KanDao Meeting Pro 360° Video Conference Room Camera User Manual

1. Киришүү

The KanDao Meeting Pro is an all-in-one 360° video conference camera designed to enhance your meeting experience. It features dual wide-angle lenses for complete room coverage, AI-powered tracking, an 8-microphone array, and a Hi-Fi speaker for clear audio. With built-in Android OS, it offers versatile operation modes and broad compatibility with popular conferencing platforms.

2. Пакеттин мазмуну

Орнотууну улантуудан мурун бардык элементтер бар экенин текшериңиз:

• KanDao Meeting Pro Device
• Алыстан башкаруу
• Линзанын капкагы
• Кубаттуу адаптер
• USB-C - USB-C кабели
• USB-C - USB-A кабели
• Сактоочу баштык
• Продукциянын таңгагында көрсөтүлгөн башка аксессуарлар.

3. Орнотуу колдонмосу

3.1 Pro Mode Setup (Standalone Operation)

This mode allows the Meeting Pro to operate independently with a displayer.

1. Кабель туташуу:

   Connect the power adapter to the Meeting Pro using the USB-C to USB-C cable. Then, connect the Meeting Pro to a displayer (monitor/TV) using an HDMI cable. Ensure the HDMI cable is securely plugged into both the Meeting Pro's HDMI OUT port and the displayer's HDMI IN port.



   Image: KanDao Meeting Pro with power and HDMI cables connected to a displayer.
2. Күйгүзүү:

   Long-press the power button on the Meeting Pro for approximately 3 seconds until the light ring illuminates. The device will boot up, and the displayer will show a connection page.

   If the displayer does not support 1080P 30Hz, long-press the VOL+ and VOL- buttons simultaneously for about 3 seconds to switch the HDMI output resolution to 720P 60Hz.

3. Language, Time Zone, and Network Setting:

   Use a wired/wireless mouse or keyboard (connected via USB) to navigate the on-screen menu. Select your preferred language and time zone. Connect to a Wi-Fi network or use an Ethernet cable for a wired connection.
4. Орнотулган программаны жаңыртуу:

   After a successful network connection, if a firmware update notification appears, please download the latest firmware. The Meeting Pro will restart automatically to complete the update. This process may take up to 3 minutes. Wait until the green light remains steady before proceeding.

5. Download Conferencing Software:

   Navigate to the App Store page on the Meeting Pro's interface. Download and install your preferred conferencing software (e.g., Zoom, Teams, Google Meet) for first-time use.

3.2 USB Mode Setup (Connected to a Computer)

This mode allows the Meeting Pro to function as a USB peripheral (webcam, microphone, speaker) for your computer.

1. Кабель туташуу:

   Connect the power adapter to the Meeting Pro using the USB-C to USB-C cable. Then, connect the Meeting Pro to your computer using the USB-C to USB-A cable. Ensure the USB-C end is plugged into the Meeting Pro's USB-C OUT port and the USB-A end into your computer's USB port.

   Caution: Pay attention to the power and computer symbols when connecting cables to ensure correct port usage.
2. Күйгүзүү:

   Long-press the power button on the Meeting Pro to start the device. The steady green light indicates successful power-on.

3. Connect Computer to Network:

   Ensure your computer is connected to the internet via Wi-Fi or Ethernet.

4. Start Conferencing:

   Open your preferred conferencing software on your computer. The Meeting Pro should be automatically recognized as the video/audio source. If not, select "KanDao Meeting Pro" as the microphone, camera, and speaker in the software's settings.
5. Pair Remote Controller:

   Simultaneously press the "OK" and "VOL-" buttons on the remote controller for 3 seconds to pair it with the Meeting Pro. The displayer will show "Controller Connected". The remote can also function as a mouse by pressing the "mouse" button on its upper right.

4. Иштөө нускамалары

The KanDao Meeting Pro offers various smart modes and features to optimize your conference experience.

4.1 Smart Modes

Switch between different modes using the remote control or on-device buttons to suit various meeting styles:

• Талкуу режими: Focuses on active speakers in individual frames.
• Глобалдык режим: Provides a complete 360° panoramic view жолугушуу бөлмөсүнөн.
• Презентация режими: Highlights the presenter and their content.
• Патруль режими: Automatically scans the room for active participants.
• Ыңгайлаштырылган режим: Allows for personalized view орнотуулар.

Image: A screen showing various conference views (Discussion, Global, Presentation, Patrol, Custom modes) from the KanDao Meeting Pro.

4.2 AI Tracking and View Кулпулоо

The device utilizes AI face and voice tracking to automatically highlight the active speaker. You can also manually lock the view or zoom in/out on specific content (except in Global Mode) using the remote control.

Image: The KanDao Meeting Pro in a conference room, demonstrating AI-powered speaker tracking by highlighting the active speaker on a large display.

4.3 Жергиликтүү жаздыруу

The Meeting Pro supports local recording of meetings to an SD card (FAT32 format only). Insert an SD card into the device. Press the record button on the remote control or long-press the mute button on the camera to start/stop recording. Recorded videos can be accessed from the DCIM folder on the SD card.

Image: A screen displaying a meeting being recorded locally by the KanDao Meeting Pro, with a remote control visible.

4.4 Экранды бөлүшүү

The device supports one-click wireless screen sharing, compatible with iOS, macOS, Android, and Windows devices using AirPlay and Miracast protocols. This feature eliminates the need for messy wired setups for content sharing.

4.5 Multi-Unit Connection

For larger conference rooms, the KanDao Meeting Pro supports the integration of 2 to 4 units to expand image and voice pickup coverage. This allows for flexible room layouts such as long tables, round tables, U-shaped setups, or even classroom arrangements.

Image: Diagrams illustrating different meeting room configurations (long table, round table, U-shaped, classroom) with multiple KanDao Meeting Pro devices for extended coverage.

4.6 Расмий продукт Videos

For detailed visual instructions and demonstrations of the KanDao Meeting Pro's features and operation, please refer to the official product videos below:

5. Техникалык тейлөө

Proper maintenance ensures the longevity and optimal performance of your KanDao Meeting Pro.

• Тазалоо: Түзмөктү тазалоо үчүн жумшак, кургак чүпүрөктү колдонуңуз. Суюк тазалоочу каражаттарды же аэрозольдорду колдонбоңуз.
• Линзага кам көрүү: Use the provided lens cover when the camera is not in use to protect the lenses from dust and scratches. For cleaning lenses, use a specialized lens cleaning cloth and solution.
• Сактагыч: Store the device in a cool, dry place away from direct sunlight and extreme temperatures. Use the provided storage bag for protection during transport.
• Программалык камсыздоо жаңыртуулары: Түзмөктө эң акыркы функциялар жана иштин жакшырышы бар экенине ынануу үчүн, микропрограмма жаңыртууларын үзгүлтүксүз текшерип жана орнотуп туруңуз.

6. Кыйынчылыктарды

If you encounter issues with your KanDao Meeting Pro, refer to the following common troubleshooting steps:

• Түзмөк күйбөй жатат: Ensure the power adapter is correctly connected and the power outlet is functional. Long-press the power button for 3 seconds.
• No Video Output on Displayer (Pro Mode):
  • HDMI кабелдик байланыштарды текшериңиз.
  • Ensure the displayer supports 1080P 30Hz. If not, switch the Meeting Pro's HDMI output resolution to 720P 60Hz by long-pressing VOL+ and VOL- buttons simultaneously for 3 seconds.
• No Video/Audio (USB Mode):
  • Verify USB cable connection to your computer.
  • In your conferencing software settings, ensure "KanDao Meeting Pro" is selected as the camera, microphone, and speaker.
• Алыстан башкаруу жооп бербейт:
  • Ensure the remote control batteries are functional.
  • Re-pair the remote control by simultaneously pressing "OK" and "VOL-" buttons for 3 seconds.
• Жасалма интеллектти көзөмөлдөө көйгөйлөрү: Ensure the room is well-lit and participants are clearly visible to the camera. Avoid rapid movements that might confuse the tracking algorithm.
• Тармакка туташуу көйгөйлөрү: Check Wi-Fi password or Ethernet cable connection. Restart the device and your router if necessary.

For further assistance, please contact KanDao customer support.

7. Техникалык шарттар

8. Кепилдик маалыматы

The KanDao Meeting Pro comes with a 12-month / 1-year warranty from the date of purchase. Please retain your proof of purchase for warranty claims. This warranty covers manufacturing defects and malfunctions under normal use. It does not cover damage caused by misuse, accidents, unauthorized modifications, or natural disasters.

9. Кардарларды колдоо кызматы

For technical assistance, troubleshooting, or any inquiries regarding your KanDao Meeting Pro, please contact our Professional Global Customer Service Team. We offer dedicated technical support to ensure your satisfaction.

• Онлайн колдоо: Visit the official KanDao website for FAQs, user manuals, and support resources.
• Электрондук почта колдоо: Продуктуңуздун таңгагына же расмий өкүлгө кайрылыңыз webатайын колдоо электрондук почта дареги үчүн сайт.
• Микропрограмманы оптималдаштыруу: KanDao regularly provides firmware optimizations to improve product performance and add new features. Ensure your device is updated to the latest firmware.
