1. Киришүү
Thank you for choosing the Karinear 2-Burner Ceramic Glass Cooktop. This appliance is designed for efficient and safe cooking, featuring a sleek black crystal surface and intuitive knob controls. With a total power output of 3000W, it offers two independent heating zones to meet your culinary needs. This manual provides essential information for safe installation, operation, maintenance, and troubleshooting to ensure optimal performance and longevity of your cooktop.
Figure 1: Karinear 2-Burner Ceramic Glass Cooktop
Жогортон ылдый view of the Karinear 2-burner ceramic glass cooktop, showcasing its sleek black surface and two heating zones with control knobs.
2. Коопсуздук маалыматы
Сураныч, шайманды колдонуудан мурун бардык коопсуздук нускамаларын кылдат окуп чыгыңыз. Бул нускамаларды аткарбоо электр шокуна, өрткө же олуттуу жаракатка алып келиши мүмкүн.
- Электр коопсуздугу: Ensure the cooktop is installed by a qualified electrician in accordance with local electrical codes. Do not use if the power cord or plug is damaged.
- Ысык беттик эскертүү: The ceramic surface and cooking zones will remain hot after use. The cooktop features a residual heat warning ("H") to indicate hot surfaces. Avoid touching hot surfaces.
- Балдар жана үй жаныбарлары: Плитада иштеп жатканда жана ал муздап жатканда балдарды жана үй жаныбарларын андан алыс кармаңыз.
- Күйүүчү материалдар: Do not store flammable materials (e.g., aerosols, cleaning products) near the cooktop.
- Вентиляция: Иштеп жатканда плитанын айланасында жетиштүү желдетүүнү камсыз кылыңыз.
- Автоматтык түрдө өчүрүү: The cooktop is equipped with an automatic shut-off feature for enhanced safety.
3. Продукциянын компоненттери
The Karinear 2-Burner Ceramic Glass Cooktop consists of the following main components:
- Керамикалык айнек бети: Негизги бышыруу бети, бышык жана тазалоо оңой.
- Heating Zones (2): Two independent electric heating zones. The far zone is 1800W (200mm) and the near zone is 1200W (165mm).
- Control Knobs (2): Electronic rotary knobs for adjusting power levels for each burner.
- Санариптик дисплей: Shows the selected power level and residual heat warning.
Figure 2: Two Powerful Burners
An illustration highlighting the two powerful heating zones of the cooktop, indicating their positions.
Figure 3: Electronic Knob Control
Жакын план view of the electronic knob controls, showing the clear markings for power levels and the simple, intuitive design.
4. Орнотуу
The Karinear cooktop is designed for built-in installation. It requires a 220-240V hard-wired connection and does not come with an outlet plug. Professional installation is highly recommended.
4.1 Кесүү өлчөмдөрү
Ensure your countertop cutout matches the following dimensions for proper fit:
- Продукттун жалпы өлчөмдөрү: 520mm (20.5in) x 290mm (11.4in) x 54mm (2.1in) (Depth)
- Recommended Cutout Dimensions: 490 мм (19.3 дюйм) x 270 мм (10.6 дюйм)
Figure 4: Built-in Dimensions Diagram
A diagram illustrating the built-in dimensions of the cooktop, showing the overall size and the required cutout dimensions for installation. It also indicates the power of each burner: 1800W and 1200W.
4.2 Электрдик туташуу
The cooktop requires a direct electrical connection. Refer to the wiring diagram provided in the installation video for correct connection of the 3-wire cable from your home power supply (20A 240V~) to the cooktop's wires (black, blue, copper ground, yellow/green ground, brown, red wires).
Video 1: Installation and Cookware Demonstration
This video showcases the versatility of the Karinear 2-burner ceramic cooktop, demonstrating its use with various types of cookware and highlighting its easy-to-clean surface. It also briefly shows the built-in installation process and wiring.
5. Операция
Operating your Karinear ceramic cooktop is straightforward with its intuitive knob controls.
5.1 Turning On/Off and Adjusting Power
- To turn on a burner, rotate the corresponding knob clockwise from the "0" position.
- Select your desired power level from 1 (low) to 9 (high) by continuing to rotate the knob. The digital display will show the selected level.
- To turn off a burner, rotate the knob counter-clockwise back to the "0" position.
5.2 Residual Heat Warning ("H")
After turning off a burner, the digital display may show an "H" (for Hot). This indicates that the cooking zone is still hot and caution should be exercised. The "H" will disappear once the surface has cooled down to a safe temperature.
Video 2: Cooktop Operation Overview
This video demonstrates the basic operation of the Karinear 2-burner ceramic cooktop, including turning on the burners, adjusting heat levels with the knobs, and the residual heat warning indicator.
6. Идиштин шайкештиги
The Karinear ceramic cooktop is compatible with a wide variety of cookware materials. Ensure the bottom of your cookware is flat and makes full contact with the heating zone for optimal performance.
Шайкеш келген ашкана идиштери:
- Iron pots and pans
- Алюминий казандар жана көмөч казандар
- Керамикалык идиштер жана көмөч казандар
- Stainless steel pots and pans
- Айнек идиш
- Эмаль капталган чоюн
- Iron woks
Figure 5: Cookware Compatibility
An image illustrating the wide range of cookware materials that can be safely used on the Karinear ceramic cooktop.
7. Тазалоо жана тейлөө
Regular cleaning and maintenance will help keep your cooktop in excellent condition and prolong its lifespan.
- Күнүмдүк тазалоо: After each use, allow the cooktop to cool down completely. Wipe the ceramic glass surface with a damp cloth and mild dish soap. Dry thoroughly with a clean cloth.
- Кежир тактар: For stubborn food residues or burnt-on spills, use a ceramic cooktop cleaner and the provided scraper. Hold the scraper at a shallow angle to avoid scratching the surface.
- Абразивтерден качыңыз: Do not use abrasive cleaners, scouring pads, or harsh chemicals, as these can damage the ceramic glass surface.
- Башкаруу баскычтары: The control knobs can be removed for cleaning. Wipe them with a damp cloth and ensure they are dry before reattaching.
6-сүрөт: Тазалоо оңой болгон бет
A hand wearing a yellow glove wiping the ceramic cooktop surface, demonstrating the ease of cleaning. The image also shows a scraper, indicating it's included for cleaning stubborn stains.
8. Кыйынчылыктарды
If you encounter any issues with your cooktop, please refer to the following table for common problems and their solutions before contacting customer support.
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Ашкана күйбөйт. | No power supply; loose wiring; circuit breaker tripped. | Check power connection; ensure wiring is secure (professional check recommended); reset circuit breaker. |
| Отун ысыбайт. | Knob not set to a power level; incorrect cookware. | Rotate knob to a power level (1-9); ensure cookware is compatible and flat-bottomed. |
| "H" displayed after turning off. | Калган жылуулук. | This is normal. The surface is still hot. Wait for it to cool down. |
| Биринчи колдонууда адаттан тыш жыттар. | Коргоочу катмар күйүп кетти. | This is normal for initial use. Ensure good ventilation. Odor will dissipate. |
9. Техникалык шарттар
| Өзгөчөлүк | Деталь |
|---|---|
| Бренд | Каринеар |
| Модель номери | Kari-DE-KNC-D23002 |
| Продукциянын өлчөмдөрү | 52P x 29l x 4.4H см (20.5 x 11.4 x 2.1 дюйм) |
| Салмагы | 5.72 кг (12.6 фунт) |
| Power Source | Corded Electric (Hard-wired) |
| Тtage | 220-240V |
| Жалпы кубаттуулук | 3000 Вт |
| Күйгүчтөрдүн саны | 2 |
| Күйүүчү түрү | Керамикалык |
| Burner Power (Far) | 1800W / 200mm |
| Burner Power (Near) | 1200W / 165mm |
| Беттик материал | Керамикалык айнек |
| Өзгөчө өзгөчөлүк | Automatic Shut-off, Residual Heat Indicator |
| Башкаруу түрү | Башкаруу баскычы |
| Келип чыккан өлкө | Кытай |
10. Кепилдик жана колдоо
Karinear products are manufactured to high-quality standards. For warranty information, returns, or technical support, please refer to the documentation included with your purchase or visit the official Karinear website. If you have received a defective or damaged product, please contact your retailer or Karinear customer service directly.
For further assistance, you may visit the Karinear store on Amazon: Karinear Appliances Store
