LEIVI акылдуу унитаз T162A колдонуучусунун колдонмосу

1. Киришүү

This manual provides detailed instructions for the installation, operation, maintenance, and troubleshooting of your LEIVI T162A Smart Toilet. Please read this manual thoroughly before installation and use to ensure proper function and safety. Keep this manual for future reference.

Figure 1.1: LEIVI T162A Smart Toilet, a modern, tankless toilet with integrated bidet features and smart functionalities.

2. Коопсуздук боюнча маанилүү маалымат

Always follow basic safety precautions when using electrical products, especially when children are present. To reduce the risk of burns, electrocution, fire, or injury to persons:

• Колдонуудан мурун бардык нускамаларды окуп чыгыңыз.
• Продукт кулап түшө турган же ваннага же раковинага тартыла турган жерге койбоңуз же сактабаңыз.
• Сууга же башка суюктукка салбаңыз же түшүрбөңүз.
• Сууга түшкөн продуктуга кол сунбаңыз. Дароо розеткадан ажыратыңыз.
• Бул өнүм балдар же майыптар тарабынан, үстүндө же жанында колдонулганда тыкыр көзөмөл керек.
• Бул продуктуну ушул колдонмодо сүрөттөлгөндөй максаттуу пайдалануу үчүн гана колдонуңуз. Өндүрүүчү сунуш кылбаган тиркемелерди колдонбоңуз.
• Never operate this product if it has a damaged cord or plug, if it is not working properly, or if it has been dropped or damaged, or dropped into water.
• Шнурды ысытылган беттерден алыс кармаңыз.
• Буюмдун аба тешиктерин эч качан жаппаңыз же аба тешиктери бүтөлүп калышы мүмкүн болгон керебет же диван сыяктуу жумшак бетке койбоңуз. Аба тешиктерин түктөн, чачтан жана ушул сыяктуулардан тазалаңыз.
• Эч качан уктап жатканда же уйкулуу кезде колдонбоңуз.
• Эч качан эч кандай тешикке эч кандай нерсени түшүрбөңүз же салбаңыз.
• Аэрозоль (спрей) продуктулары колдонулуп жаткан же кычкылтек берилип жаткан жерде сыртта колдонбоңуз же иштетпеңиз.
• Бул өнүмдү туура жерге туташтырылган розеткага гана туташтырыңыз. Жерге салуу көрсөтмөлөрүн караңыз.

3. Пакеттин мазмуну

Пакетти ачкандан кийин, төмөндө келтирилген компоненттердин бардыгы бар экенин жана бузулбаганын текшериңиз:

• LEIVI T162A Smart Toilet Unit
• Монтаждоочу аксессуарлар
• Колдонуучунун Колдонмосу (бул документ)
• Зымсыз алыстан башкаруу пульту (батарея менен)

4. Орнотуу жана орнотуу

The LEIVI T162A Smart Toilet is designed for floor-mounted installation. Due to the complexity of plumbing and electrical connections, professional installation is highly recommended to ensure proper function and adherence to local building codes.

4.1 Алдын ала орнотуу текшерүү тизмеси

• Ensure the installation area has adequate water supply and drainage.
• Verify that a grounded electrical outlet is available near the installation site.
• Confirm floor stability and levelness for proper toilet placement.

4.2 Орнотуу кадамдары (Ашыкчаview)

For detailed, step-by-step installation instructions, please refer to the dedicated Көйгөйлөрдү чечүү боюнча колдонмо (PDF) which often includes installation diagrams.

1. Prepare the installation area by ensuring the water supply is shut off and the old toilet (if any) is removed.
2. Position the new toilet unit over the flange, ensuring proper alignment.
3. Secure the toilet to the floor using the provided mounting accessories.
4. Connect the water supply line to the toilet's inlet.
5. Электр шнурын жерге туташтырылган электр розеткасына туташтырыңыз.
6. Суу менен камсыздоону күйгүзүп, агып кеткендигин текшериңиз.
7. Perform an initial flush and test all functions.

Figure 4.1: ашыкview of various practical features, including heated seat, warm air dry, and multiple wash modes, which should be tested after installation.

5. Иштөө нускамалары

Your LEIVI T162A Smart Toilet offers a range of automated and user-controlled features for enhanced comfort and hygiene.

5.1 Automatic Lid Opening & Closing

The toilet is equipped with motion sensors for touchless operation:

• Auto Lid Opening: When you approach the toilet, the lid will automatically rise. This eliminates the need to bend down or touch the lid.
• Auto Lid Closing & Flushing: After use and upon leaving the seat, the toilet will automatically close the lid and activate the flushing mechanism. This ensures hygiene and prevents forgetting to flush.

Figure 5.1: The toilet lid automatically opens when a user approaches, providing a hands-free experience.

Figure 5.2: The toilet automatically closes its lid and flushes after use. It also features a kicking sensor for men's use.

5.2 Автоматтык жуу

In addition to the auto-flush after leaving the seat, the toilet features high-efficiency flushing technology to reduce waste build-up and maintain cleanliness.

5.3 Bidet Functions and Spraying Settings

The integrated bidet offers various adjustable settings:

• Тез арада берилүүчү жылуу суу: The heating tube provides instant warm water, adjustable to 4 temperature levels (from room temperature up to 122°F / 50°C).
• Бир нече жуу режимдери: Choose from Strong Wash, Pulsating Wash, Soft Wash, Rear Wash, Front Wash (feminine wash), and Oscillating Wash. The oscillating wash moves the wand back and forth for thorough cleansing.
• Жөнгө салынуучу суунун басымы: Customize the water pressure to your preference.

Figure 5.3: The instant warm water feature provides comfortable water temperature, adjustable to four levels.

Figure 5.4: Explore various wash modes including Rear Wash, Front Wash, and Oscillating Wash for a personalized cleaning experience.

5.4 Ergonomic Heated Seat

The contoured seat provides warmth and comfort, especially in colder environments. The seat temperature is adjustable to 4 levels (from room temperature up to 98.6°F / 37°C).

Figure 5.5: The heated seat offers adjustable temperature settings for optimal comfort.

5.5 Warm Air Dry

After washing, a warm air dryer provides a hands-free drying experience. The air temperature is adjustable to 4 levels (from room temperature up to 122°F / 50°C).

Figure 5.6: The warm air dry function provides efficient drying with adjustable temperature settings.

5.6 Зымсыз Алыстан башкаруу

The toilet comes with a waterproof wireless remote control for convenient operation. It features a magnetic design for easy wall mounting or in-hand use.

• Функциялары: Stop, Rear wash, SPA wash, Bidet wash, Drying, Spray nozzle backwards/forwards, Water temperature, Flush, Night light, Position, Massage Swing, User1/User2 presets, Seat opening, Cover opening, Deodorization, Eco mode, Self-cleaning, Seat temperature adjustment.

Figure 5.7: The wireless remote control provides comprehensive control over all toilet functions.

5.7 Stepless Side Knob

A convenient side knob allows for quick access and adjustment of various functions, including Dry/Flush, Posterior/Feminine Wash, and Position adjustment.

Figure 5.8: The stepless side knob offers intuitive control for common functions.

5.8 LED санарип дисплей

The integrated LED digital display provides real-time information on water and seat temperatures, and indicates Eco mode status.

Figure 5.9: The LED digital display shows current settings. Also shown are visible filtration, auto nightlight, and IPX4 waterproof design.

5.9 Кошумча функциялар

• Auto Nightlight: An ambient light sensor automatically turns the nightlight on and off, providing illumination for nighttime use.
• Активдештирилген көмүр жыттандыруучу каражат: Neutralizes bathroom odors using activated carbon filters, effectively cleaning the air around the toilet.
• IPX4 Суу өткөрбөйт: The integrated body is designed to be IPX4 waterproof, ensuring safety and durability in bathroom environments.
• Visible Filtration: Features a visible filter for easy observation and timely replacement.
• Power Outagэлектрондук порт: Allows for manual flushing during power outages.

6. Техникалык тейлөө жана тазалоо

Regular maintenance ensures the longevity and hygienic operation of your LEIVI Smart Toilet.

6.1 Cleaning the Toilet Unit

• Use a soft cloth and mild, non-abrasive cleaner to wipe down the exterior surfaces.
• Do not use harsh chemicals, abrasive pads, or strong detergents, as these can damage the finish.
• For the bowl, use standard toilet bowl cleaner as needed.

6.2 Self-Cleaning Wand & Nozzle

The bidet wand and stainless steel nozzle are designed for self-cleaning. The wand is automatically cleaned before and after each wash function (Rear Wash, Front Wash, etc.).

Figure 6.1: The bidet wand features an automatic self-cleaning function for enhanced hygiene.

6.3 Фильтрди алмаштыруу

The toilet features a visible filtration system. Monitor the filter for discoloration or debris. Replace the filter periodically to ensure optimal water quality for the bidet functions. Refer to the troubleshooting guide or contact customer support for specific filter replacement instructions and part numbers.

7. Кыйынчылыктарды

If you encounter issues with your LEIVI Smart Toilet, please refer to the official Көйгөйлөрдү чечүү боюнча колдонмо (PDF) for detailed solutions. Below are some common issues and general advice:

• No Power/Functions Not Working: Check if the power cord is securely plugged into a grounded outlet. Verify that the circuit breaker has not tripped.
• Lid Not Opening/Closing Automatically: Ensure the motion sensor is clean and unobstructed. Check if the auto-sensing feature is enabled via the remote control.
• Insufficient Water Pressure for Bidet: Check the water supply valve is fully open. Ensure the water filter is not clogged and replace if necessary.
• Heated Seat/Water Not Warming: Verify temperature settings on the remote or side knob. Allow a few minutes for heating elements to reach desired temperature.
• Жагымсыз жыттар: Ensure the activated carbon deodorizer is functioning. Consider replacing the deodorizer filter if odors persist.
• агып кетүү: Immediately shut off the water supply. Check all connections for tightness. If leakage persists, contact a qualified plumber or customer support.

8. Техникалык шарттар

Figure 8.1: The LEIVI T162A features a comfort height of 17 inches, designed for ease of use.

9. Кепилдик маалыматы

LEIVI warrants its Toilets to be free from defects in materials and workmanship during normal use when properly installed and serviced for a period of үч (3) жыл from the date of purchase for all customers. This warranty covers manufacturing defects and ensures the product's functionality under normal operating conditions.

For warranty claims or service, please retain your proof of purchase and contact customer support.

10. Кардарларды колдоо кызматы

For any questions, technical assistance, or support regarding your LEIVI Smart Toilet, please contact LEIVI customer service. You can find contact information on the official LEIVI webсайт же сатып алуу платформасы аркылуу.

Сатуучу: LEIVI

For additional resources, including the Troubleshooting Guide, please visit the product page or the LEIVI brand store.
