Introduction
This manual provides essential information for the safe and efficient operation of your Princess Steam Aerofryer 01.182080.02.001. This innovative appliance combines the functions of an air fryer and a steam oven, allowing for a wide variety of healthy cooking methods. Please read these instructions thoroughly before first use and keep them for future reference.
Коопсуздук нускамалары
Өрт, электр шок жана жаракат алуу коркунучун азайтуу үчүн электр шаймандарын колдонууда ар дайым негизги коопсуздук чараларын сактаңыз.
- VoltagШайманда көрсөтүлгөн e сиздин жергиликтүү электр тармагына дал келетtagэ туташтыруудан мурун.
- Негизги блокту, шнурду же розеткага сууга же башка суюктуктарга батырбаңыз.
- Шайманды жана анын шнурун балдар жетпеген жерде сактаңыз.
- Эгерде сайгыч, негизги шнур же шаймандын өзү бузулса, шайманды иштетпеңиз.
- Колдонгондон кийин жана тазалоодон мурун шайманды ар дайым розеткадан сууруп коюңуз. Колдонуудан мурун толугу менен муздаганча күтүңүз.
- Surfaces become hot during use. Use oven mitts when handling hot components.
- Иштеп жатканда аба кирүүчү же чыгуучу вентиляторлорду жаппаңыз.
- Өндүрүүчү сунуштаган аксессуарларды гана колдонуңуз.
- Do not place the appliance against a wall or other appliances. Leave at least 10 cm of free space on the back and sides and 10 cm above the appliance.
Продукт бүттүview
Familiarize yourself with the components of your Princess Steam Aerofryer.
Негизги компоненттер
- Санариптик сенсордук башкаруу панели бар негизги блок
- Алынуучу аба Фритер себет
- Special Steam Rack
- Water Tank (for steam function)
Figure 1: Princess Steam Aerofryer highlighting 8 preset programs, steam technology, BPA/PFOA free, less oil cooking, and digital touch control panel.
2-сүрөт: жарылган view of the appliance, showing the main unit, the removable air fryer basket, and the special steam rack.
Өлчөмдөрү жана сыйымдуулугу
- Сыйымдуулугу: 6.5 литр
- Кубаттуулугу: 1700 Ватт
- Өлчөмдөрү (L x W x Y): 40 x 4.3 x 32 см
- Салмагы: 5.7 килограмм
Figure 3: Appliance dimensions: approximately 42.4 cm (length), 39.7 cm (height), 32 cm (width). The basket diameter is approximately 23.5 cm. Total weight is 6.4 kg, and capacity is 6.5 L.
Жайгашуу
Таңгактан чыгаруу жана баштапкы тазалоо
- Бардык таңгактоочу материалдарды жана чаптамаларды алып салыңыз.
- Негизги блоктун сыртын жарнама менен сүртүңүзamp кездеме.
- Wash the air fryer basket, steam rack, and any other removable accessories in warm soapy water or in a dishwasher. Rinse thoroughly and dry.
Жайгаштыруу
Place the appliance on a stable, heat-resistant surface, away from walls or other appliances to ensure proper ventilation. Ensure there is at least 10 cm of clear space around the unit.
Filling the Water Tank (for Steam Function)
- Locate the water tank on the appliance.
- Суу куюлган резервуарды этияттык менен алып салыңыз.
- Fill the tank with clean, distilled water up to the maximum fill line. Do not overfill.
- Reinsert the water tank securely into the appliance.
Figure 4: Filling the water tank for the steam function. Use distilled water to prevent mineral buildup.
Иштөө нускамалары
The Princess Steam Aerofryer features a digital touch screen for easy control of temperature, time, and cooking modes.
Figure 5: Visual representation of the appliance's dual functionality, combining steam cooking (left) and hot air frying (right) for versatile meal preparation.
Жалпы операция
- Plug the appliance into a grounded wall socket. The display will illuminate.
- Шайманды иштетүү үчүн Кубат баскычын басыңыз.
- Select your desired cooking mode (Air Fry or Steam) using the mode button.
- Adjust the temperature (40°C to 200°C) and time (up to 90 minutes) using the respective +/- buttons.
- Даярдоону баштоо үчүн Кубат баскычын кайра басыңыз.
Air Frying
Кытырак натыйжа алуу үчүн, май аз колдонулат.
- Тамак-ашты аба кууруучу себетке салыңыз. Ашыкча толтурбаңыз.
- Себетти негизги блокко салыңыз.
- Select Air Fry mode. Set desired temperature and time.
- Start cooking. Shake the basket halfway through for even cooking, if necessary.
6-сүрөт: Мисample of air-fried foods such as french fries and a whole chicken, demonstrating the appliance's capacity.
Буулоо
For retaining moisture, nutrients, and natural flavors.
- Суу резервуарынын толтурулганын текшериңиз.
- Place food on the special steam rack.
- Insert the rack into the main unit.
- Select Steam mode. Set desired temperature and time.
- тамак бышыруу.
Figure 7: Steaming dumplings in the appliance, showcasing the steam function.
Алдын ала орнотууларды колдонуу
The appliance comes with 8 pre-programmed settings for common dishes:
- Жашылчалар
- Эт
- Балык
- Fries
- Нан
- Паста
- Торт
- Pizza
To use a preset, select the desired program from the digital touch screen. The appliance will automatically set the optimal temperature and time. You can manually adjust these settings if needed.
Figure 8: Digital display showing icons for various preset cooking options, including chips, cake, pizza, prawns, chicken, steak, fish, and bacon.
Тазалоо жана тейлөө
Үзгүлтүксүз тазалоо оптималдуу иштешин камсыз кылат жана шайманыңыздын иштөө мөөнөтүн узартат.
Ар бир колдонуудан кийин тазалоо
- Шайманды сууруп, толугу менен муздатууга уруксат бериңиз.
- Remove the air fryer basket and steam rack. These accessories are dishwasher safe.
- Жарнама менен шаймандын ичин тазалаңызamp кездеме жана жумшак жуугуч. Абразивдүү тазалагычтарды колдонбоңуз.
- Жарнама менен сыртын сүртүңүзamp кездеме.
- Empty and clean the water tank after each use, especially when using the steam function.
Descaling (for Steam Function)
If you notice reduced steam production or mineral buildup, descale the appliance. Consult the manufacturer's website or customer support for specific descaling instructions and recommended products.
Проблемаларды чечүү
Жалпы маселелер жана алардын чечимдери үчүн бул бөлүмдү караңыз.
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Шайман күйбөйт. | розеткага кошулбаган; электр розеткасынын маселеси; прибордун бузулушу. | Check power cord connection. Try a different outlet. If still not working, contact customer support. |
| Тамак тегиз бышырылбайт. | Себет ашыкча жүктөлгөн; тамак чайкалган эмес/оодарылган эмес; температура/убакыт туура эмес. | Себетти ашыкча толтурбаңыз. Бышыруу учурунда тамакты чайкаңыз же оодарыңыз. Температураны жана убакытты зарылчылыкка жараша тууралаңыз. |
| No steam or low steam production. | Суу сактагыч бош; минералдардын топтолушу. | Refill water tank. Perform descaling procedure if mineral buildup is suspected. |
| Санариптик дисплей туура иштебей жатат. | Software glitch; internal component issue. | Unplug the appliance for a few minutes, then plug it back in. If the issue persists, contact customer support. |
Техникалык шарттар
- Бренд: Princess
- Модель номери: 01.182080.02.001
- Түсү: Кара
- Сыйымдуулугу: 6.5 литр
- Күч: 1700 Ватт
- Тtage: 230 вольт
- Материал: Алюминий, Пластик
- Температура диапазону: 40°C - 200°C
- Таймер: 90 мүнөткө чейин
- Өзгөчөлүктөр: 8 Presets, Steam Function, Dishwasher-safe parts, Adjustable thermostat and timer
- Элемент Салмагы: 5.7 килограмм
- Продукциянын өлчөмдөрү (L x W x Y): 40 x 4.3 x 32 cm (Note: Packaging/shipping dimensions may vary slightly from actual unit dimensions shown in diagrams)
Кепилдик жана колдоо
Your Princess Steam Aerofryer is covered by a manufacturer's warranty. Please refer to the warranty card included with your purchase for specific terms and conditions. For technical support, spare parts, or warranty claims, please contact Princess customer service through their official webсайтка же продуктуну сатып алган сатуучуга.
Information regarding spare parts availability is currently unavailable. Please contact customer support for assistance.
