Defiant Focusing 150 люмендик LED фарасынын колдонуучу колдонмосу

1. Introduction and Overview

Сатып алганыңыз үчүн рахматasing the Defiant Focusing 150 Lumen LED Headlight. This manual provides detailed instructions for the safe and efficient operation, setup, and maintenance of your new headlight. Designed for versatility, this headlight offers bright, hands-free illumination for various tasks and activities.

Негизги өзгөчөлүктөр төмөнкүлөрдү камтыйт:

• 150 Lumen LED Output: Provides powerful illumination for clear visibility.
• Фокустоо нуру: Adjustable beam from wide flood to narrow spot for versatile lighting needs.
• 3 жарык режимдери: High, Low, and Flashing for different situations.
• Hands-Free операциясы: Comfortable and adjustable head strap allows for hands-free use.
• Туруктуу курулуш: Made from ABS, aluminum, and plastic for long-lasting performance.

1.1-сүрөт: The Defiant Focusing 150 Lumen LED Headlight removed from its packaging, showcasing its compact design and adjustable head strap. This image provides a clear view of the product's form factor and how it would appear when worn.

2. Пакеттин мазмуну

Сураныч, пакеттин мазмунун текшерип, бардык буюмдардын бар экенин жана бузулбаганын текшериңиз:

• 1 x Defiant Focusing 150 Lumen LED Headlight Unit
• 3 x AAA Alkaline Batteries (may be included depending on packaging)

2.1-сүрөт: The front of the Defiant Headlight packaging, clearly showing the headlight unit and the included AAA batteries. This view confirms the product's branding, key features, and the inclusion of batteries as part of the package.

3. Орнотуу: Батареяны орнотуу

The Defiant Headlight requires 3 AAA alkaline batteries for operation. Follow these steps to install or replace the batteries:

1. Locate the battery compartment on the back of the headlight unit. This is typically a small cover that can be slid or unlatched.
2. Батарея уясынын капкагын ачыңыз.
3. Insert 3 AAA batteries, ensuring the positive (+) and negative (-) ends align correctly with the markings inside the compartment. Incorrect insertion can damage the device.
4. Close the battery compartment cover securely until it clicks into place or is firmly sealed.
5. Test the headlight by pressing the power button to ensure it turns on.

Маанилүү: Always use fresh, high-quality alkaline batteries. Do not mix old and new batteries, or different types of batteries, as this can lead to leakage or damage.

4. Иштөө нускамалары

Your Defiant Headlight is designed for simple and intuitive operation.

4.1. Күйгүзүү/өчүрүү жана режимди тандоо

The power button is typically located on the top or side of the headlight unit.

• Күйгүзүү: Press the power button once. The headlight will typically turn on in High mode.
• Режимдерди өзгөртүү үчүн: While the headlight is on, press the power button repeatedly to cycle through the available modes:
  • Жогорку: Maximum brightness (150 Lumens) for strong illumination.
  • Төмөн: Reduced brightness for extended battery life or closer tasks.
  • Жаркылдоо: Сигнал берүү же өзгөчө кырдаалдар үчүн.
• Өчүрүү: After cycling through all modes, pressing the button one more time will turn the headlight off. Alternatively, some models may turn off if the button is held down for a few seconds.

4.2. Focusing the Beam

The Defiant Headlight features a twist-focus mechanism to adjust the beam from a wide floodlight to a narrow spotlight.

1. Grasp the front bezel or lens housing of the headlight.
2. Gently twist the bezel clockwise or counter-clockwise.
3. Observe the light beam as you twist; it will transition from a broad, diffused light to a concentrated, narrow beam. Adjust to your desired focus.

4.1-сүрөт: Жакын план view of the Defiant Headlight on its packaging, highlighting the "TWIST FOCUS" arrows. This illustrates the rotational mechanism used to adjust the light beam from a wide flood to a narrow spot, providing versatile illumination.

4.3. Баш боону тууралоо

Резинкалуу баш боосу ар кандай өлчөмдөгү баш кийимдерге же баш кийимдердин үстүнөн кийилгенде ыңгайлуу жана бекем отурушун камсыз кылуу үчүн жөнгө салынат.

• To adjust, slide the buckles on the strap to lengthen or shorten it until a snug yet comfortable fit is achieved.
• The headlight unit itself can also be pivoted up or down to direct the light beam precisely where needed.

5. Техникалык тейлөө

Proper care and maintenance will ensure the longevity and optimal performance of your Defiant Headlight.

• Тазалоо: Фараны жумшак менен сүртүңүз, гamp cloth. Do not use abrasive cleaners or solvents. Ensure the lens is clean for maximum light output.
• Батареяга кам көрүү: Remove batteries if the headlight will not be used for an extended period to prevent battery leakage, which can damage the unit.
• Сактагыч: Фараны салкын, кургак жерде, күндүн түз нурунан жана өтө жогорку температурадан алыс сактаңыз.
• Суу каршылык: While durable, this headlight is not designed for submersion. Avoid exposing it to heavy rain or water.

6. Кыйынчылыктарды

If you encounter issues with your Defiant Headlight, refer to the following common problems and solutions:

7. Техникалык шарттар

Detailed technical specifications for the Defiant Focusing 150 Lumen LED Headlight:

8. Кепилдик жана колдоо

This Defiant product is warranted to be free of defects in materials and workmanship for Сатып алган күндөн тартып 1 жыл. This warranty does not cover damage from misuse, abuse, or normal wear and tear.

For assistance, technical support, or warranty claims, please contact Defiant customer service:

• Телефон: 1-866-308-3976
• Webсайт: HOMEDEPOT.COM (as indicated on packaging for support)

8.1-сүрөт: The back of the Defiant Headlight packaging, displaying important information including warranty details, customer support contact number (1-866-308-3976), and the Home Depot website for assistance. It also includes warnings regarding battery usage.
