1. Киришүү
This manual provides essential information for the safe and efficient installation, operation, and maintenance of your MEIKEE 15W RGBW Low Voltage Landscape Lights. Please read these instructions thoroughly before use and retain them for future reference.
2. Коопсуздук маалыматы
- Орнотуудан же техникалык тейлөөдөн мурун электр кубаты өчүрүлгөнүн текшериңиз.
- This product operates on DC/AC 12-24V low voltage. Do not connect directly to 120V AC power without a compatible low voltagд трансформатор.
- Төмөн үнtage wiring and transformers are камтылган эмес жана өзүнчө сатып алуу керек.
- Электрдик коркунучтарды болтурбоо үчүн бардык туташуулардын коопсуз жана суу өткөрбөгөндүгүн текшериңиз.
- Do not attempt to modify or disassemble the lights, as this may void the warranty and create safety risks.
- Орнотуу учурунда балдарды жана үй жаныбарларын орнотуу аянтынан алыс кармаңыз.
3. Пакеттин мазмуну
Төмөндө тизмеленген нерселердин баары пакетиңизде бар экенин текшериңиз:
- 12 x 15W RGBW Landscape Lights
- 24 x Wire Connectors
- 2 x Алыстан башкаруу
- 1 х Инструкция (бул документ)
- 1 x Screw Pack (for wall mounting)
4. Орнотуу
4.1. Орнотуу ыкмалары
Your MEIKEE landscape lights offer two primary installation methods: ground insertion or wall mounting.
- Ground Insertion: Attach the provided stake to the light fixture. Push the stake firmly into the ground in your desired location.
- Дубалга орнотуу: Use the included bracket and screws to secure the light fixture to a wall or fence. Adjust the light head to the desired angle.
4.2. Электр зымдары боюнча нускамалар
The lights require a DC/AC 12-24V low voltage power supply. A low voltage transformer and low voltage wiring are камтылган эмес and must be acquired separately.
- Prepare your low voltage wiring by separating the two halves of the power cable.
- Disassemble the wire connector by unscrewing the cap.
- Insert one half of the power cable through the large cap of the connector.
- Align the power cable with the pin inside the connector and screw the cap back on firmly to pierce the cable and establish contact.
- Repeat the process for the other half of the power cable and the second part of the connector.
- Connect the light's wires to the prepared wire connectors, ensuring a secure and tight connection.
- Test the connection to ensure the wire does not come out easily.
4.3. Setup Videos
For a visual guide on installation and features, please refer to the following videos:
Видео 1: This official MEIKEE video provides a comprehensive demonstration of how to install the 15W Low Voltage RGB Color Changing Landscape Lights and showcases their various features and color options.
Видео 2: An official MEIKEE video illustrating the use of the remote control functionality and outdoor application of 15W RGBW Landscape lights.
5. Иштөө нускамалары
Your MEIKEE landscape lights are controlled via the included 29-key remote control. Ensure the remote has batteries installed (batteries included in the screw pack).
5.1. Алыстан башкаруу функциялары
- Күйгүзүү/өчүрүү: Жарыктарды күйгүзүү же өчүрүү үчүн кызыл баскычты колдонуңуз.
- Жалгыз түстөр: Select from 10 single colors directly using the color buttons.
- Жөнгө салынуучу жарыктык: Use the brightness up/down buttons to adjust the intensity of the selected color (25%-100%).
- Flash/Smooth Mode: Toggle between flashing and smooth transitions for single colors.
- Multi-Color Working Modes: Choose from 10 multi-color modes with adjustable speed for dynamic lighting effects.
- Таймер функциясы: Set the lights to automatically turn off after 2, 4, or 6 hours using the dedicated timer buttons.
- Эстутум функциясы: The lights will remember your last setting (color, brightness, mode) when turned off and on again, eliminating the need to reset.
6. Техникалык тейлөө
Proper maintenance ensures the longevity and optimal performance of your landscape lights.
- Тазалоо: Мезгил-мезгили менен жарык берүүчү приборлорду жумшак, гamp кирди жана калдыктарды тазалоо үчүн кездеме. Абразивдүү тазалагычтардан алыс болуңуз.
- Гидроизоляция: The lights are IP66 waterproof, designed to withstand various weather conditions. Ensure all connections are tightly sealed during installation to maintain this rating.
- Жылуулук таркатылышы: The aluminum housing is designed for efficient heat dissipation. Ensure the fixtures are not covered or obstructed to allow for proper airflow.
- Кабелдик текшерүү: Regularly inspect the low voltage cables for any signs of damage, fraying, or wear. Replace damaged cables immediately to prevent electrical hazards.
7. Кыйынчылыктарды
If you encounter issues with your MEIKEE landscape lights, refer to the following common troubleshooting steps:
- Жарыктар күйбөйт:
- Check the power supply to the low voltagд трансформатор.
- Ensure all wire connections are secure and properly pierced.
- Алыстан башкаруу пультунун батареялары иштеп турганын жана туура салынганын текшериңиз.
- Алыстан жооп бербейт:
- Пульт менен жарыктардын ортосунда эч кандай тоскоолдуктар жок экенин текшериңиз.
- Пульттун батарейкаларын алмаштырыңыз.
- Confirm you are within the maximum control distance (12 meters / 39.3 feet).
- Inconsistent Lighting/Flickering:
- Inspect wire connections for looseness or corrosion.
- Төмөнкү көлөмүн текшериңизtage wiring for damage.
- Ensure the transformer is adequately sized for the total wattagтуташкан жарыктардын e.
- Ички суу түтүгү:
- While the lights are IP66 rated, extreme conditions or improper installation can sometimes lead to water ingress. If this occurs, disconnect power immediately and contact customer support.
8. Техникалык шарттар
| Өзгөчөлүк | Спецификация |
|---|---|
| Бренд | MEIKEE |
| Модель номери | 12 |
| Ватtage | жарыкка 15 Ватт |
| Тtage | 12-24 Volts (DC/AC) |
| Ачык түс | RGBW (Кызыл, Жашыл, Көк, Ак) |
| Материал | Алюминий, поликарбонат |
| Сууга туруктуулук деңгээли | IP66 суу өткөрбөйт |
| Башкаруу ыкмасы | Remote Control (29-key) |
| Өзгөчөлүктөр | 10 single colors with adjustable brightness, 12 working modes with adjustable speed, Timer function (2/4/6H), Memory function |
| Орточо жашоо | 50,000 саат |
| Продукциянын өлчөмдөрү | 10"L x 4"W x 9"H (approximate per light) |
| Элемент Салмагы | 4.66 фунт (жалпы таңгак) |
9. Кепилдик жана колдоо
MEIKEE products are covered by a 2-year limited warranty from the date of purchase. This warranty covers defects in materials and workmanship under normal use.
For technical support, warranty claims, or any questions regarding your product, please contact MEIKEE customer service. You can typically reach us via email through the Amazon platform or by using the contact information provided in your product packaging.
We aim to provide a timely response within 24 hours.
