1. Киришүү
Thank you for choosing the Einhell GE-CH 36/61 Li-Solo Power X-Change Cordless Hedge Trimmer. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new tool. Please read this manual thoroughly before first use and keep it for future reference.
The Einhell GE-CH 36/61 Li-Solo is designed for trimming hedges, shrubs, and bushes in domestic gardens and allotments. It is part of the Power X-Change family, utilizing two 18V lithium-ion batteries for 36V power. The tool features laser-cut and diamond-sharpened blades for precise cuts and a robust metal gearbox for durability.
2. Жалпы коопсуздук маалыматы
ЭСКЕРТҮҮ: Бул электр куралы менен берилген бардык коопсуздук эскертүүлөрүн, нускамаларды, иллюстрацияларды жана спецификацияларды окуңуз. Төмөндө саналып өткөн бардык көрсөтмөлөрдү аткарбоо электр тогуна, өрткө жана/же олуттуу жаракатка алып келиши мүмкүн.
- Always wear appropriate personal protective equipment (PPE), including safety glasses, gloves, and sturdy footwear, when operating the hedge trimmer.
- Кыймылдаткычты иштетип жатканда балдарды жана башкаларды алыс кармаңыз.
- Чач кыркуучу машинаны нымдуу же жамгырлуу аба ырайында иштетпеңиз.
- Жумушчу аймактын тоскоолдуктардан жана таштандылардан тазаланганын текшериңиз.
- Before performing any maintenance, cleaning, or storage, always remove the batteries from the tool.
- Ар бир колдонуудан мурун, хедж-триммердин бузулгандыгын текшериңиз. Бузулган болсо, колдонбоңуз.
- Hold the hedge trimmer firmly with both hands during operation.
3. Продукт бүтүп калдыview
The Einhell GE-CH 36/61 Li-Solo hedge trimmer is designed for efficient and comfortable hedge maintenance. Key features include:
- Power X-Change System: Utilizes two 18V batteries for 36V power, compatible with other Einhell Power X-Change tools.
- Жогорку сапаттагы бычактар: Laser-cut and diamond-sharpened blades with a 61 cm cutting length and 26 mm tooth spacing for clean, precise cuts.
- Robust Gearbox: Durable metal gearing ensures a long service life and up to 2,400 cuts per minute.
- Эргономикалык дизайн: Optimized battery positioning and Softgrip handles provide comfortable handling for extended use.
- Waste Collector: A practical waste collector helps remove cuttings from the top of the hedge.
- Коопсуздук өзгөчөлүктөрү: Two-hand safety switch, hand guard, aluminum blade guard, and shock protection for maximum user safety.
Figure 3.1: Einhell GE-CH 36/61 Li-Solo Cordless Hedge Trimmer, main view.
Сүрөт 3.2: Жакын пландан view of the hedge trimmer blade and the HEDGERAKER guard.
Figure 3.3: The hedge trimmer features high-quality laser-cut and diamond-sharpened blades for optimal cutting performance.
4. Орнотуу
4.1 Батареяны орнотуу
The Einhell GE-CH 36/61 Li-Solo requires two 18V Power X-Change batteries for operation. Batteries and charger are not included with the tool and must be purchased separately.
- Ensure the hedge trimmer is switched off and the safety switch is engaged.
- Locate the battery compartments on the tool handle.
- Slide fully charged 18V Power X-Change batteries into the compartments until they click securely into place.
- To remove batteries, press the release buttons on the batteries and pull them out.
Figure 4.1: Inserting an 18V Power X-Change battery into the hedge trimmer.
Figure 4.2: The hedge trimmer with both 18V Power X-Change batteries correctly installed.
Figure 4.3: Reminder that batteries and charger are sold separately.
5. Иштөө нускамалары
5.1 Иштөө алдында
- Ensure all safety guards are in place and undamaged.
- Check the blades for sharpness and any signs of damage.
- Тиешелүү коопсуздук шайманын кийиңиз.
- Clear the work area of any loose objects, wires, or debris.
5.2 Куралды иштетүү жана токтотуу
- To start: Hold the hedge trimmer firmly with both hands. Press and hold the safety switch on the front handle, then simultaneously press the ON/OFF switch on the rear handle. The blades will begin to move.
- To stop: Release either the safety switch or the ON/OFF switch. The blades will stop immediately.
5.3 Кесүү техникасы
- Горизонталдуу кесүү: For the top of hedges, hold the trimmer with the blade slightly angled (5-10 degrees) towards the hedge. Move the trimmer steadily along the top, ensuring an even cut.
- Тик кесүү: For the sides of hedges, hold the trimmer vertically and move it in an arc motion from bottom to top, or top to bottom, depending on comfort and hedge height.
- Avoid cutting branches thicker than the maximum tooth spacing (26 mm).
- Do not force the tool through thick branches; this can damage the blades or motor.
5.4 Waste Collector
The integrated waste collector helps to direct cuttings away from the top of the hedge, making cleanup easier. Ensure it is properly attached before operation.
Figure 5.1: A user demonstrating the hedge trimmer in action on a large hedge.
6. Техникалык тейлөө
Regular maintenance ensures the longevity and safe operation of your hedge trimmer.
6.1 Тазалоо
- Тазалоодон мурун ар дайым батареяларды алып салыңыз.
- Clean the blades immediately after each use to prevent sap and debris buildup. Use a stiff brush and a suitable blade cleaning spray.
- Жарнама менен корпусту сүртүңүзamp кездеме. Катуу химиялык заттарды же абразивдүү тазалагычтарды колдонбоңуз.
- Ensure all ventilation openings are clear of debris.
6.2 Blade Care and Storage
- Periodically lubricate the blades with a light machine oil or blade lubricant to reduce friction and prevent rust.
- If blades become dull or damaged, they should be sharpened by a qualified professional or replaced.
- Хедж триммерди кургак, коопсуз жерде, балдар жетпеген жерде сактаңыз.
- Always use the supplied blade sheath when storing or transporting the tool to prevent accidental injury and protect the blades.
Figure 6.1: Always use the blade cover for safe storage and transport.
Figure 6.2: The hedge trimmer can be conveniently stored on a wall mount.
7. Кыйынчылыктарды
Бул бөлүмдө сиз хедж триммериңиз менен кездешүүсү мүмкүн болгон жалпы маселелер каралат.
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Хедж триммер иштебейт. | Batteries not inserted correctly or discharged. Safety switch not engaged. | Ensure batteries are fully charged and correctly inserted. Press both safety switch and ON/OFF switch simultaneously. |
| Төмөндөтүлгөн кесүү натыйжалуулугу. | Бышактар кызыксыз же кир. | Clean blades thoroughly. If dull, have them sharpened or replaced. |
| Иш учурунда аспап токтойт. | Overload protection activated. Batteries discharged. | Reduce cutting load. Allow tool to cool down. Replace or recharge batteries. |
| Ашыкча термелүү. | Damaged blades or loose components. | Inspect blades for damage. Check for any loose screws or parts. If problem persists, contact customer support. |
8. Техникалык шарттар
Technical data for the Einhell GE-CH 36/61 Li-Solo Cordless Hedge Trimmer:
| Өзгөчөлүк | Спецификация |
|---|---|
| Модель номери | GE-CH 36/61 Li |
| Power Source | Battery-powered (2 x 18V Power X-Change) |
| Blade Length | 61 см |
| Тиш аралыгы | 26 мм |
| Мүнөтүнө кыскартуу | 2400 об/мин |
| Продукциянын өлчөмдөрү (L x W x Y) | 106 x 23.5 x 20.5 см |
| Салмагы | 2.8 кг |
| Бычактын материалы | Металл |
| Өндүрүүчү | Эйнхелл |
| Келип чыккан өлкө | Кытай |
9. Кепилдик жана колдоо
9.1 Кепилдик маалыматы
This Einhell product is covered by a manufacturer's warranty. Spare parts availability is typically guaranteed for 2 years. Please refer to the warranty card included with your purchase or visit the official Einhell webСиздин аймакка тиешелүү деталдуу кепилдик шарттары жана шарттары үчүн сайт.
9.2 Кардарларды колдоо
For technical assistance, spare parts, or warranty claims, please contact Einhell customer support. Contact details can usually be found on the Einhell webсайтында же продукт документациясында.
