ANCEL HD3300 Plus оор жүк ташуучу унаа сканеринин колдонуучу колдонмосу

1. Киришүү

The ANCEL HD3300 Plus is a professional heavy-duty truck diagnostic tool designed to provide comprehensive system diagnostics and special functions for a wide range of diesel vehicles. This manual provides detailed instructions on how to set up, operate, maintain, and troubleshoot your device to ensure optimal performance and accurate vehicle analysis.

2. Продукт бүтүп калдыview

2.1. Аппараттын компоненттери

Сүрөт: алдыңкы view of the ANCEL HD3300 Plus diagnostic tool, showing its touchscreen display and various function icons.

2.2. Кутуда эмне бар

Image: Contents of the ANCEL HD3300 Plus package, including the main unit, cables, and user manual.

• 1x ANCEL HD3300 Plus Heavy Duty Truck Scanner
• 1x 6/9-PIN Diesel OBD Cable
• 1x 2M Main Test Line with OBD2 Connector
• 1x CAT-9 Connector
• 1x Колдонуучунун колдонмосу

For a visual guide on the packing list, please watch the video below:

Видео: деталдаштырылган кутудан чыгаруу жана андан ашыкview of the ANCEL HD3300 Plus package contents.

2.3. Негизги өзгөчөлүктөрү

• Professional DPF Regen Tool: Supports OEM-level DPF functions for Cummins, Detroit, Caterpillar, International, Volvo, Paccar, Isuzu, Fuso, including DPF regeneration, DPF reset, BlueTec, and more.
• Advanced Oil Light Reset Function: Provides OEM-level oil reset for ISUZU & FUSO, helping to reset the Oil Life Reminder.
• All System Diagnostic: Supports comprehensive scans of heavy-duty trucks compliant with standard HD OBD protocols (Engine, ABS/EBS, Transmission, Body Controller, Chassis Controller, Instrument Panel System, Cruise Control, Gateway, etc.).
• Standard Diesel OBD & OBDII Protocols: Compatible with the latest J27145 HD OBD protocols for 12V & 24V heavy-duty trucks (Cummins, Caterpillar, Detroit, Volvo, International) and standard OBDII protocols for mainstream cars and light vehicles (post-1996).
• Full OBD Level Diagnosis: A 2-in-1 platform integrating 24V heavy-duty truck scanner and 12V car scanner, with 6-pin, 9-pin, and 16-pin adapters. Performs engine diagnostics, reads/erases trouble codes, turns off MIL, shows live data, and vehicle identification info.
• Additional User-Friendly Functions: Includes one-click screenshot, one-click update, one-click printing, one-click feedback, and test report creation/emailing.
• Simulation & DEMO Mode: Offers a demonstration mode for understanding diagnostic procedures and result interfaces without vehicle connection.
• Pin Detect: Automatically measures voltage of the OBD diagnostic interface to check CAN Voltage and detect damaged pins, ensuring proper working condition.

Генерал үчүнview of the device's capabilities, please watch the video below:

Видео: Бүттүview of the ANCEL HD3300 heavy-duty truck diagnostic tool's features and functionalities.

3. Орнотуу жана активдештирүү

3.1. Аппаратты туташтыруу

The HD3300 Plus comes with various connectors (6-pin, 9-pin, 16-pin, CAT-9) to ensure compatibility with different heavy-duty vehicles. Connect the appropriate diagnostic cable to the device and then to your vehicle's OBD port. Ensure the connection is secure.

Сүрөт: Арткы view of the ANCEL HD3300 Plus, displaying the model number and serial information.

3.2. Аппаратты активдештирүү

Before using the device for the first time, it needs to be activated. This process typically requires a Wi-Fi connection.

1. Connect the HD3300 Plus to your vehicle's diagnostic port using the appropriate cable.
2. On the device, navigate to Орнотуулар.
3. Тандоо Wi-Fi and turn it on. Connect to an available Wi-Fi network. If no network is available, you can create a mobile hotspot from your phone.
4. кайтуу Орнотуулар жана тандаңыз Колдонуучу.
5. Click Иштетүү. The device will attempt to activate.
6. Once activated, a success message will appear.

For a step-by-step guide on activating your device, please watch the video below:

Video: Instructions on how to activate the ANCEL HD3300 Plus, including connecting to Wi-Fi and completing the activation process.

4. Негизги операциялар

4.1. All System Diagnostic

The HD3300 Plus can perform a full system diagnostic scan on compatible heavy-duty trucks, covering various modules like Engine, ABS/EBS, Transmission, and more. This allows for deep analysis and identification of issues across the vehicle's electronic systems.

Image: Diagram illustrating the various systems covered by the ANCEL HD3300 Plus's full system diagnostic capabilities.

To learn how to perform an all-system diagnostic, watch the video below:

Video: Demonstrates how to use the HD3300 Plus for comprehensive all-system diagnostics on a truck.

4.2. Окуу жана Эрasing Fault Codes

The device can read current, pending, and history fault codes from various vehicle systems. After identifying and addressing the underlying issues, you can use the tool to erase the fault codes and turn off the Malfunction Indicator Lamp (МИЛ).

Image: Illustrates the process of reading and erasing fault codes using the HD3300 Plus.

4.3. Түз эфирдеги маалымат агымы

View real-time data from multiple sensors in both graphical and text formats. This feature is crucial for monitoring vehicle performance and diagnosing intermittent issues.

Image: Screenshot of the HD3300 Plus display showing live data stream in graphical format.

5. Атайын функциялар

5.1. DPF Regeneration

The DPF (Diesel Particulate Filter) regeneration function helps clear accumulated soot from the filter, restoring engine performance and preventing costly repairs. The HD3300 Plus supports OEM-level DPF functions for various engine brands.

Image: Diagram explaining the DPF regeneration process and its benefits for diesel engines.

Image: Visual representation of various diesel engine brands supported for DPF functions by the HD3300 Plus.

For detailed steps on performing DPF regeneration, please refer to the video below:

Video: A demonstration of how to use the HD3300 Plus to perform DPF regeneration.

5.2. Oil Light Reset

The oil light reset function allows you to reset the oil life reminder after an oil change, ensuring accurate maintenance intervals for ISUZU and FUSO vehicles.

Image: Illustrates the benefits of the enhanced service reset and oil reset functions, showing engines supported.

6. Техникалык тейлөө жана жаңыртуулар

6.1. Программалык камсыздоону жаңыртуу

Keep your HD3300 Plus up-to-date with the latest software and vehicle database versions through convenient one-click Wi-Fi updates. This ensures compatibility with new vehicle models and improved functionality.

Image: Shows the personalized settings menu, including options for updates, feedback, printing, and screenshots.

For instructions on how to update the HD3300 Plus, please watch the video below:

Video: A short demonstration on how to update the software of the HD3300 Plus.

6.2. Башка функциялар

• One-click Screenshot: Capture diagnostic results or any screen for future reference.
• One-click Printing: Print diagnostic reports directly from the device (requires compatible printer setup).
• One-click Feedback: Send feedback or report issues directly to ANCEL support.
• Test Report by Email: Generate and send diagnostic reports via email for easy sharing and record-keeping.

7. Кыйынчылыктарды

If you encounter issues with your ANCEL HD3300 Plus, refer to the following common troubleshooting tips:

• Activation Failed / Network Issues: Ensure your Wi-Fi connection is stable and strong. If activation still fails, verify the serial number and contact customer support.
• Байланыш катасы: Check all cable connections (6-pin, 9-pin, 16-pin, CAT-9) to ensure they are secure and correctly matched to the vehicle's port. Verify the vehicle's ignition is on. For HD OBD protocols, ensure the vehicle supports SAE J1939 and SAE J1708 standards. Try accessing the OBDII menu for testing if issues persist.
• Коддорду тазалоо мүмкүн эмес: Ensure the vehicle's ignition is on and the engine is off (KOEO - Key On, Engine Off). Some codes may require specific driving cycles or repairs before they can be cleared. Verify compatibility with your vehicle model.
• Түзмөк тоңуп калат/жай иштейт: Ensure the device software is up-to-date. Clear cache or perform a factory reset if necessary (note: this will erase saved data).
• Кубат жок: Check the diagnostic cable connection to the vehicle's OBD port. Ensure the vehicle's battery has sufficient charge.

For further assistance, please contact ANCEL customer support.

8. Техникалык шарттар

9. Кепилдик жана колдоо

ANCEL is committed to providing excellent customer service and product support for the HD3300 Plus.

• 30 күндүк акысыз кайтаруу: 30 күндүк кайтаруу саясаты менен жан дүйнө тынчтыгынан ырахат алыңыз.
• 24/7 Техникалык колдоо: Access professional technical assistance around the clock.
• 2-Year Service: Benefit from comprehensive service coverage for two years.
• Өмүр бою акысыз жаңыртуу: Receive free software updates for the lifetime of the product, ensuring continued compatibility and enhanced features.

For any inquiries or support needs, please visit the official ANCEL webсайтына кириңиз же алардын кардарларды тейлөө тобуна түздөн-түз кайрылыңыз.
