iO HVAC Controls TS-55 55°F Heating Thermostat User Manual

1. Продукт бүтүп калдыview

The iO HVAC Controls TS-55 is a non-adjustable heating thermostat designed to maintain a fixed temperature of 55°F (approximately 13°C). This unit is ideal for temporary construction sites or applications where a consistent, minimum heating temperature is required without user adjustment. It helps prevent freezing and maintains a stable environment, protecting property and materials.

This thermostat operates on a 24 VAC input voltage and is specifically for heating applications.

2. Коопсуздук маалыматы

WARNING: Read all instructions carefully before installation and operation. Failure to follow these instructions could result in property damage, personal injury, or death.

• Always turn off power to the heating system at the main service panel before installing or servicing the thermostat.
• Installation must be performed by a qualified technician in accordance with local electrical codes.
• Do not use this thermostat for applications other than those specified.
• Бардык зымдарды туташтыруу коопсуз жана туура изоляцияланганын текшериңиз.
• Термостатты суудан жана ашыкча нымдуулуктан алыс кармаңыз.

3. Пакеттин мазмуну

Пакетте бардык буюмдар бар экенин текшериңиз:

• iO HVAC Controls TS-55 Heating Thermostat
• Орнотуу бурамалары (адатта 2)
• Колдонуучунун Колдонмосу (бул документ)

4. Орнотуу

4.1 Монтаждалуучу жер

Орнотуу үчүн төмөнкү жерди тандаңыз:

• Болжол менен полдон 5 фут (1.5 метр) жогору.
• On an inside wall, away from direct sunlight, drafts, or heat sources (e.g., lamps, appliances, fireplaces).
• Away from windows and exterior doors.
• In an area with good air circulation, not behind curtains or furniture.

4.2 Термостатты орнотуу

1. Электр кубатын өчүрүү: Ensure power to the heating system is OFF at the main service panel.
2. Капкакты алып салуу: Carefully remove the front cover of the thermostat to expose the mounting holes and wiring terminals.
3. Кызмат орду: Place the thermostat base against the wall at the chosen location.
4. Mark holes: Mark the positions for the mounting screws.
5. Бургулоо тешиктери: Зарыл болсо, пилоттук тешиктерди бургула.
6. Коопсуз база: Fasten the thermostat base to the wall using the provided mounting screws. Do not overtighten.

4.3 Электр зымдары

The TS-55 thermostat requires a 24 VAC power supply and is designed for single-stage heating systems. Refer to your heating system's manual for specific wiring diagrams if needed.

1. Зымдарды аныктоо: Identify the R (24 VAC power) and W (Heat call) wires from your heating system.
2. Connect R wire: Connect the R wire from your heating system to the 'R' terminal on the thermostat.
3. Connect W wire: Connect the W wire from your heating system to the 'W' terminal on the thermostat.
4. Коопсуз байланыштар: Бардык зым байланыштары бекем жана коопсуз экендигин текшериңиз.
5. Капкакты алмаштыруу: Carefully replace the front cover of the thermostat.
6. Күчтү калыбына келтирүү: Turn on power to the heating system at the main service panel.

Сүрөт 1: Алдыңкы view of the iO HVAC Controls TS-55 Heating Thermostat. This image shows the compact, rectangular design of the non-adjustable thermostat.

5. Операция

The iO HVAC Controls TS-55 thermostat is designed for simple, fixed-temperature operation. It is a non-adjustable unit, meaning there are no user controls or display to change the temperature setting.

• Туруктуу температура: The thermostat is factory-preset to maintain a heating temperature of 55°F (approximately 13°C).
• Автоматтык иштетүү: When the ambient temperature in the room falls below 55°F, the thermostat will automatically activate the heating system.
• Жылытуу цикли: The heating system will continue to operate until the ambient temperature rises above 55°F, at which point the thermostat will turn off the heating.
• No User Interface: There are no buttons, switches, or screens for user interaction. Its function is entirely automatic based on the fixed temperature setpoint.

6. Техникалык тейлөө

The TS-55 thermostat requires minimal maintenance to ensure optimal performance.

• Тазалоо: Periodically wipe the exterior of the thermostat with a soft, dry cloth to remove dust. Do not use liquid cleaners or abrasive materials.
• Аба агымы: Термостаттын вентиляторлору (эгерде бар болсо) чаң же таштанды менен тосулуп калбагандыгын текшериңиз, анткени бул температураны сезүү тактыгына таасир этиши мүмкүн.
• Ички тейлөө жок: The thermostat contains no user-serviceable parts. Do not attempt to open the unit beyond removing the front cover for installation.

7. Кыйынчылыктарды

If you experience issues with your TS-55 thermostat, refer to the following common problems and solutions:

If problems persist after attempting these solutions, contact a qualified HVAC technician or iO HVAC Controls customer support.

8. Техникалык шарттар

9. Кепилдик жана колдоо

9.1 Чектелген Кепилдик

The iO HVAC Controls TS-55 Heating Thermostat comes with a 1 жылдык Чектелген Кепилдик from the date of purchase. This warranty covers defects in materials and workmanship under normal use. It does not cover damage resulting from improper installation, misuse, abuse, accidents, or unauthorized modifications.

For full warranty terms and conditions, please refer to the documentation provided with your purchase or contact iO HVAC Controls directly.

9.2 Кардарларды колдоо

If you have questions about the installation, operation, or troubleshooting of your TS-55 thermostat, please contact your retailer or a qualified HVAC professional. For direct support regarding product defects or warranty claims, please reach out to iO HVAC Controls customer service.

Please note: Contact information for iO HVAC Controls is typically found on their official webсайт же продукт таңгак.
