1. Киришүү
The SONOFF THS01 is a high-accuracy temperature and humidity sensor designed to work seamlessly with SONOFF TH Elite and TH Origin smart switches. It provides precise environmental data, enabling intelligent control and monitoring of your home or specific environments.
Figure 1.1: SONOFF THS01 Temperature and Humidity Sensor with RJ9 4P4C connector.
Негизги өзгөчөлүктөрү:
- Wider Monitoring Range: Temperature measurement from -40℃ to +85℃ and humidity measurement from 0 to 100% RH.
- RJ9 4P4C Connector: Upgraded connector for stable and reliable hot-plugging.
- Easy to Use: Simple connection to TH Elite/TH Origin devices.
- Extendable: Can be used with RL560 sensor extension cable for longer distances (up to 60M for THS01/DS18B20, 10M for MS01).
2. Пакеттин мазмуну
The package for the SONOFF THS01 sensor typically includes:
- 1 x SONOFF THS01 Temperature and Humidity Sensor
- Колдонуучунун Колдонмосу (бул документ)
Сүрөт 2.1: Алдыңкы view of the SONOFF THS01 product packaging.
2.2-сүрөт: Артка view of the SONOFF THS01 product packaging, showing additional details and certifications.
3. Орнотуу боюнча колдонмо
The THS01 sensor is designed for easy plug-and-play installation with compatible SONOFF TH Elite/Origin devices. Follow these steps to connect your sensor:
- Ensure your SONOFF TH Elite/Origin device is powered off before connecting the sensor.
- Locate the RJ9 4P4C sensor interface on your TH Elite/Origin device.
- Insert the RJ9 4P4C connector of the THS01 sensor firmly into the sensor interface. The RJ9 4P4C connector supports hot-plugging, but it is recommended to power off the main device for safety during initial connection.
- Once connected, power on your TH Elite/Origin device. The sensor will be automatically detected.
- For extended reach, you can use the SONOFF RL560 sensor extension cable (sold separately).
Figure 3.1: The THS01 sensor connected to a SONOFF TH Elite/Origin device, ready for operation.
Figure 3.2: The THS01 sensor actively monitoring temperature and humidity, displayed on the TH Elite/Origin's LCD screen.
4. Иштөө нускамалары
Once connected to a SONOFF TH Elite/Origin device, the THS01 sensor enables various smart monitoring and control functionalities through the eWeLink App and the device's LCD display.
4.1 Реалдуу убакыттагы мониторинг
The TH Elite/Origin device, with the THS01 sensor connected, provides real-time temperature and humidity readings on its integrated LCD screen. These readings are refreshed every 5 seconds. You can also view real-time data and historical trends via the eWeLink App on your smartphone or tablet.
Video 4.1: Demonstration of SONOFF TH Elite's features, including real-time temperature and humidity monitoring with compatible sensors like THS01, and app integration.
4.2 Local Auto Mode
The TH Elite/Origin supports a "Local Auto Mode" which allows the device to automatically turn on/off connected appliances based on predefined temperature and humidity thresholds. This functionality operates even if your Wi-Fi connection is temporarily unavailable.
- Set specific temperature or humidity ranges for automatic control.
- Define effective time periods for these automation rules.
Видео 4.2: Бүттүview of SONOFF TH Elite's capabilities, including sensor compatibility (like THS01), local auto mode setup, and smart scene creation for automated control.
4.3 Үн менен башкаруу
When paired with a SONOFF TH Elite/Origin device, the THS01 sensor's data can be integrated with popular voice assistants such as Amazon Alexa and Google Assistant. This allows you to inquire about current temperature and humidity or trigger actions using voice commands.
Figure 4.3: Illustrates voice control capabilities with Amazon Alexa and Google Assistant for monitoring and controlling devices based on sensor data.
5. Техникалык шарттар
Detailed technical specifications for the SONOFF THS01 Temperature and Humidity Sensor:
| Атрибут | Нарк |
|---|---|
| Модел | THS01 |
| Түс | Кара |
| Температураны өлчөө диапазону | -40 градустан +85 градуска чейин |
| Нымдуулукту өлчөө диапазону | 0-100% RH |
| Туташтыргыч түрү | RJ9 4P4C |
| Кабелдин узундугу | 0.5 метр (болжол менен 1.64 фут) |
| Maximum Extendable Length (with RL560) | 60 meters (for THS01/DS18B20) |
| Продукциянын өлчөмдөрү | 1.62"W x 3.54"H (approx. 4.1cm W x 9.0cm H) |
| Элемент Салмагы | 0.02 килограмм |
| Батареяга талап | No batteries needed (powered by host device) |
Figure 5.1: Visual representation of THS01 specifications, including model, color, cable length, connector type, and working ranges.
Figure 5.2: ашыкview of various SONOFF sensors compatible with TH Elite/Origin, including THS01, DS18B20 (waterproof temperature), MS01 (soil moisture), and RL560 (extension cable).
6. Кароо жана тейлөө
To ensure the longevity and accurate performance of your SONOFF THS01 sensor, please follow these care and maintenance guidelines:
- Тазалоо: Wipe the sensor body with a soft, dry cloth. Do not use abrasive cleaners, solvents, or harsh chemicals.
- Курчап турган чөйрө: Avoid exposing the sensor to extreme physical shock, vibrations, or direct water immersion (unless specifically designed for it, which THS01 is not).
- Сактагыч: When not in use for extended periods, store the sensor in a cool, dry place away from direct sunlight.
- Колдонуу: Handle the RJ9 4P4C connector with care to prevent bending or damaging the pins.
7. Кыйынчылыктарды
If you encounter issues with your SONOFF THS01 sensor, refer to the following common troubleshooting steps:
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| No temperature/humidity reading on display or App. | Sensor not properly connected; Host device (TH Elite/Origin) not powered on; Sensor malfunction. | Ensure the RJ9 4P4C connector is fully inserted. Verify the TH Elite/Origin device is powered. Try reconnecting the sensor. If issue persists, contact support. |
| Туура эмес окуулар. | Sensor placed in an unsuitable environment (e.g., direct sunlight, near heat source/vent); Sensor dirty. | Relocate the sensor to a more representative area. Clean the sensor gently with a dry cloth. Allow time for readings to stabilize. |
| Sensor not detected after connecting. | Firmware of TH Elite/Origin is outdated; Faulty sensor or port. | Check for firmware updates for your TH Elite/Origin device in the eWeLink App. Try connecting the sensor to a different compatible device if available, or try a different sensor if possible. |
8. Кепилдик жана колдоо
SONOFF products are manufactured to high-quality standards and are warranted against manufacturing defects. For specific warranty terms and conditions, please refer to the warranty information provided with your main SONOFF TH Elite/Origin device or visit the official SONOFF webсайт.
For technical support, troubleshooting assistance, or product inquiries, please contact SONOFF customer service through their official channels:
- Webсайт: sonoff.tech
- Электрондук почта: support@itead.cc
- Amazonдогу SONOFF дүкөнү: Visit the SONOFF Store
Please have your product model number (THS01) and purchase information ready when contacting support.
