Ring Smart Dash Cam RSDC2000 User Manual

1. Introduction and Overview

Capture your driving experience with the Ring Automotive RSDC2000 Smart Dash Cam. This advanced dash cam features Full HD 1080p resolution at 30 frames per second, providing clear and detailed video footage. Integrated Wi-Fi and a G-sensor ensure easy connectivity and automatic incident recording. The Ring Connect app allows convenient access and control, while the compact 2-inch screen offers easy viewing. Its sleek black design ensures it blends seamlessly with your vehicle's interior, making it an essential accessory for safe and secure driving.

Image: The Ring Smart Dash Cam RSDC2000 shown with its magnetic mount and a smartphone displaying the Ring Connect application, highlighting its connectivity features.

2. Продукциянын өзгөчөлүктөрү

• Secure Recording: Works in conjunction with Ring Connect to save, store, and easily share captured content.
• G-сенсор: Automatically saves moments during a collision, ensuring critical footagе сакталган.
• Оңой орнотуу: Simple setup with a magnetic mount and included trim tool for quick and secure placement.
• App and Wi-Fi Connectivity: Stay connected with the Ring Connect app and Wi-Fi features for convenient viewing and sharing of footage.
• High Quality Video: Enjoy crystal-clear videos captured in Full HD 1080p at 30fps.
• Паркинг режими: Records collisions even when the vehicle is parked, providing continuous surveillance.
• Микро SD карта слоту: Supports up to 32GB capacity for ampжазууларды сактоо.
• Компакт дизайн: Smaller than a credit card, ensuring an unobstructed view айдап бара жатканда.
• Кең талаа View: 120-даражадагы талаа view to capture a comprehensive view жолдун.

Image: Diagram illustrating the secure recording capabilities, including G-sensor, parking mode, and Micro SD card slot.

Image: Visual representation of the dash cam's compact size, comparing it to a credit card and showing its dimensions.

3. Кутуда эмне бар?

The Ring Smart Dash Cam RSDC2000 package includes the following components:

• Ring Smart Dash Cam RSDC2000 Body
• 3.5m 12V DC Power Cable with USB
• Магниттик тоос
• Quick Start Instructions
• Кыркынды алып салуу куралы
• Recording Window Sticker
• Spare Self-Adhesive Pad

Image: An illustration detailing all items included in the product packaging, such as the dash cam unit, power cable, magnetic mount, and tools.

4. Орнотуу

Follow these steps to set up your Ring Smart Dash Cam RSDC2000:

1. Монтаждоо ордун тандоо: Алдыңкы айнегиңизде тунук жер бар жерди тандаңыз view of the road and does not obstruct your driving visibility. The area should be clean and dry.
2. Attach Magnetic Mount: Secure the magnetic mount to the chosen location on your windshield using the adhesive pad. Ensure it is firmly attached.
3. Видеорегистраторду туташтырыңыз: The dash cam unit easily attaches to the magnetic mount. Ensure it clicks securely into place.
4. Туташуу кубаты: Plug the 3.5m 12V DC power cable into the dash cam and then into your vehicle's cigarette lighter socket. Route the cable neatly along the windshield edge using the included trim removal tool to tuck it under the vehicle's trim for a clean installation.
5. Микро SD картаны салыңыз: Insert a compatible Micro SD card (up to 32GB, not included) into the designated slot on the dash cam.
6. Баштапкы күйгүзүү: Once connected to power, the dash cam should power on automatically. Follow any on-screen prompts for initial setup, such as setting the date and time.
7. Download Ring Connect App: Download the Ring Connect app from your smartphone's app store. This app will allow you to connect to your dash cam via Wi-Fi for viewing and managing footage.

Image: The dash cam mounted on a car's windshield, demonstrating its discreet placement and ease of installation.

5. Иштөө нускамалары

The Ring Smart Dash Cam RSDC2000 is designed for straightforward operation:

• Автоматтык жаздыруу: The dash cam will automatically begin recording when your vehicle's ignition is turned on. Footage is recorded in Full HD 1080p at 30 frames per second.
• Цикл жаздыруу: When the Micro SD card is full, the dash cam will automatically overwrite the oldest unprotected footage to continue recording.
• G-Sensor (Incident Detection): Капыстан сокку же кагылышуу болгон учурда, орнотулган G-сенсору окуяны автоматтык түрдө аныктайт жана учурдагы видео сегментти кулпулап, анын циклдик жазуу аркылуу кайра жазылышына жол бербейт.
• Паркинг режими: When enabled, the dash cam can continue to monitor your vehicle for impacts even when parked. If an impact is detected, it will automatically record and save the footage.
• Using the 2-inch Screen: The integrated 2-inch screen allows for real-time viewing of the recording, playback of saved footage, and navigation through the device's menu settings.
• Wi-Fi and Ring Connect App: Connect your smartphone to the dash cam's Wi-Fi network. Open the Ring Connect app to view жаша фооtage, download recorded videos to your phone, adjust settings, and share clips.

Image: A driver's perspective showing the dash cam mounted on the windshield, illustrating its wide 120-degree field of view and clear recording capabilities.

Image: The dash cam and a smartphone with the Ring Connect app, demonstrating the wireless connectivity for footage transmission without removing the camera.

6. Техникалык тейлөө

Proper maintenance ensures the longevity and optimal performance of your Ring Smart Dash Cam RSDC2000:

• Линзаны тазалоо: Regularly wipe the camera lens with a soft, lint-free cloth to ensure clear recordings. Avoid abrasive cleaners.
• Экранды тазалоо: Use a microfiber cloth to gently clean the 2-inch display screen.
• Микро SD картаны башкаруу: It is recommended to format the Micro SD card periodically (e.g., once a month) using the dash cam's menu settings. This helps maintain card health and prevents data corruption. Back up any important footage форматтоодон мурун.
• Программалык камсыздоонун жаңыртуулары: Ring Automotive текшерүү website or the Ring Connect app for any available firmware updates. Keeping your dash cam's firmware up-to-date can improve performance and add new features.
• Температураны эске алуу: Avoid exposing the dash cam to extreme temperatures for prolonged periods. If the vehicle is parked in direct sunlight on a hot day, consider removing the dash cam or shading it.
• Кабелдик текшерүү: Periodically inspect the power cable for any signs of wear or damage. Replace if necessary.

7. Кыйынчылыктарды

If you encounter issues with your Ring Smart Dash Cam RSDC2000, refer to the following common troubleshooting steps:

• Dash Cam күйбөй жатат:
  • Ensure the power cable is securely connected to both the dash cam and the vehicle's cigarette lighter socket.
  • Check if the vehicle's cigarette lighter socket is receiving power (e.g., by testing with another device).
  • Try a different 12V power source if available.
• Жаздыруу көйгөйлөрү (жаздыруу жок/бузулган Fileс):
  • Micro SD карта туура салынганын текшериңиз.
  • Format the Micro SD card using the dash cam's menu. If issues persist, try a different, high-quality Micro SD card.
  • Check if the card is full and loop recording is enabled.
• Wi-Fi туташуу көйгөйлөрү:
  • Смартфонуңузда жана видеорегистраторуңузда Wi-Fi күйгүзүлгөнүн текшериңиз.
  • Камераны да, смартфонуңузду да өчүрүп күйгүзүңүз.
  • Ensure you are within close proximity to the dash cam for a stable Wi-Fi connection.
• Видеонун сапаты начар:
  • Камера линзасын тазалаңыз.
  • Ensure the protective film (if any) has been removed from the lens.
  • Check the video resolution settings in the dash cam's menu or the Ring Connect app.
• Dash Cam Freezes/Unresponsive:
  • Күйгүзүүнү мажбурлап баштоо үчүн кубат баскычын басып, кармап туруңуз.
  • If a reset button is available (refer to quick start guide), use a thin object to press it.

If these steps do not resolve the issue, please refer to the official Ring Automotive support resources or contact customer service.

8. Техникалык шарттар

9. Кепилдик жана колдоо

For warranty information, please refer to the documentation provided with your product or visit the official Ring Automotive website. Information regarding spare parts availability and guaranteed software updates is not directly available in this manual.

For technical support, troubleshooting assistance beyond this manual, or inquiries about spare parts and software updates, please contact Ring Automotive customer service directly. You can typically find contact details on their official webсайтында же продуктунун тез баштоо колдонмосунда.

Ring Automotive Official Webсайт: www.ringautomotive.com
