nebula Cosmos Max displaying the Android TV home screen, showing various streaming app icons and navigation options.

5.2 Adjusting Image Settings

Access the image settings menu to customize your viewing experience. Options include HDR modes (Standard, Vivid, Sport, Movie, Game), brightness, contrast, color temperature, and more. Experiment with these settings to achieve your preferred picture quality.

Image: A close-up of a tiger's face, with a magnified inset demonstrating the fine detail and clarity of 4K Ultra HD resolution.

5.3 Үн жөндөөлөрүн тууралоо

The Cosmos Max features 360° true 3D audio with Dolby Digital Plus. You can adjust sound modes (Standard, Music, Movie, Sports), equalizer details, and advanced settings. The projector also supports DTS Virtual X and Dolby Atmos for enhanced audio. You can select output devices including internal speakers, Bluetooth, HDMI eARC, or S/PDIF.

Image: A diagram highlighting the projector's 4x10W speakers and Dolby Audio branding, emphasizing its sound capabilities.

5.4 Көздү коргоо функциясы

The projector is equipped with an eye protection feature that automatically dims the light if an object (like a person or pet) gets too close to the lens, preventing direct exposure to the bright light.

Image: A close-up of the projector's lens, showing a hand interacting with the device to trigger autofocus, which is also linked to eye protection.

6. Байланыш

The Nebula Cosmos Max offers a variety of connectivity options:

• HDMI: 2 ports (HDMI 1, HDMI 2/eARC, HDMI 3) for connecting devices like Blu-ray players, gaming consoles, or streaming sticks.
• USB-A: 2 ports (USB 1, USB-A) for playing media from USB flash drives or connecting USB accessories.
• Оптикалык: 1 port (S/PDIF) for high-quality audio output to external sound systems.
• LAN: Зымдуу интернет байланышы үчүн.
• AV IN: For connecting older audio/video equipment.
• USB кызматы: Тейлөө жана техникалык тейлөө максатында.
• Wi-Fi: Dual Frequency 2.4/5GHz for wireless internet connectivity.
• Bluetooth: BT4.2 for connecting external Bluetooth speakers or headphones.

7. Техникалык шарттар

8. Кыйынчылыктарды

• Netflix Installation: If Netflix is not pre-installed, install "Nebula Manager" from Google Play Store and then install Netflix through it. Use "Nebula Connect" app on your phone for mouse mode navigation.
• iOS Түзмөк туташуу: Install "AirScreen" from Google Play Store on the projector and ensure both devices are on the same Wi-Fi network.
• USB ойнотуу: Орнотуу а file management app (e.g., File Explorer) and a video player from Google Play Store to play content from a USB flash drive.
• Tilted Image: If the projected image is tilted, turn off auto keystone correction via "Settings > Projector Settings > Keystone Correction" and manually adjust vertical and horizontal keystone.
• Autofocus Not Triggering: Slightly move the device or press the "focus" button on the remote to trigger autofocus.

9. Техникалык тейлөө

To ensure optimal performance and longevity of your Nebula Cosmos Max projector, follow these maintenance guidelines:

• Тазалыкты сактоо: Regularly clean the projector lens with a soft, lint-free cloth. Avoid abrasive materials or harsh chemicals.
• Чаңды көзөмөлдөө: Keep the projector in a clean, dust-free environment. Periodically clean the ventilation grilles to prevent dust buildup, which can affect cooling.
• Программалык камсыздоонун жаңыртуулары: Ensure the projector's firmware is up to date for peak performance and access to the latest features. Check for updates via the system settings.
• Туура желдетүү: Вентиляция тешиктерин жаппаңыз. Ашыкча ысып кетүүнүн алдын алуу үчүн проектордун айланасында адекваттуу аба агымын камсыз кылыңыз.
• Сактагыч: Узак мөөнөткө пайдаланылбаганда, проекторду салкын, кургак жерде, эң жакшысы баштапкы таңгагында же коргоочу кутусунда сактаңыз.

10. Кепилдик жана колдоо

Your NEBULA Cosmos Max D2150 projector comes with a standard manufacturer's warranty. Please refer to the Quick Start Guide included in your package for specific warranty terms and conditions. For technical support or any inquiries, please visit the official NEBULA support webсайтка же кардарларды тейлөөгө кайрылыңыз.

Image: The Top FAQ section from NEBULA, providing common questions and solutions, which can also serve as a support resource.
