KOSPET Max S Android Smart Watch User Manual

1. Киришүү

This manual provides detailed instructions for the KOSPET Max S Android Smart Watch. Please read this manual thoroughly before using the device to ensure proper operation and to maximize its features. Keep this manual for future reference.

2. Коопсуздук маалыматы

• Аппаратты ажыратууга, оңдоого же өзгөртүүгө аракет кылбаңыз. Уруксатсыз өзгөртүүлөр кепилдикти жокко чыгарып, зыян келтириши мүмкүн.
• Түзмөктү өтө жогорку температурадан, түз күн нурунан жана дат басуучу заттардан алыс кармаңыз.
• Use only the provided charging cable and adapter. Using incompatible accessories may cause damage or fire.
• The device is IP67 waterproof. Avoid prolonged immersion in water or exposure to high-pressure water jets. Ensure the SIM card tray is properly sealed to maintain water resistance.
• Consult a medical professional before using the device if you have a pacemaker or other medical implants.

3. Пакеттин мазмуну

Продукцияңыздын таңгагында бардык элементтер бар экенин текшериңиз:

• KOSPET Max S Smart Watch
• Charging Cable/Dock
• Watch Band/Strap
• Колдонуучунун Колдонмосу (бул документ)
• SIM Card Tray Ejector Tool (or small screwdriver)

4. Продукт бүтүп калдыview

Familiarize yourself with the components of your KOSPET Max S Smart Watch.

Figure 4.1: KOSPET Max S Smart Watch front view showing the display with time, date, network, battery status, and app icons.

Figure 4.2: Close-up of the KOSPET Max S 2.4-inch Super Retina Display, showcasing анын тунуктугу жана жандуу тустеру.

4.3-сүрөт: Каптал view of the KOSPET Max S Smart Watch, highlighting the integrated side camera and physical buttons.

Негизги компоненттер:

• Дисплей: 2.4-inch high-definition touchscreen.
• Каптал камера: 8-megapixel camera for photos and video.
• Алдыңкы камера: 2-megapixel camera for video calls and face unlock.
• SIM карта слоту: Supports Nano SIM for 4G LTE connectivity.
• Микрофон жана Динамик: Чалуулар жана үн буйруктары үчүн.
• Жүрөктүн кагышынын сенсору: Located on the back for fitness tracking.

5. Орнотуу

5.1. Аппаратты заряддоо

Before initial use, fully charge your KOSPET Max S Smart Watch. Connect the charging cable to the watch's charging port and plug the other end into a USB power adapter (not included) or a computer's USB port. The screen will indicate charging status.

Figure 5.1: Diagram illustrating the KOSPET Max S battery life under typical usage (40 hours) and light usage (60 hours) with its 2000mAh battery.

5.2. SIM картаны орнотуу

The KOSPET Max S supports 4G LTE connectivity via a Nano SIM card. To install:

1. Power off the watch.
2. Locate the SIM card tray on the side of the watch.
3. Use the provided ejector tool (or a small screwdriver) to open the SIM card tray.
4. Carefully place the Nano SIM card into the tray with the gold contacts facing down.
5. Insert the tray back into the watch until it clicks into place. Ensure it is flush with the watch body to maintain water resistance.

Note: Some users have reported difficulty with the provided screwdriver. If necessary, use a suitable alternative tool for SIM tray access.

5.3. Баштапкы күйгүзүү

Press and hold the power button (usually on the side) until the KOSPET logo appears. Follow the on-screen prompts to complete the initial setup, including language selection, time zone, and Wi-Fi connection.

5.4. Pairing with a Smartphone

To fully utilize all features, pair your KOSPET Max S with a compatible smartphone. The recommended application is WiiWatch 2. Download it from the Google Play Store or Apple App Store.

1. Enable Bluetooth on your smartphone and the KOSPET Max S.
2. Open the WiiWatch 2 app on your smartphone and follow the instructions to search for and connect to your watch.

Note: Some users have experienced unstable Bluetooth connections with WiiWatch 2. Alternatives like "Watch Droid Phone" (for smartphone) and "Watch Droid Assistant" (for watch) may offer a more stable connection.

6. Иштөө нускамалары

6.1. Негизги навигация

• Сенсордук экран: Swipe left/right, up/down to navigate menus and screens. Tap to select.
• Кубат баскычы: Экранды ойготуу/уйку режимине өткөрүү үчүн басыңыз. Күйгүзүү/өчүрүү же кайра күйгүзүү үчүн басып кармап туруңуз.
• Артка баскычы: (If present) Returns to the previous screen.

6.2. 4G LTE Network and Calls

With a Nano SIM card installed, your KOSPET Max S can function as a standalone phone. It supports 5 network modes and global 4G/3G/2G bands.

• Чалууларды жасоо: Use the dialer app on the watch to make calls directly.
• Чалууларды кабыл алуу: Answer or decline incoming calls directly from the watch.
• Билдирүү: SMS билдирүүлөрдү жөнөтүү жана алуу.

6.3. Тиркемелер жана Google Play дүкөнү

Running on Android 10.1, the KOSPET Max S allows you to download and install applications from the Google Play Store. This includes social media, navigation, and productivity apps.

6.4. Камеранын иштеши

The watch features dual cameras:

6.1-сүрөт: жарылган view illustrating the KOSPET Max S dual camera setup, featuring an 8MP side camera and a 2MP front camera for versatile photography and video calls.

• Side Camera (8MP): Ideal for capturing photos and videos in a traditional camera orientation.
• Алдыңкы камера (2 мегапиксел): Primarily used for video calls and the Face Unlock feature.

Access the camera app from the main menu to take pictures or record videos.

6.5. GPS навигациясы

The KOSPET Max S integrates multi-satellite positioning, supporting GPS, GLONASS, and A-GPS signals for accurate location tracking and navigation.

Figure 6.2: KOSPET Max S Smart Watch displaying a map with GPS navigation, indicating multi-satellite positioning support (GPS, A-GPS, GLONASS) for precise location tracking.

Use pre-installed map applications or download your preferred navigation app from the Google Play Store.

6.6. Face Unlock and Security

Enhance the security of your watch with Face Unlock. This feature uses the front camera to recognize your face for quick and secure access.

Figure 6.3: Illustration of the KOSPET Max S Face Unlock feature, showing facial recognition in action, alongside the option for pattern unlock.

To set up Face Unlock, navigate to the security settings in your watch and follow the on-screen instructions to register your face. You can also set up a pattern or PIN as a backup.

6.7. Фитнеске көз салуу

The KOSPET Max S includes features for tracking your physical activity.

Figure 6.4: KOSPET Max S Smart Watch displaying various fitness tracking modes, including basketball, ping-pong, badminton, outdoor run, outdoor walk, ride bike, indoor run, play football, and rope skipping.

• Кадам эсептегич: Automatically tracks your daily steps.
• Жүрөктүн кагышын көзөмөлдөөчү: Measures your heart rate throughout the day.
• Спорт режимдери: Select from various sports modes (e.g., running, cycling) for more accurate tracking of specific activities.

Access fitness data through the dedicated fitness app on your watch.

7. Техникалык тейлөө

7.1. Тазалоо

Саатты жана боону жумшак менен дайыма сүртүп туруңуз, damp cloth. Avoid using harsh chemicals or abrasive materials, which can damage the finish.

7.2. Сууга туруктуулук (IP67)

The KOSPET Max S is rated IP67 waterproof, meaning it is resistant to dust and can withstand immersion in water up to 1 meter for 30 minutes. However, it is not suitable for swimming, diving, or exposure to high-pressure water. Always ensure the SIM card tray is securely closed to maintain water resistance.

8. Кыйынчылыктарды

• Саат күйбөйт: Ensure the watch is fully charged. If the issue persists, try a hard reset by holding the power button for an extended period (e.g., 15-20 seconds).
• SIM card not detected or no network:
  • Verify the SIM card is correctly inserted and the tray is fully closed.
  • Ensure your SIM card is active and has a valid data plan.
  • Check network settings on the watch to ensure mobile data is enabled.
  • Confirm compatibility with your network provider's bands.
• Bluetooth байланышы туруксуз:
  • Саатты да, смартфонуңузду да өчүрүп күйгүзүңүз.
  • Ensure both devices are within Bluetooth range.
  • Consider using alternative pairing applications like "Watch Droid Phone" and "Watch Droid Assistant" if WiiWatch 2 is problematic.
• Apps are slow or unresponsive:
  • Close background applications to free up memory.
  • Clear the cache of the problematic app.
  • Ensure the watch's software is up to date.
• GPS сигналды албай жатат:
  • Ачык жерде экениңизди тактаңыз view асмандын.
  • Check that location services are enabled in the watch settings.

9. Техникалык шарттар

10. Кепилдик жана колдоо

Warranty information for the KOSPET Max S Smart Watch is typically provided with your purchase documentation or can be found on the official KOSPET webсайт. Кепилдик камтууга, шарттарга жана шарттарга байланыштуу чоо-жайын билүү үчүн бул ресурстарды караңыз.

For technical support, troubleshooting assistance beyond this manual, or warranty claims, please contact KOSPET customer service through their official webсайтты же продуктуңуз менен берилген байланыш маалыматын.
