Introduction
The ZEALOT 120W Bluetooth Speaker S95 is a powerful and portable audio device designed for robust sound performance in various environments. Featuring 120W high-power output, IPX6 waterproof rating, and a long-lasting 40-hour playtime, this speaker is ideal for outdoor activities, parties, and home entertainment. It includes customizable EQ modes, dynamic LED lights, and versatile connectivity options to enhance your listening experience.
Кутуда эмне бар
- Зымсыз динамик x1
- Removable Shoulder Strap x1
- Колдонуучунун колдонмосу x1
- AUX кабели x1
- Type-C кабели x1
- Portable Velvet Bag x1
The package includes the ZEALOT S95 speaker, a removable shoulder strap for portability, a user manual for detailed instructions, an AUX cable for wired connections, a Type-C charging cable, and a portable velvet bag for protection and transport.
Продукт өзгөчөлүктөрү
120W High Power Audio
The S95 speaker is equipped with two 50W subwoofers and two 10W tweeters, powered by an advanced DSP chip. This configuration delivers clear mid-highs, rich, smooth, zero-distortion sound, and high-frequency audio up to 40kHz for an immersive listening experience.
IPX6 суу өткөрбөйт рейтинги
With an IPX6 rating, the ZEALOT S95 is highly resistant to heavy water sprays from all directions. This makes it suitable for outdoor use near water, such as camping, boating, or beach trips, without concern for splashes. Note: IPX6 rating means it is resistant to water jets, but not designed for submersion.
Party Wireless Speaker and EQ Mode
The S95 supports True Wireless Stereo (TWS) pairing, allowing you to connect two S95 speakers for a combined 240W maximum ultra-stereo sound experience. An integrated EQ button enables fine-tuning of audio signals with preset modes for personalized listening, including Bass, Vocal, and Normal settings.
Bluetooth 5.3 and 40H Playback
Advanced Bluetooth 5.3 technology ensures fast and stable wireless connectivity. In addition to Bluetooth, the speaker offers versatile music playback options via AUX 3.5mm, TF card, and USB drive. The powerful battery system provides up to 40 hours of playback time at minimum volume, suitable for extended use.
LED жарык шоу
The speaker features three colorful light modes that can sync with the pulse and rhythm of the music, creating a dynamic visual experience. These beat-driven lights add an exciting touch to parties, gatherings, and other events.
Орнотуу жана баштоо
Күйгүзүү/өчүрүү
To power on the speaker, press and hold the power button (⏻) for more than 3 seconds. To power off, repeat the same action.
Bluetooth Жупташтыруу
- Ensure the speaker is powered on and in Bluetooth mode (indicated by a blinking Bluetooth icon).
- Түзмөгүңүздө (смартфон, планшет ж.б.) Bluetooth иштетиңиз жана жеткиликтүү түзмөктөрдү издеңиз.
- Select "ZEALOT S95" from the list to pair. A confirmation tone will sound upon successful connection.
Чыныгы Wireless Stereo (TWS) жупташтыруу
To achieve 240W ultra-stereo sound, you can pair two ZEALOT S95 speakers:
- Эки S95 динамик тең күйүп турганын жана башка Bluetooth түзмөгүнө туташпаганын текшериңиз.
- On one speaker, press the TWS pairing button (two interlocking squares icon). The speaker will enter TWS pairing mode.
- Эки динамик автоматтык түрдө бири-бирине туташат. Жупташтырылгандан кийин ырастоо үн сигналы чыгат.
- Connect your device to one of the paired speakers via Bluetooth. Both speakers will now play in stereo.
Иштөө нускамалары
Башкаруу баскычтары
| Icon | Функция | Акция |
|---|---|---|
| ⏻ | Күйгүзүү/өчүрүү | 3 секунддан ашык басыңыз |
| Ⓑ | Bluetooth Pairing/Disconnecting | Press to pair/disconnect |
| ▷ | Ойнотуу/Тыныгуу | 1 секунд басыңыз |
| - | Үндү төмөндөтүү / Мурунку трек | Press 1s for Volume-, Press ≥2s for Previous Track |
| + | Көлөмүн жогорулатуу / Кийинки трек | Press 1s for Volume+, Press ≥2s for Next Track |
| M | Режим тандоо | Cycles through Wireless/TF/USB/AUX modes |
| EQ | Эквалайзер режими | Cycles through Bass/Vocal/Normal EQ |
| ✱ | Жарык күйгүзүү/өчүрүү | Press to toggle LED lights |
EQ режимдери
Press the EQ button to cycle through the available equalizer modes:
- Бас (Green light is on): Enhances low frequencies for a deeper bass sound.
- Вокал (Orange light is on): Optimizes mid-range frequencies for clearer vocals.
- Кадимки (White light is on): Provides a balanced audio profile.
LED жарык режимдери
Press the Light On/Off button (✱) to toggle the LED party lights. The lights will cycle through various colors and patterns, often syncing with the music's rhythm.
Туташуу параметрлери
The ZEALOT S95 offers multiple ways to connect your audio sources:
- Bluetooth 5.3: Шайкеш түзүлүштөр менен зымсыз байланыш үчүн.
- AUX 3.5 мм: Use the included AUX cable to connect devices with a 3.5mm audio output.
- TF картасы: Insert a TF (MicroSD) card loaded with audio files.
- USB Drive: Connect a USB flash drive with audio files.
Батарея жана заряддоо
Спикерди заряддоо
The speaker is equipped with a powerful battery for extended use. To charge, connect the included Type-C cable to the 'DC 5V' port on the speaker and to a compatible power adapter. For optimal charging efficiency, a 9V/3A to 20V/2.25A charging adapter is recommended. A full charge takes approximately 4 hours.
Батарея деңгээлинин көрсөткүчү
The battery level is indicated by LED lights on the control panel:
- 80%-100%: Жашыл жарык күйүп турат
- 40%-70%: Сары жарык күйүп турат
- ≤ 30%: Кызыл жарык күйүп турат
Power Bank функциясы
The speaker can also function as a power bank. Use the 'OUT 5V' USB port to charge external devices like smartphones or tablets.
Кароо жана тейлөө
- Суу каршылык: The IPX6 rating protects against strong water jets. Do not submerge the speaker in water. Ensure all port covers are securely closed before exposure to water.
- Тазалоо: жумшак колдонуу, damp Динамиктин сыртын тазалоо үчүн чүпүрөк колдонуңуз. Катуу химиялык заттардан же абразивдүү тазалоочу каражаттардан алыс болуңуз.
- Сактагыч: Динамикти түз күн нурунан жана өтө температурадан алыс салкын, кургак жерде сактаңыз.
- Батареяга кам көрүү: For optimal battery life, avoid fully discharging the speaker frequently. Charge it regularly, even if not in use for extended periods.
Проблемаларды чечүү
- Кубат жок: Ensure the speaker is fully charged. Connect to a power source and check the battery indicator.
- Bluetooth жупташтыруу мүмкүн эмес: Make sure the speaker is in Bluetooth pairing mode (blinking Bluetooth icon). Ensure your device's Bluetooth is on and within range (up to 10 meters). Try unpairing and re-pairing.
- Үн жок: Check the volume levels on both the speaker and your connected device. Ensure the correct input mode (Bluetooth, AUX, TF, USB) is selected.
- Үн сапаты начар: Ensure the speaker is within Bluetooth range and there are no obstructions. Try adjusting the EQ mode.
- TWS жупташтыруу маселелери: Ensure both speakers are S95 models and not connected to any other device before initiating TWS pairing.
Техникалык шарттар
| Өзгөчөлүк | Деталь |
|---|---|
| Модель аты | S95 Bluetooth спикери |
| Динамик түрү | Көчмө спикер |
| Динамиктин максималдуу чыгаруу күчү | 150 Ватт (чоку) |
| Сабвуфердин диаметри | 3.6 дюйм |
| Tweeter диаметри | 1.26 дюйм |
| Зымсыз байланыш технологиясы | Bluetooth 5.3 |
| Bluetooth диапазону | 10 метр (33 бут) |
| Сууга туруктуулук деңгээли | IPX6 суу өткөрбөйт |
| Батарея сыйымдуулугу | 24000 миллионamp Саат |
| Заряддоо убактысы | 4 саат |
| Оюн убактысы | Up to 40 hours (at minimum volume) |
| Продукциянын өлчөмдөрү | 6.57"D x 14.09"W x 11.3"H |
| Элемент Салмагы | 11.26 фунт |
| Камтылган компоненттер | AUX Cable, Power Cable, Removable Shoulder Strap, User Manual |
Кепилдик жана колдоо
The ZEALOT S95 Bluetooth Speaker comes with a Limited Warranty. For warranty claims, technical support, or any inquiries regarding your product, please contact ZEALOT customer service through the official channels provided at the time of purchase or on the ZEALOT webсайт.
Расмий продукт Videos
ZEALOT S95 Bluetooth Speaker for Party
Бул видеодо толук маалымат берилетview of the ZEALOT S95 Bluetooth Speaker, highlighting its features and suitability for party environments. It showcases the speaker's design and functionality.
The Best Speaker I've Had: ZEALOT 120W Bluetooth Speaker
This video offers a personal review and demonstration of the ZEALOT 120W Bluetooth Speaker, emphasizing its sound quality and overall performance from a user's perspective.
