Smart WiFi сенсордук которгуч колдонуучусунун колдонмосу

1. Киришүү

This manual provides comprehensive instructions for the safe installation, configuration, operation, and maintenance of your Smart WiFi Touch Switch. Please read this manual thoroughly before installation and keep it for future reference.

The Smart WiFi Touch Switch is an advanced wall switch designed for modern smart homes. It allows you to control your lighting or other household appliances remotely via a mobile application, voice commands, or directly through its high-sensitivity touch panel.

2. Продукциянын өзгөчөлүктөрү

• Зымсыз туташуу: Connects to your local 2.4G WiFi router without the need for a central control host.
• High-Sensitivity Touch Panel: Features a tempered glass panel with high-sensitivity touch keys, resistant to water and shock.
• Туруктуу курулуш: The bottom casing is made of ABS V0 flame-retardant material for enhanced safety.
• Wide Voltage киргизүү: Supports an ultra-wide voltag90V-250V диапазону.
• Үн менен башкаруу шайкештиги: Works seamlessly with Amazon Alexa, Google Home, and SIRI for convenient voice commands.
• Мобилдик колдонмону башкаруу: Control your lights and appliances remotely from anywhere, anytime, with real-time status updates.
• LED арткы жарык: The remote wall switch features an LED backlight for easy visibility and operation at night.
• Таймер функциясы: Set schedules and countdown timers for automated control of your devices.
• Көп тилдүү колдоо: The accompanying mobile application supports 22 languages globally.

Сүрөт 2.1: Алдыңкы view of the Smart WiFi Touch Switch, showcasing its sleek black tempered glass panel with a blue WiFi indicator and a central blue circular touch button.

3. Коопсуздук маалыматы

Сураныч, жаракаттарды же аппаратты бузууну болтурбоо үчүн төмөнкү коопсуздук чараларын сактаңыз:

• Электр коопсуздугу: Always disconnect power at the circuit breaker before installing, removing, or servicing the switch. Failure to do so may result in electric shock or death.
• Квалификациялуу электрик: Installation should be performed by a qualified electrician or a person with a thorough understanding of electrical wiring.
• Үй ичинде гана колдонуу: This device is designed for indoor use in dry locations only.
• Тtage Шайкештик: Ensure your electrical system's voltage matches the switch's supported range (90V-250V).
• Туура зымдар: Ensure correct connection of live (L) and neutral (N) wires, as well as load wires (L1, L2, L3) as per the wiring diagram. Connecting the live wire and zero wire is crucial for safer operation.
• Сертификаттар: The product is FCC, CE, and RoHS certified, ensuring compliance with safety and environmental standards.

4. Пакеттин мазмуну

Пакетте бардык буюмдар бар экенин текшериңиз:

• Smart WiFi Touch Switch (1 unit)
• Монтаждоо бурамдары (2 даана)
• Колдонуучунун колдонмосу (1 нуска)

5. Орнотуу

5.1 Баштоодон мурун

• Turn off power at the circuit breaker for the switch location.
• Ensure you have identified the Live (L), Neutral (N), and Load (L1, L2, L3) wires from your existing wiring.

5.2 Электр өткөргүч схемасы

5.1-сүрөт: Арткы view of the Smart WiFi Touch Switch with wiring terminals. N for Neutral, L for Live, and L1, L2, L3 for load connections.

5.3 Орнотуу кадамдары

1. Кубатты өчүрүү: At your home's main circuit breaker, turn off the power to the switch you are replacing.
2. Эски которгучту алып салуу: Carefully remove the faceplate and unscrew the old switch from the wall box. Disconnect the wires, noting which wire was connected to which terminal.
3. Зымдарды туташтыруу: Connect the wires from your wall box to the corresponding terminals on the Smart WiFi Touch Switch as shown in Figure 5.1. Ensure secure connections.
   • Нейтралдуу зымды 'N' терминалына туташтырыңыз.
   • Live зымды "L" терминалына туташтырыңыз.
   • Connect the Load wires (to your lights/appliances) to the 'L1', 'L2', 'L3' terminals as needed.
4. Которгучту орнотуу: Gently push the wired switch into the wall box and secure it with the provided mounting screws.
5. Faceplate тиркөө: Snap or screw the new faceplate onto the switch.
6. Күчтү калыбына келтирүү: Turn the power back on at the circuit breaker. The switch's LED backlight should illuminate.

6. Setup (App & Network)

6.1 Колдонмону жүктөп алыңыз

Издөө the recommended smart home application (e.g., Smart Life, Tuya Smart) on your smartphone's app store (iOS or Android) and install it.

6.2 Жупташтыруу процесси

1. Ensure your smartphone is connected to a 2.4GHz WiFi network. The switch does not support 5GHz networks.
2. Open the installed smart home app and register or log in to your account.
3. Follow the in-app instructions to add a new device. This typically involves selecting 'Electrical Switch' or 'Wall Switch'.
4. The app will guide you through putting the switch into pairing mode (often by pressing and holding the touch button until the WiFi indicator blinks rapidly).
5. Confirm the WiFi network and enter your WiFi password in the app.
6. Wait for the app to discover and connect to the switch. Once connected, you can rename the switch and assign it to a room.

Figure 6.1: ашыкview of smart switch functionalities including app control, voice control, and scheduling.

7. Иштөө нускамалары

7.1 Сенсордук башкаруу

Simply touch the central circular button on the switch panel to manually turn the connected lights or appliances ON or OFF. The LED backlight will indicate the current status.

7.2 Колдонмону башкаруу

Use the installed smart home application on your smartphone to control the switch remotely. The app allows you to:

• Turn lights/appliances ON/OFF from anywhere with an internet connection.
• View the real-time ON/OFF status of your devices.
• Set schedules and countdown timers for automated operation.
• Create smart scenes and automations with other smart devices.

Figure 7.1: Setting a timer for the smart switch using the mobile application.

7.3 Үн менен башкаруу

After linking your smart home app account with Amazon Alexa, Google Home, or SIRI (via Apple HomeKit if supported by the app), you can control the switch using voice commands. Examples:

• – Alexa, бөлмөнүн жарыгын күйгүз.
• "Hey Google, turn off the kitchen switch."
• "SIRI, turn on the bedroom lamp."

Figure 7.2: Smart switch integration with voice assistant devices like Amazon Echo.

8. Техникалык тейлөө

• Тазалоо: To clean the switch panel, gently wipe it with a soft, dry, lint-free cloth. Do not use abrasive cleaners, solvents, or harsh chemicals.
• Колдонуучунун тейлөөчү тетиктери жок: The Smart WiFi Touch Switch contains no user-serviceable parts. Do not attempt to disassemble or repair the device yourself. Refer all servicing to qualified personnel.
• Экологиялык шарттар: Коммутаторду өтө жогорку температурага, нымдуулукка же түз күн нуруна дуушар кылбаңыз.

9. Кыйынчылыктарды

10. Техникалык шарттар

Figure 10.1: Dimensions of the Smart WiFi Touch Switch.

11. Кепилдик жана колдоо

Warranty information for this product is not explicitly provided in the available product details. For specific warranty terms and conditions, please refer to the documentation included with your purchase or contact your retailer.

For technical support, troubleshooting assistance, or inquiries regarding spare parts, please contact the retailer from whom you purchased the product or the manufacturer directly. Please have your product model number (01rhx5gwk0zf5881-01) and purchase details ready when contacting support.
