1. Коопсуздук маалыматы
WARNING: Read this entire manual carefully before operating the STIGA BC 555 B brushcutter. Failure to follow instructions can result in serious injury or death.
- Always wear appropriate personal protective equipment (PPE) including long pants, safety glasses, sturdy footwear, hearing protection, and gloves.
- Be aware of thrown debris and sharp blades. Keep bystanders, children, and pets at a safe distance (at least 15 meters).
- Inspect the work area for objects that could be thrown or entangled in the cutting head.
- Ensure the brushcutter is in good working condition before each use. Do not operate if damaged.
- Handle fuel with extreme care. Store in approved containers, mix in a well-ventilated area, and avoid spilling.
- Never operate the brushcutter under the influence of alcohol, drugs, or medication that may impair judgment.
2. Продукт бүтүп калдыview
The STIGA BC 555 B is a powerful gas-powered brushcutter designed for demanding garden tasks. It features a 51.7 cc (1.55 kW) engine, a straight shaft, and a 45 cm cutting width. Its ergonomic design, reinforced structure, and low vibration levels ensure user comfort and control. The unit comes equipped with a Tap&Go dual-line nylon head and a 3-tooth metal blade for versatile cutting applications.
2.1-сүрөт: Толук view of the STIGA BC 555 B Brushcutter, showcasing its overall design with the engine, shaft, handle, and cutting head.
3. Компоненттер
Familiarize yourself with the main components of your STIGA BC 555 B brushcutter:
- Кыймылдаткыч блогу: The power source, housing the 51.7 cc engine.
- Вал: The long, straight tube connecting the engine to the cutting head.
- Bicycle Handlebar: Ergonomically designed for comfortable two-hand operation and control.
- Башкаруу туткасы: Located on the handlebar, containing the throttle trigger, safety lock, and stop switch.
- Кесүүчү күзөт: Protects the user from thrown debris.
- Tap&Go Dual Line Head: For nylon line cutting, allows line advancement by tapping on the ground.
- 3-Tooth Metal Blade: For heavier brush and thicker vegetation.
- Кош жип: Distributes the weight of the machine for reduced fatigue.
3.1-сүрөт: Альтернатива view of the brushcutter, highlighting the engine, shaft, and cutting head assembly.
Figure 3.2: Close-up of the control handle, showing the throttle trigger and stop switch for operational control.
4. Орнотуу жана чогултуу
Биринчи жолу колдонуудан мурун, бир аз чогултуу талап кылынат. Төмөнкү кадамдарды кылдаттык менен аткарыңыз:
- Рулдун жыйындысы: Attach the bicycle handlebar to the shaft using the provided fasteners. Ensure it is securely tightened and positioned for comfortable operation.
- Cutting Guard Installation: Securely attach the cutting guard to the shaft above the cutting head. This guard is essential for user safety.
- Cutting Head/Blade Attachment: Depending on your task, install either the Tap&Go nylon head or the 3-tooth metal blade. Refer to the specific instructions in your detailed manual for correct attachment and torque specifications.
- Жөндөө: Attach the double harness to the brushcutter. Adjust the straps to ensure the machine is balanced and comfortable to wear, distributing the weight evenly across your shoulders and back.
- Күйүүчү май аралашмасы: This brushcutter requires a specific fuel-oil mixture. Consult your engine manual for the correct ratio (typically 2-stroke oil mixed with unleaded gasoline). Mix fuel in an approved container and fill the fuel tank carefully, avoiding spills.
Figure 4.1: Detail of the handlebar attachment point on the brushcutter shaft, showing the secure mounting mechanism.
Figure 4.2: Close-up of the harness attachment point on the brushcutter shaft, designed for connecting the double harness.
5. Иштөө нускамалары
5.1 Моторду ишке киргизүү
- Щетка кескичти тегиз, туруктуу бетке коюңуз.
- Ensure the stop switch is in the 'ON' position.
- Engage the choke (if the engine is cold).
- Күйүүчү май көрүнгөнгө чейин праймер лампасын бир нече жолу басыңыз.
- Pull the starter cord firmly and steadily until the engine starts.
- Once started, disengage the choke gradually. Allow the engine to warm up for a few moments before use.
5.2 Using the Brushcutter
- Wear the double harness correctly, ensuring the brushcutter is balanced and comfortable.
- Maintain a firm grip on both handlebars.
- Кесүүчү башты жерге параллель кармаңыз.
- Use a sweeping motion, cutting from right to left for optimal efficiency and debris control.
- For the Tap&Go head, lightly tap the cutting head on the ground while the engine is running at full throttle to advance the nylon line.
- When using the metal blade, be extra cautious of kickback and avoid contact with hard objects.
5.3 Моторду токтотуу
To stop the engine, simply move the stop switch to the 'OFF' position.
6. Техникалык тейлөө
Regular maintenance ensures optimal performance and extends the life of your brushcutter.
- Аба чыпкасы: Clean or replace the air filter regularly, especially in dusty conditions. A clogged filter reduces engine performance.
- Свеча: От алдыргыч шамды мезгил-мезгили менен текшерип жана тазалап туруңуз. Эгерде эскирген же булганган болсо, аны алмаштырыңыз.
- Күйүүчү май чыпкасы: Check and replace the fuel filter as needed to prevent fuel system blockages.
- Cutting Head/Blade: Inspect the nylon line for wear and replace as necessary. Sharpen or replace the metal blade if it becomes dull or damaged.
- Жалпы тазалоо: After each use, clean the brushcutter, removing grass, dirt, and debris from the engine, shaft, and cutting head.
- Сактагыч: For long-term storage, drain the fuel tank or use a fuel stabilizer. Clean the machine thoroughly and store it in a dry, secure location.
7. Кыйынчылыктарды
Бул жерде кээ бир жалпы маселелер жана алардын мүмкүн болуучу чечимдери:
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Мотор иштебейт | No fuel, incorrect choke setting, fouled spark plug, clogged fuel filter | Check fuel level and mixture, adjust choke, clean/replace spark plug, replace fuel filter |
| Иш учурунда электр кубатын жоготуу | Clogged air filter, incorrect fuel mixture, dull cutting tool | Clean/replace air filter, ensure correct fuel mixture, sharpen/replace cutting tool |
| Ашыкча термелүү | Damaged or unbalanced cutting head/blade, loose components | Inspect and replace damaged cutting tools, tighten all fasteners |
| Nylon line not advancing | Line tangled, insufficient engine speed, empty spool | Untangle line, ensure full throttle when tapping, refill spool |
8. Техникалык шарттар
Key technical specifications for the STIGA BC 555 B Brushcutter:
| Өзгөчөлүк | Спецификация |
|---|---|
| Мотордун жылышы | 51.7 см³ |
| Мотор күчү | 1.55 кВт |
| Кесүү туурасы | 45 см |
| Handle Type | Велосипед рулу |
| Кесүүчү баш | Tap&Go Dual Line Head |
| Blade түрү | 3 тиштүү металл бычак |
| Жабдык | Double Harness |
| Продукциянын өлчөмдөрү (L x W x Y) | 1890 x 690 x 12.7 см |
| Элемент Салмагы | 9.8 килограмм |
| Power Source | Газ менен иштейт |
| Модель номери | 287421002/ST1 |
9. Кепилдик жана колдоо
The STIGA BC 555 B brushcutter is covered by a manufacturer's warranty. Please refer to the warranty card included with your product for specific terms and conditions, including warranty duration and coverage details. For technical support, spare parts, or service, please contact your authorized STIGA dealer or visit the official STIGA webжардам үчүн сайт.
