1. Киришүү
This manual provides detailed instructions for the installation, operation, and maintenance of your Hubble Nursery Pal Link Premium Twin 5-Inch Baby Monitor. This system includes a 5-inch parent unit and two smart cameras, designed to help you monitor your child. Please read this manual thoroughly before using the product to ensure proper function and safety.

Сүрөт 1.1: Бүттүview of the Hubble Nursery Pal Link Premium Twin system, showing the parent unit, two cameras, and the HubbleClub app on a smartphone.
2. Коопсуздук боюнча маанилүү маалымат
Please observe the following safety precautions to reduce the risk of fire, electric shock, or injury:
- кичинекей бөлүктөрүн балдардан алыс кармаңыз.
- Do not place the camera or cords within reach of children. Cords can pose a strangulation hazard.
- Берилген кубат адаптерлерин гана колдонуңуз.
- Продукцияны сууга же нымга тийгизбеңиз.
- Ensure proper ventilation for all components.
- Do not attempt to open or repair the product yourself. Refer all servicing to qualified personnel.
3. Пакеттин мазмуну
Пакетиңизде бардык буюмдар бар экенин текшериңиз:

Image 3.1: Visual representation of the package contents.
- 5-inch Parent Unit with Split Screen capability
- Digital Pan, Tilt, and Zoom Cameras (x2)
- Power Adapters (for Parent Unit and Cameras)
- Quick Start Guide
- HubbleClub Services Information
4. Орнотуу колдонмосу
4.1 Ата-эне блогун заряддоо
Before initial use, fully charge the parent unit for approximately 16 hours. Connect the small plug of the power adapter to the parent unit and the other end to a power outlet. The battery indicator will show charging status.
4.2 Positioning the Cameras
Place the cameras on a flat surface or mount them to a wall. Ensure the camera is at least 3 feet (1 meter) away from your child to avoid potential hazards. Position the cameras to provide a clear view of the monitoring area.

Image 4.1: The parent unit and a single camera, illustrating their compact design.
4.3 Connecting to Wi-Fi and HubbleClub App
Алыскы үчүн viewing and advanced features, download the HubbleClub app on your smartphone or tablet. Follow the in-app instructions to connect your cameras to your home Wi-Fi network. This enables features such as 24-hour recording, live streaming, and remote access.

Image 4.2: The HubbleClub app interface on a smartphone, demonstrating its capabilities for monitoring and managing multiple cameras.
5. Иштөө нускамалары
5.1 Parent Unit Functions
The 5-inch diagonal color screen on the parent unit allows for direct monitoring. Use the controls to:
- View live video feed from one or both cameras (split screen).
- Utilize two-way communication to speak to your child.
- Play preloaded lullabies and soothing sounds.
- Adjust camera pan, tilt, and zoom remotely.

Image 5.1: The parent unit displaying a split screen, allowing simultaneous viewing of two camera feeds.
5.2 HubbleClub колдонмосунун өзгөчөлүктөрү
The HubbleClub app enhances your monitoring experience with additional functionalities:
- Live Streaming & Remote Access: View camera feeds from anywhere via your smart device.
- 24-Hour Recording: Continuous recording for review (subscription may be required).
- Routine Management: Schedule and manage routines for sleep and other activities.
- Baby Growth & Development Tracker: Monitor your child's progress.
- Экологиялык мониторинг: Кыймыл, үн жана температуранын өзгөрүшү жөнүндө эскертмелерди алыңыз.
- Эксперттик кеңеш: Access parenting tips and sleep advice.

Image 5.2: Key features of the monitor system, including environmental monitoring and communication capabilities.
5.3 Аралыгы жана батареянын иштөө мөөнөтү
The parent unit offers an impressive range of up to 1,000 feet (300 meters) in optimal conditions. The 3,000mAh battery provides up to 15 hours of operation on a single charge, depending on usage.

Image 5.3: The parent unit in a home setting, emphasizing its long battery life and extended range.
6. Техникалык тейлөө
To ensure the longevity and optimal performance of your baby monitor:
- Тазалоо: Wipe the parent unit and cameras with a soft, dry, lint-free cloth. Do not use cleaning sprays or liquid cleaners.
- Сактагыч: If storing the unit for an extended period, ensure the parent unit battery is fully charged and then store in a cool, dry place.
- Батареяга кам көрүү: Avoid fully discharging the parent unit battery frequently to prolong its lifespan.
7. Кыйынчылыктарды
If you encounter issues with your Hubble Nursery Pal Link Premium Twin, refer to the following common solutions:
| Көйгөй | Чечим |
|---|---|
| Ата-эне бөлүмүндө сүрөт/үн жок. | Ensure both the parent unit and cameras are powered on and within range. Check power connections. |
| Сүрөттүн сапаты начар. | Check for obstructions between the camera and parent unit. Ensure cameras are in a well-lit area or night vision is active. Adjust camera position. |
| Parent unit not connecting to Wi-Fi. | Verify your Wi-Fi network is 2.4GHz. Ensure correct Wi-Fi password. Restart your router and the parent unit. |
| Батареянын иштөө мөөнөтү кыска. | Reduce screen brightness. Limit continuous live viewing. Ensure the unit is fully charged before use. |
| App not receiving notifications. | Check app notification settings on your smartphone. Ensure the app has necessary permissions. Verify internet connectivity. |
8. Продукттун спецификациялары
| Өзгөчөлүк | Деталь |
|---|---|
| Модель номери | HCSNPLP2-2 |
| Ата-эне бирдигинин дисплейи | 5 дюймдук диагоналдык түстүү экран |
| Камера түрү | Digital Pan, Tilt, Zoom (x2) |
| Байланыш | Wi-Fi (2.4 ГГц) |
| Видео тартуунун резолюциясы | 1080p |
| Зымсыз диапазон | 1,000 футка чейин (көрүү сызыгы) |
| Ата-эне блогунун батареясы | 3000 mAh Lithium Ion (up to 15 hours) |
| Өзгөчөлүктөр | Two-way communication, Lullabies, Night Vision, Room Temperature Monitoring, Motion/Sound Detection |
| Монтаж түрү | Дубалга орнотуу |
| Элемент Салмагы | 1.96 фунт (0.89 килограмм) |
| UPC | 697333826898, 697333826928 |
9. Кепилдик жана колдоо
For warranty information and technical support, please refer to the warranty card included in your product packaging or visit the official Hubble Connected website. You can also find frequently asked questions and contact information for customer service there.
Hubble Connected Official Webсайт: www.hubbleconnected.com
