1. Киришүү
This manual provides comprehensive instructions for the installation, operation, maintenance, and troubleshooting of your POOLEX Jetline Selection Inverter 95 Pool Heat Pump, model PC-JLS095N. Designed for efficient heating of swimming pools up to 50 m³, this heat pump features a high-performance Mitsubishi compressor and variable speed fan, ensuring optimal performance and energy efficiency.
Please read this manual thoroughly before installing or operating the unit to ensure safe and correct usage and to maximize the lifespan of your heat pump.
2. Продукт бүтүп калдыview
The POOLEX Jetline Selection Inverter 95 is a state-of-the-art pool heat pump engineered for silent and efficient operation. It incorporates advanced inverter technology, allowing it to adapt its heating capacity to the specific needs of your pool, leading to significant energy savings.
Сүрөт 2.1: Алдыңкы view of the POOLEX Jetline Selection Inverter 95 Pool Heat Pump. This image shows the main unit with its distinctive fan grille and control panel area.
Негизги өзгөчөлүктөр төмөнкүлөрдү камтыйт:
- Жогорку натыйжалуулугу: Achieves a COP greater than 16 in 26/26 conditions, suitable for pools up to 50 m³.
- Variable Speed Technology: Equipped with a Mitsubishi compressor and variable speed fan for precise temperature control and quiet operation.
- Бир нече иштөө режимдери: Features Auto, Boost, and Eco modes to adapt to various heating requirements.
- Smart Control: Integrated WiFi technology for smartphone control and a movable LED control panel (up to 10m extension).
- Төмөн температурада иштөө: Capable of operating in ambient temperatures as low as -7°C.
Figure 2.2: The POOLEX Jetline Selection Inverter 95 heat pump positioned next to a swimming pool in an outdoor setting. This illustrates a typical installation environment for the unit.
3. Орнотуу жана орнотуу
Proper installation is crucial for the performance and longevity of your heat pump. It is recommended that installation be performed by a qualified professional.
3.1 Таңгактан чыгаруу жана текшерүү
Carefully unpack the heat pump and all accessories. Inspect for any shipping damage. Report any damage to your supplier immediately.
3.2 Сайтты тандоо
Choose a location that allows for adequate airflow around the unit and is close to the pool's filtration system. Ensure the ground is level and stable.
3.3 Компоненттерди чогултуу
The heat pump comes with essential accessories for installation:
Figure 3.1: Various accessories included with the heat pump. These include PVC connectors (Ø 50 mm 1'' ½), anti-vibration bracket kit, condensate drain hose, a maintenance box with multilingual user manual, and a wired control extension (10 m).
- Anti-vibration Bracket Kit: Install these brackets under the unit to minimize vibration and noise.
- PVC Connectors: Use the provided Ø 50 mm 1'' ½ PVC connectors to integrate the heat pump into your pool's plumbing system. Ensure all connections are watertight.
- Condensate Drain Hose: Connect the condensate drain hose to the designated outlet to manage condensation runoff.
- Wired Control Extension: The LED control panel can be extended up to 10 meters using the provided cable for convenient placement.
3.4 Электрдик туташуу
Connect the heat pump to a dedicated electrical circuit as per local electrical codes. Ensure proper grounding.
3.5 WiFi Setup
The heat pump features integrated WiFi for smartphone control. Download the compatible application (e.g., Smart Life app) from your device's app store and follow the in-app instructions to connect your heat pump to your home network. This allows for remote monitoring and control.
4. Иштөө нускамалары
Your POOLEX heat pump is designed for user-friendly operation with multiple modes to suit your heating needs.
4.1 Башкаруу панели
The LED control panel displays current settings and allows for mode selection and temperature adjustment. It can be detached and extended up to 10 meters for convenient access.
4.2 Иштөө режимдери
The heat pump offers three distinct operating modes:
- Авто режим: The heat pump automatically adjusts its power output to maintain the desired pool temperature efficiently.
- Көбөйтүү режими: Provides maximum heating power for rapid temperature increase, ideal for initial heating or quick recovery after a temperature drop.
- Эко режими: Operates at a lower power setting to conserve energy once the desired temperature is reached, maintaining it with minimal consumption.
4.3 Setting Desired Temperature
Use the up/down arrows on the control panel or the smartphone app to set your desired pool water temperature. The unit will then work to achieve and maintain this temperature based on the selected operating mode.
4.4 Иштөө принциби
The heat pump extracts heat from the ambient air and transfers it to the pool water. This process is highly efficient, especially with the variable speed compressor and fan.
Figure 4.1: Schematic diagram showing the heat pump's operation. Air is drawn in, heat is extracted, and then transferred to the pool water, which circulates through the unit.
Figure 4.2: Diagram highlighting key internal components: the variable speed fan and the variable speed compressor. These components work together to optimize heat transfer and energy consumption.
5. Техникалык тейлөө
Regular maintenance ensures optimal performance and extends the life of your POOLEX heat pump.
5.1 Күнүмдүк тазалоо
- Сырткы: Keep the exterior of the unit clean and free from dust and debris. Use a soft, damp кездеме.
- Аба алуу/чыгаруу: Ensure the air intake and outlet grilles are clear of obstructions (leaves, dirt, etc.) to maintain proper airflow.
5.2 Суу химиясы
Maintain proper pool water chemistry (pH, chlorine levels) as recommended by your pool professional. Imbalanced water can corrode internal components over time.
5.3 Кышка даярдык
Before winter or periods of extended non-use, properly winterize the heat pump according to local climate conditions. This typically involves draining water from the unit and covering it. A winterization cover (isotherm cover) may be included or available separately.
5.4 Кесиптик инспекция
It is recommended to have a qualified technician inspect your heat pump annually to ensure all components are functioning correctly and to perform any necessary adjustments.
6. Кыйынчылыктарды
This section provides solutions to common issues you might encounter with your heat pump. For more complex problems, contact customer support.
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Heat pump not turning on. | Электр энергиясы жок; өчүргүч иштен чыкты. | Check power connection and reset circuit breaker. |
| Жетишсиз жылытуу. | Low ambient temperature; dirty coils; incorrect mode. | Ensure ambient temperature is above -7°C. Clean coils. Select Boost mode for faster heating. |
| Unit making unusual noise. | Loose components; debris in fan; vibration. | Check for loose parts. Clear any debris from fan. Ensure anti-vibration mounts are correctly installed. |
| WiFi app not displaying full data. | App limitations; connectivity issues. | Ensure stable WiFi connection. Note that the app may only display basic information like current and target temperature. For detailed operational status, refer to the physical control panel. |
7. Техникалык шарттар
Detailed technical specifications for the POOLEX Jetline Selection Inverter 95 heat pump:
| Спецификация | Нарк |
|---|---|
| Модель номери | PC-JLS095N |
| Продукциянын өлчөмдөрү (L x W x Y) | 82.4 x 33.4 x 65.6 см |
| Элемент Салмагы | 38.5 кг |
| Өндүрүүчү | Poolstar |
| Кубат булагынын түрү | Гидротехникалык |
| Сунушталган бассейндин көлөмү | 40 to 50 m³ |
| Минималдуу иштөө температурасы | -7°C |
| COP (26/26 шарттары) | >16 |
| Компрессордун түрү | Mitsubishi (Variable Speed) |
| Желдетүүчү түрү | Өзгөрмө ылдамдык |
| Байланыш | Интегралдык WiFi |
8. Кепилдик жана колдоо
POOLEX is committed to 100% customer satisfaction. While specific warranty details are typically provided with your purchase documentation, we stand by the quality of our products.
If you have any questions about the product, require technical assistance, or need to address any concerns, please visit the official POOLEX website or contact their customer service directly. An excellent product is supported by excellent customer service.
