1. Продукт бүтүп калдыview
The ISOtunes Xtra 2.0 Earplug Earbuds are designed to provide certified hearing protection while allowing for Bluetooth audio streaming and clear communication. They feature a secure neckband design, magnetic earbuds, and a durable, water-resistant construction suitable for various demanding environments.
Figure 1: ISOtunes Xtra 2.0 Earbuds in various work settings.
2. Кутуда эмне бар
Your ISOtunes Xtra 2.0 package includes the following items:
- ISOtunes Xtra 2.0 Earbuds
- 4 pairs of ISOtunes TRILOGY™ foam eartips (XS, S, M, L)
- 3 pairs of silicone double-flange eartips (S, M, L)
- USB заряддоо кабели
- Боо менен жабдылган сактоочу баштык
Figure 2: Included accessories with your ISOtunes Xtra 2.0.
3. Орнотуу
3.1 Кулакчындарды кубаттоо
Before first use, fully charge your ISOtunes Xtra 2.0 earbuds. The earbuds feature a USB-C charging port located on the control module.
- Locate the USB-C charging port on the control module.
- Берилген USB заряддоо кабелин портко туташтырыңыз.
- USB кабелинин экинчи учун шайкеш келген USB кубат булагына (мисалы, компьютер, дубал адаптери) сайыңыз.
- The LED indicator will show charging status (typically red for charging, blue for fully charged).
Figure 3: Charging port on the control module.
3.2 Eartip Selection and Installation
Proper eartip selection is crucial for optimal noise isolation and comfort. The ISOtunes Xtra 2.0 comes with both foam and silicone eartips in various sizes.
- Select the correct size: Experiment with different sizes to find the tips that provide a snug, comfortable fit and seal your ear canal effectively.
- For foam eartips: Roll the foam tip between your fingers to compress it into a thin cylinder. Insert the compressed tip into your ear canal and hold it in place for a few seconds while it expands to create a seal.
- For silicone eartips: Gently insert the silicone tip into your ear canal until it feels secure and comfortable.
Figure 4: Proper insertion of foam eartips.
Figure 5: Noise Reduction Rating (NRR) information.
3.3 Bluetooth жупташтыруу
The ISOtunes Xtra 2.0 uses Bluetooth 5.0 for a stable wireless connection up to 30 feet.
- Ensure your earbuds are charged and powered off.
- Башкаруу модулундагы көп функциялуу баскычты LED индикатору көк жана кызыл түстө күйүп-өчкөнгө чейин басып туруңуз, бул жупташуу режимин көрсөтөт.
- Түзмөгүңүздө (смартфон, планшет ж.б.) Bluetooth иштетиңиз жана жеткиликтүү түзмөктөрдү издеңиз.
- Select "ISOtunes Xtra 2.0" from the list.
- Туташкандан кийин LED индикатору көк түстө күйөт.
The earbuds support dual connection, allowing you to connect to two devices simultaneously.
Figure 6: Bluetooth 5.0 connectivity features.
4. Иштөө нускамалары
4.1 Негизги башкаруу каражаттары
The control module on the neckband allows for easy management of audio and calls:
- Күйгүзүү/өчүрүү: Көп функциялуу баскычты басып, кармап туруңуз.
- Ойнотуу/тындыруу: Көп функциялуу баскычты кыска басыңыз.
- Үндү жогорулатуу/Кийинки трек: Short press '+' for volume up; long press '+' for next track.
- Үнүн азайтуу/Мурунку трек: Short press '-' for volume down; long press '-' for previous track.
Figure 7: Control buttons on the ISOtunes Xtra 2.0.
4.2 Чалууларды башкаруу
The integrated noise-cancelling microphone ensures clear calls even in loud environments.
- Чалууга жооп берүү/аяктоо: Көп функциялуу баскычты кыска басыңыз.
- Чакырууну четке кагуу: Көп функциялуу баскычты көпкө басыңыз.
- Үн жардамчысы: Double-press the multi-function button to activate your device's voice assistant.
4.3 Magnetic Earbuds
The earbuds feature magnets that allow them to connect together when not in use, preventing tangling and providing a convenient way to wear them around your neck. Connecting the magnets will also pause your music, and separating them will resume playback.
Figure 8: Magnetic earbuds for secure storage and auto-pause.
4.4 SafeMax™ Technology
The ISOtunes Xtra 2.0 incorporates SafeMax™ Technology, limiting the volume output to 85 dB to protect your hearing from prolonged exposure to loud music.
5. Техникалык тейлөө
5.1 Тазалоо
The ISOtunes Xtra 2.0 earbuds are IP67 rated, meaning they are completely dust, sweat, and waterproof. This allows for easy cleaning.
- Wipe the earbuds and neckband with a damp кездеме.
- For eartips, remove them from the earbuds and wash with mild soap and water. Ensure they are completely dry before reattaching.
- Катуу химиялык заттарды же абразивдүү тазалоочу каражаттарды колдонбоңуз.
Figure 9: IP67 rating for dust, sweat, and water resistance.
5.2 Сактоо
When not in use, store your earbuds in the provided drawstring pouch to protect them from dust and damage.
6. Кыйынчылыктарды
If you encounter issues with your ISOtunes Xtra 2.0 earbuds, try the following steps:
- Кубат жок: Ensure the earbuds are fully charged. Connect them to the charging cable and check the LED indicator.
- Жупташуу мүмкүн эмес: Make sure the earbuds are in pairing mode (flashing blue and red LED). Turn off and on your device's Bluetooth, then try pairing again. Ensure the earbuds are within 30 feet of your device.
- Үн жок: Check the volume levels on both the earbuds and your connected device. Ensure the earbuds are properly seated in your ear canal.
- Poor Sound Quality/Noise Isolation: Verify that you are using the correct size and type of eartips for a proper seal. Re-insert foam tips if necessary.
- Чалуу сапаты маселелери: Ensure the microphone is not obstructed. Move to a quieter environment if possible.
For further assistance, please refer to the support section or contact ISOtunes customer service.
7. Техникалык шарттар
| Өзгөчөлүк | Спецификация |
|---|---|
| Модель аты | XTRA 2.0 (IT-22) |
| Ызы-чууну азайтуу рейтинги (NRR) | 27 дБ |
| Көлөмдүн чеги | 85 dB (SafeMax™ Technology) |
| Батареянын иштөө мөөнөтү | Up to 11 hours (music & talk time) |
| Байланыш технологиясы | Bluetooth 5.0 |
| Зымсыз диапазон | 30 метрге чейин |
| Сууга туруктуулук деңгээли | IP67 (Dust, Sweat, and Waterproof) |
| Микрофон | Ызы-чууну изоляциялоочу микрофон |
| Заряддоо порту | USB-C |
| Элемент Салмагы | 170 грамм (6 унция) |
| Материал | Пластик |
Video 1: Official ISOtunes XTRA 2.0 Product Overview. This video provides a visual summary of the earbuds' key features and benefits, including their use in various work environments, noise reduction capabilities, and durable design.
8. Кепилдик жана колдоо
ISOtunes products are designed for durability and performance. Your ISOtunes Xtra 2.0 earbuds come with a 1-year warranty, ensuring satisfaction and product reliability.
For warranty claims, technical support, or additional product information, please visit the official ISOtunes store or contact their customer service directly.
зыярат кылыңыз ISOtunes Store көбүрөөк маалымат алуу үчүн.
