Candy Smart CSE V8LF-S кир жуугуч машинанын колдонуучу нускамасы

1. Киришүү

Thank you for choosing the Candy Smart CSE V8LF-S Tumble Dryer. This manual provides essential information for the safe and efficient use, installation, and maintenance of your appliance. Please read these instructions carefully before using the tumble dryer and keep them for future reference.

2. Коопсуздук маалыматы

• Электр коопсуздугу: Ensure the appliance is connected to a properly earthed socket. Do not use adapters or extension cords. Disconnect from the power supply before cleaning or maintenance.
• Вентиляция: This is a vented tumble dryer. Ensure adequate ventilation in the room to prevent the backflow of gases from appliances burning other fuels. The exhaust hose must be unobstructed.
• Балдар жана аялуу адамдар: Бул шайманды 8 жаштан жогорку балдар жана физикалык, сезүү же акыл-эс жөндөмү начар же тажрыйбасы жана билими жок адамдар, эгерде аларга көзөмөлдүк же көрсөтмө берилген болсо, колдонсо болот.
• Күйүүчү материалдар: Do not dry items that have been soiled with flammable substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes, or wax removers.
• Орнотуу: The appliance must be installed by a qualified person. Do not install the dryer behind a lockable door, a sliding door, or a door with a hinge on the opposite side to that of the tumble dryer, in such a way that a full opening of the tumble dryer door is restricted.

3. Продукт бүтүп калдыview

The Candy Smart CSE V8LF-S is an 8 kg capacity vented tumble dryer designed for efficient clothes drying. It features a digital display, a program selection knob, and NFC technology for enhanced control.

Фронт view of the Candy Smart CSE V8LF-S vented tumble dryer, showing the control panel, door, and overall design.

Жакын план view of the tumble dryer's stainless steel drum interior, featuring perforations for airflow during the drying process.

4. Орнотуу жана орнотуу

4.1 Пакеттен чыгаруу

Remove all packaging materials. Check the appliance for any transport damage. Report any damage to your retailer immediately.

4.2 Орнотуу

Place the dryer on a firm, level floor. Ensure there is sufficient space around the appliance for proper ventilation. The dryer can be installed in a column above a washing machine using a suitable stacking kit (sold separately).

Diagram illustrating the external dimensions of the Candy Smart CSE V8LF-S tumble dryer: 85 cm height, 59.6 cm width, and 58.5 cm depth.

4.3 Вентиляция

Connect the exhaust hose to the rear of the dryer and lead it to an external vent. Ensure the hose is not kinked or obstructed to allow free airflow.

4.4 Электрдик туташуу

Connect the power plug to a suitable earthed electrical outlet (230 Volts). Ensure the voltage жана жыштык шаймандын техникалык тактасындагы спецификацияларга дал келет.

5. Иштөө нускамалары

5.1 Кирди жүктөө

Open the dryer door and load laundry into the drum. Do not overload the dryer; ensure clothes can tumble freely. Close the door firmly.

5.2 Программаны тандоо

Turn the program selection knob to choose one of the 14 available drying cycles. The digital display will show the estimated drying time. Refer to the appliance's control panel for specific program details.

5.3 NFC Technology (Smart Touch)

This dryer is equipped with NFC technology, allowing you to interact with the appliance via a compatible smartphone. Download the Candy simply-Fi app to access additional programs, monitor cycles, and perform diagnostics. To use, activate NFC on your smartphone and place it near the 'Smart Touch' logo on the control panel.

5.4 Кечигип баштоо

Press the 'Delayed Start' button to postpone the start of the drying cycle by 3, 6, or 9 hours. This feature allows you to run the dryer at a more convenient time.

5.5 Баштоо жана токтотуу

Press the 'Start/Pause' button to begin the selected program. To pause a cycle, press the button again. To cancel a program, turn the program knob to the 'Off' position.

6. Техникалык тейлөө

6.1 Линт чыпкасын тазалоо

The lint filter must be cleaned after every drying cycle to maintain drying efficiency and prevent fire hazards. The filter is located inside the door opening.

1. Кургаткычтын эшигин ачыңыз.
2. Pull the filter upwards to remove it.
3. Топтолгон түктөрдү кол менен же жумшак щетка менен алып салыңыз.
4. Фильтрди кайра өз ордуна бекем орнотуңуз.

An image demonstrating the removal of the lint filter from the tumble dryer's door opening, essential for maintenance.

6.2 Сырты тазалоо

Кургаткычтын сырткы беттерин жумшак, г менен сүртүңүзamp кездеме. Абразивдүү тазалагычтарды же эриткичтерди колдонбоңуз.

7. Кыйынчылыктарды

• Кургаткыч иштебей жатат: Check if the power plug is inserted correctly, the door is fully closed, and a program has been selected. Ensure the 'Start/Pause' button has been pressed.
• Кийимдердин туура кургабай калышы: Ensure the lint filter is clean. Check if the exhaust hose is clear and not kinked. Avoid overloading the dryer. Select an appropriate drying program for the fabric type.
• адаттан тыш үндөр: Small items may be caught in the drum. Check for foreign objects. If the noise persists, contact customer support.
• NFC connection issues: Ensure your smartphone's NFC is active and positioned correctly over the 'Smart Touch' logo. Check the Candy simply-Fi app for troubleshooting tips.

For more complex issues, refer to the detailed troubleshooting section in the full manual available online or contact customer support.

8. Техникалык шарттар

The official EU energy label for the Candy Smart CSE V8LF-S tumble dryer, indicating its energy efficiency class (C), annual energy consumption (321 kWh/100 cycles), noise level (67 dB), and capacity (8.0 kg). A QR code is visible for more information. For detailed energy information, visit: EPREL маалымат базасы

9. Кепилдик жана колдоо

Your Candy Smart CSE V8LF-S Tumble Dryer comes with a standard manufacturer's warranty. Please retain your proof of purchase for warranty claims.

Кардарларды колдоо Байланыш маалыматы:

• Электрондук почта: eprel_info@haier-europe.com
• Телефон: +3903920861
• Корпоративдик Webсайт: https://corporate.haier-europe.com/
• Кызмат Webсайт: https://go.he.services/service.hwd-candy
• Колдонмолор Webсайт: https://manuals.he.services/
