Introduction
The MSA ALTAIR 2XT Two-Tox Gas Detector is a portable, robust, and easy-to-use device designed for monitoring hazardous gas levels. This model specifically detects Carbon Monoxide (CO) and Hydrogen Sulfide (H2S), providing critical safety information to users in various industrial environments. It incorporates advanced Xcell Sensor technology for reliable performance and aims to minimize total cost of ownership through its durable design and efficient operation.
This manual provides essential information for the proper setup, operation, maintenance, and troubleshooting of your ALTAIR 2XT gas detector.
Продукт өзгөчөлүктөрү
- Менчиктин төмөн наркы: Features fastest sensor response times, lowest calibration gas flow rate, an expected 4-year sensor life, and a 3-year warranty on the instrument and most sensors. This single device can monitor two gases simultaneously.
- Full-Time Traceability: Capable of recording over 300 alarm events and more than 850 hours of data, including bump and calibration records. It is compatible with the MSA GALAXY GX2 Automated Test System and MSA Link Pro software for comprehensive data management.
- Мыкты туруктуулугу: Constructed with tough over-molded rubber armor, designed to survive multiple 25-ft drops onto concrete. It boasts agency-certified dust- and water-tight IP67 construction and an intrinsically-safe design for use in hazardous locations.
- Колдонууга оңой: Designed for one-button operation, even with gloved hands. Features large LCD characters and status icons for clear readability, and a 10-second backlight with adjustable timeout. Care and use instructions are included with the device.
Компоненттер жана башкаруу элементтери
Сүрөт 1: Алдыңкы View of ALTAIR 2XT Gas Detector. This image shows the front of the device, highlighting the large LCD display, the single operational button, and the clearly labeled CO and H2S sensor areas. The display shows "24 Months", indicating remaining sensor life.
2-сүрөт: Артка View of ALTAIR 2XT Gas Detector. The back of the device features a durable belt clip for secure attachment and a product label detailing the model, serial number (00115759), manufacturing information, and various safety certifications (UL/CSA, ATEX, IECEx).
The ALTAIR 2XT is designed for simplicity. The front panel features a large, easy-to-read LCD display that shows gas concentrations, remaining sensor life, and various status icons. A single button controls all primary functions, allowing for intuitive operation even in challenging conditions. The back of the device includes a robust clip for attachment to clothing or equipment.
Жайгашуу
Батарея орнотуу
The ALTAIR 2XT requires 1 Lithium Metal battery for operation. Batteries are not included with the initial purchase. Refer to the device's battery compartment for correct polarity and installation instructions. Ensure the battery compartment is securely closed after installation to maintain the device's IP67 rating.
Баштапкы күйгүзүү
Upon first power-on or after a battery replacement, the device will perform a self-test. Follow any on-screen prompts. Ensure the device is in a fresh air environment during initial startup to allow for proper sensor zeroing.
Операция
Негизги операция
The ALTAIR 2XT is operated using a single button. Press and hold the button to power on/off the device. Short presses navigate through menus or acknowledge alarms. The large LCD display provides real-time readings of Carbon Monoxide (CO) and Hydrogen Sulfide (H2S) concentrations.
Ойготкуч шарттары
The device is equipped with an audible alarm to alert users to hazardous gas levels. Alarm thresholds are set as follows:
- Көмүртек кычкылы (CO): Low alarm at 25 ppm, High alarm at 100 ppm.
- Суутек күкүрт (H2S): Low alarm at 10 ppm, High alarm at 15 ppm.
When an alarm condition is met, the device will emit an audible alert. Acknowledge the alarm by pressing the button. Always follow your company's safety protocols when an alarm is triggered.
Арткы жарык
The display features a 10-second backlight for improved visibility in low-light conditions. The timeout duration can be adjusted through the device settings.
Техникалык тейлөө
Булп сыноо жана калибрлөө
Regular bump testing and calibration are crucial for ensuring the accuracy and reliability of your gas detector. The ALTAIR 2XT is designed for easy integration with the MSA GALAXY GX2 Automated Test System, which simplifies these routine maintenance tasks. Refer to the MSA GALAXY GX2 system manual for detailed instructions on automated testing.
Sensor Life and Replacement
The Xcell Sensors in the ALTAIR 2XT have an expected life of 4 years. The device's display will indicate the remaining sensor life in months. When sensors approach their end-of-life, they should be replaced by qualified personnel to maintain accurate readings and device functionality.
Тазалоо жана сактоо
Жарнама менен аппараттын сыртын тазалаңызamp cloth. Do not use abrasive cleaners or solvents. Store the device in a clean, dry environment within the specified operating temperature range when not in use.
Проблемаларды чечүү
This section provides general guidance for common issues. For more complex problems, refer to the full technical manual or contact MSA customer support.
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Түзмөк күйбөйт. | Өлүк же туура эмес орнотулган батарея. | Батареяны орнотууну текшерүү; зарыл болсо, батареяны алмаштыруу. |
| Inaccurate gas readings. | Sensors require calibration or are at end-of-life. | Perform a bump test or full calibration. Consider sensor replacement if readings remain inaccurate. |
| Ойготкуч үзгүлтүксүз угулат. | Presence of target gas; sensor fault. | Evacuate to fresh air if gas is present. If in fresh air, perform a bump test. If issue persists, contact support. |
Техникалык шарттар
| Атрибут | Деталь |
|---|---|
| Бренд | MSA |
| Модель номери | 10154040 |
| Стиль | CO/H2S (Carbon Monoxide / Hydrogen Sulfide) |
| Power Source | Battery Powered (1 Lithium Metal battery required) |
| Түс | БОЗ |
| Ойготкуч түрү | Укулган |
| Иштөө нымдуулугу | 95 пайыз |
| Жогорку температура рейтинги | 50 градус |
| Сенсор түрү | Электрохимиялык |
| Элемент Салмагы | 2.39 унция |
| Продукциянын өлчөмдөрү | 6 x 4 x 3 дюйм |
| Сенсордун күтүлгөн мөөнөтү | 4 жыл |
| Сертификаттар | UL/CSA, IP67 (Dust- and Water-tight), Intrinsically-Safe |
| Маалыматтарды каттоо | Records 300+ alarm events and 850+ hours of data |
Кепилдик жана колдоо
The MSA ALTAIR 2XT Gas Detector is covered by a 3-year warranty on the instrument and most sensors. For detailed warranty information, terms, and conditions, please visit the official MSA webсайт.
For technical support, service, or to inquire about replacement parts and accessories, please contact MSA customer service or visit their official webсайт:
Сиз ошондой эле көбүрөөк маалымат жана өнүмдөрдү таба аласыз MSA Store on Amazon.
Маанилүү коопсуздук маалыматы
Always operate the MSA ALTAIR 2XT Gas Detector according to the instructions provided in this manual and any additional safety documentation from MSA. This device is intrinsically safe and designed for use in hazardous locations, but proper handling and adherence to safety protocols are paramount.
Refer to the comprehensive "Reference manual for warning and cautions" (document ID: 00115759) for detailed safety guidelines, limitations, and environmental considerations. Failure to follow all instructions and warnings may result in inaccurate readings, device malfunction, personal injury, or death.
Ensure regular training for all users on the proper use and interpretation of gas detector readings and alarms.
Figure 3: Worker using the ALTAIR 2XT. This image shows a worker in protective gear with the gas detector clipped to their chest, demonstrating typical usage in an industrial setting.
Figure 4: ALTAIR 2XT in use. Башка view of a worker wearing the gas detector, emphasizing its compact and wearable design for continuous monitoring.
