1. Киришүү
Thank you for choosing the Avalla S-150 Portable Air Conditioner. This manual provides essential information for the safe and efficient operation, installation, and maintenance of your unit. Please read this manual thoroughly before using the appliance and retain it for future reference.
The Avalla S-150 is a versatile 4-in-1 unit, offering powerful cooling, effective dehumidification, air circulation as a fan, and a dedicated sleep mode for enhanced comfort.
2. Коопсуздук маалыматы
Маанилүү коопсуздук көрсөтмөлөрү:
- Ар дайым түзмөктүн туруктуу, тегиз бетке коюлганын текшериңиз.
- Before first use, allow the unit to stand upright for at least 24 hours to allow the refrigerant to settle.
- Аба кирүүчү же чыгуучу тешиктерди жаппаңыз. Аба агымынын туура айланышы үчүн түзмөктүн айланасында жетиштүү боштук калтырыңыз.
- This appliance uses R-290 refrigerant, which is flammable. Ensure proper ventilation and avoid ignition sources.
- Аппаратты бузулган шнур же сайгыч менен иштетпеңиз.
- Unplug the unit from the power outlet before cleaning or maintenance.
- Иштеп жаткан учурда балдарды жана үй жаныбарларын аппараттан алыс кармаңыз.
3. Продукт бүтүп калдыview
3.1 Компоненттер
The Avalla S-150 Portable Air Conditioner typically includes the following components:
- Негизги кондиционер
- Чыгаруучу шланг
- Window Sealing Kit (includes window bracket/slider and hose adapter)
- Алыстан башкаруу
Figure 1: Avalla S-150 unit and accessories.
3.2 Негизги өзгөчөлүктөрү
- Күчтүү муздатуу: 8000 BTU cooling capacity, capable of cooling rooms up to 80m³ down to 16°C. Air circulation rate of 290m³/h.
- 4-ин-1 Функциясы: Air Conditioner, Dehumidifier, Fan, and Sleep Mode.
- Колдонуучуга ыңгайлуу башкаруулар: Intuitive one-touch controls, clear digital display, and a convenient remote control.
- Тынч иштөө: Operates at approximately 52dB, with an enhanced sleep mode for reduced noise during nighttime use.
- Энергияны үнөмдүү: Class A energy efficiency rating with an 891W motor, designed for low running costs (approx. 19p per hour). Utilizes eco-friendly R-290 refrigerant.
- Кургатуу: Removes up to 22 litres of moisture per day, helping to prevent damp and mould. Can also assist in drying clothes.
- Жуучу аба чыпкасы: Equipped with a washable air filter to maintain performance and extend unit lifespan.
Figure 2: Control your climate all year round with 4-in-1 functionality.
Figure 3: Powerful cooling performance for large rooms.
4. Орнотуу
Баштапкы орнотуу үчүн бул кадамдарды аткарыңыз:
- Unpack and Settle: After unpacking, place the unit upright on a flat, stable surface. Allow it to stand for at least 24 hours before plugging it in. This ensures the refrigerant settles properly.
- Түзүүчү түтүктү туташтыруу: Чыгаруучу түтүктү түзмөктүн арткы жагындагы атайын розеткага туташтырыңыз.
- Терезе топтомун орнотуу: Secure the other end of the exhaust hose to the window sealing kit. Install the window kit in a suitable window opening to vent hot air outside. The kit is designed to be adaptable for various window types, including sliding, casement, awning, and sash windows.
- Позициялоо: Place the air conditioner near a window or opening that allows for easy venting of the exhaust hose. Ensure there is sufficient space around the unit for proper air circulation.
Figure 4: Easy setup and operation.
4.1 Видеону орнотуу
Video 1: Welcome to the 2345W Industrial Class S-150 Air Conditioner. This video provides a visual guide to the unit's features and setup.
5. Иштөө нускамалары
5.1 Башкаруу панели жана алыстан башкаруу
The unit can be operated using the touch-sensitive control panel on top of the unit or the included remote control. The digital display shows the current temperature setting and mode indicators.
5.2 Иштөө режимдери
- Муздак режим: Select this mode for air conditioning. Adjust the desired temperature using the up/down arrows. The unit can cool down to 16°C.
- Кургаткыч режими: This mode extracts excess moisture from the air, removing up to 22 litres per day. The fan speed is typically fixed in this mode.
- Күйөрман режими: Circulates air without cooling or dehumidifying. Choose between 2 fan speeds (low/high) for optimal airflow.
- Уйку режими: Designed for quiet operation during sleep. This mode typically reduces fan speed and dims the display lights.
Figure 5: Quiet operation and sleep mode.
5.3 Таймер функциясы
The programmable timer allows you to set the unit to turn on or off automatically, up to 24 hours in advance. Refer to the remote control or control panel section for specific timer setting instructions.
5.4 Балдардан коргоо функциясы
Activate the child lock feature to prevent accidental changes to settings by children. Consult the remote control or control panel section for activation/deactivation steps.
5.5 Жалпы операциялык видео
Video 2: Avalla - Portable Air Conditioners. This video provides a general overview of Avalla portable air conditioners, including operational aspects.
6. Техникалык тейлөө
Regular maintenance ensures optimal performance and extends the lifespan of your Avalla S-150.
- Аба чыпкасын тазалоо: The unit is equipped with a washable air filter. Regularly remove and clean the filter under running water. Allow it to dry completely before reinserting. Frequency depends on usage and air quality, but generally every 2-4 weeks.
- Суу резервуарын бошотуу: In dehumidifier mode, the unit collects water. When the water tank is full, the unit will typically indicate this and stop operation. Drain the collected water as per the instructions in the full manual.
- Тышкы тазалоо: Агрегаттын сыртын жумшак менен сүртүңүз, гamp кездеме. Катуу химиялык заттарды же абразивдүү тазалагычтарды колдонбоңуз.
Figure 6: Dehumidifier function for drying clothes.
Figure 7: Dehumidifier function for protecting health and home.
7. Кыйынчылыктарды
If you encounter issues with your Avalla S-150, refer to the following common problems and solutions:
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Түзмөк күйбөйт | No power supply; Power button not pressed; Water tank full | Check power connection; Press power button firmly; Empty water tank |
| Жетишсиз муздатуу | Windows/doors open; Air filter dirty; Exhaust hose blocked/disconnected; Room size too large | Close windows/doors; Clean air filter; Check hose connection; Ensure unit is suitable for room size (up to 80m³) |
| Бирдиги ызы -чуу | Unit not on a level surface; Obstruction in fan; Normal operating noise | Place on a level surface; Check for obstructions; Note that some noise (approx. 52dB) is normal during operation. |
| Damp жыт | Water accumulation in tank; Unit needs cleaning | Empty water tank regularly; Perform general cleaning of the unit. |
If the problem persists after attempting these solutions, please contact Avalla customer support for assistance.
8. Техникалык шарттар
| Өзгөчөлүк | Спецификация |
|---|---|
| Модель номери | S-150 |
| Бөлүмдүн номери | AVS-150 |
| Муздатуу кубаттуулугу | 8000 BTU |
| нымдуулуктун күч жөндөмдүүлүгү | Күнүнө 22 литрге чейин |
| Power Source | Электр зымдары |
| Тtage | 230 вольт (AC) |
| Ватtage | 2345 watts (891W motor for operational efficiency) |
| Үн деңгээли | 52 дБ |
| Продукциянын өлчөмдөрү (D x W x Y) | 30 x 29.7 x 70 см |
| Элемент Салмагы | 20.2 кг |
| Энергия натыйжалуулугунун рейтинги | А классы |
| Муздаткыч | R-290 (Экологиялык жактан таза) |
9. Кепилдик жана колдоо
Avalla жогорку сапаттагы продукцияларды жана эң сонун кардарларды тейлөөнү камсыз кылууга умтулат.
- Кепилдик: Your Avalla S-150 Portable Air Conditioner comes with a 2-year warranty from the date of purchase. Please retain your proof of purchase for warranty claims.
- Кардарларды колдоо: For any questions, technical assistance, or warranty inquiries, please contact our UK-based customer support team.
- Онлайн ресурстар: Visit the official Avalla Store for additional product information, FAQs, and support resources: Авалла дүкөнү.
