1. Орнотуу
1.1 Кутудан чыгаруу жана компоненттер
Your Godox XProII-S Flash Trigger and X1R-S Receiver Kit includes the following items:
- 1x Godox XProII-S TTL Wireless Flash Trigger
- 2x Godox X1R-S TTL Wireless Flash Receiver
Image: The Godox XProII-S Flash Trigger and two X1R-S Receivers included in the kit.
1.2 Батареяны орнотуу
The XProII-S trigger and X1R-S receivers typically use AA batteries (not included). Refer to the battery compartment markings for correct polarity.
1.3 Mounting the XProII-S Trigger
- Slide the XProII-S trigger onto your Sony camera's hotshoe.
- Secure the trigger by rotating the quick-release lock until it is firmly attached.
Image: Close-up of the XProII-S trigger's quick-release lock mechanism, ensuring secure attachment to the camera hotshoe.
1.4 Attaching X1R-S Receiver to Flash
- Slide the X1R-S receiver onto your compatible flash unit's hotshoe.
- Secure the receiver using its locking mechanism.
Image: The Godox X1R-S Flash Receiver for Sony, designed to be mounted on a flash unit.
1.5 Күйгүзүү/өчүрүү
Press and hold the power button on both the XProII-S trigger and X1R-S receivers to turn them on or off. Ensure all units are powered on for wireless communication.
2. Иштөө
2.1 Basic Controls (XProII-S)
The XProII-S features a large LCD screen and intuitive buttons for navigation and settings adjustment. The main dial is used to change values, while the SET button confirms selections.
Image: The Godox XProII-S Flash Trigger displaying its LCD screen and various control buttons.
2.2 Setting Channels and IDs
To prevent interference and ensure reliable communication, set the same channel and ID on both the XProII-S trigger and all connected X1R-S receivers. The XProII-S can scan for the clearest channel.
Video: Demonstrates setting channels and IDs on the Godox XProII-S trigger and a connected flash unit, including the channel scanning function.
2.3 Жаркылдатуу режимдери (TTL, Кол менен, Көп)
The XProII-S supports various flash modes:
- TTL автофлеш: Туура экспозиция үчүн жарк чыгарууну автоматтык түрдө тууралайт.
- Кол менен жарк (M): Жаркылдатуучу кубаттуулукту так кол менен башкарууга мүмкүндүк берет.
- Көп жарк: Fires a series of rapid flashes for stroboscopic effects.
Сүрөт: Мисamples of the XProII-S display showing TTL, Multi, and Manual flash mode settings.
2.4 Жогорку ылдамдыктагы синхрондоштуруу (HSS)
HSS allows the flash to synchronize with shutter speeds up to 1/8000s, enabling the use of wide apertures in bright conditions.
2.5 Жарк этүүнүн ордун толтуруу (FEC)
Adjust the flash output relative to the TTL metered exposure to fine-tune lighting. This can be set directly on the trigger.
2.6 TCM Transform Function
The TCM (TTL Convert Manual) function allows you to convert a TTL flash value into a manual power setting. This provides a starting point for manual adjustments, saving time during setup.
Video: Demonstrates the TCM (TTL Convert Manual) function, showing how TTL settings can be used as a reference for manual flash adjustments.
2.7 Bluetooth and App Control
The XProII-S features Bluetooth connectivity, allowing you to control lighting parameters remotely using the Godox app on your smartphone or tablet. This offers a flexible and intuitive control experience.
- Enable Bluetooth on your XProII-S trigger.
- Open the Godox app on your mobile device.
- Издөө and connect to your XProII-S device.
- Adjust flash settings directly from the app.
Image: A smartphone displaying the Godox app interface, controlling flash settings remotely via Bluetooth with the XProII-S trigger.
Video: Illustrates the process of connecting the Godox XProII-S trigger to a smartphone via Bluetooth and adjusting flash settings using the Godox app.
2.8 L-858 Mode (Light Meter Integration)
The XProII-S can integrate with the Sekonic L-858 light meter, allowing the light meter to prioritize control over your lights. This streamlines the process of setting flash values based on precise light measurements.
Video: Shows the XProII-S operating in L-858 mode, demonstrating how it integrates with a Sekonic L-858 light meter to control flash output.
2.9 Жалгыз байланышты ишке киргизүү
This feature enhances burst mode performance by allowing faster flash triggering in rapid succession, reducing the interval between each flash.
Video: Illustrates the Single Contact Triggering feature, showing its effect on burst mode performance for faster flash synchronization.
2.10 Топтук контроль
The XProII-S allows you to control multiple flash units in different groups (A, B, C, D, E). Each group can have independent flash mode and power settings, providing versatile lighting control.
3. Техникалык тейлөө
3.1 Тазалоо
Regularly clean the exterior of the trigger and receivers with a soft, dry cloth. For hotshoe contacts, use a clean, dry cotton swab. Avoid using harsh chemicals or abrasive materials.
3.2 Сактоо
When not in use for extended periods, remove batteries from both the trigger and receivers to prevent leakage. Store the units in a cool, dry place away from direct sunlight and extreme temperatures.
3.3 Микропрограмма жаңыртуулары
Godox periodically releases firmware updates to improve performance and add new features. Check the official Godox website for the latest firmware for your XProII-S and X1R-S units and follow the provided instructions for updating.
4. Кыйынчылыктарды
If you encounter issues with your Godox XProII-S and X1R-S kit, refer to the following common problems and solutions:
4.1 Жарк этпейт
- Батареяларды текшерүү: Ensure batteries in both the trigger and receiver are fully charged and correctly inserted.
- Күйгүзүү: Verify that both the trigger and receiver are powered on.
- Channel/ID Mismatch: Confirm that the trigger and receiver are set to the same channel and ID.
- Hotshoe Connection: Ensure the trigger is securely mounted on the camera's hotshoe and the receiver on the flash. Clean contacts if necessary.
- Камера орнотуулары: Check your camera's flash settings to ensure external flash is enabled.
4.2 Туура эмес экспозиция
- Жаркыроо режими: If in Manual mode, adjust the power output. If in TTL, check for Flash Exposure Compensation (FEC) settings.
- Аралык: Ensure the flash-to-subject distance is appropriate for the flash power setting.
- Айланадагы жарык: Consider the impact of ambient light on your exposure.
4.3 Bluetooth туташуу маселелери
- Bluetooth иштетүү: Ensure Bluetooth is enabled on both the trigger and your mobile device.
- Колдонмо уруксаттары: Verify that the Godox app has necessary Bluetooth permissions on your device.
- Түзмөктөрдү кайра иштетүү: Try restarting the trigger, your mobile device, and the Godox app.
5. Техникалык шарттар
| Өзгөчөлүк | Спецификация |
|---|---|
| Модел | Godox XProII-S (Trigger), Godox X1R-S (Receiver) |
| Шайкештик | Sony камералары |
| Зымсыз тутум | Godox 2.4G зымсыз X системасы |
| Flash режимдери | TTL Autoflash, Manual Flash, Multi Flash |
| Жогорку ылдамдыктагы синхрондоштуруу (HSS) | 1/8000с чейин |
| Жарк этүүнүн ордун толтуруу (FEC) | Колдоого алынган |
| TCM функциясы | TTL to Manual Conversion |
| Bluetooth | Supported (for Godox App control) |
| Каналдар | 32 |
| Топтор | 5 (A, B, C, D, E) |
| Зымсыз диапазон | Болжол менен 100 метр |
| Power Source | AA батарейкалар (киргизилген эмес) |
| Пакеттин өлчөмдөрү | 6.93 x 5.24 x 4.41 дюйм |
| Элемент Салмагы | 1.32 фунт |
6. Кепилдик жана колдоо
6.1 Кепилдик маалыматы
This Godox product is covered by a manufacturer's warranty against defects in materials and workmanship. The specific duration and terms of the warranty may vary by region and retailer. Please retain your proof of purchase for warranty claims.
6.2 Кардарларды колдоо
For technical assistance, troubleshooting beyond this manual, or warranty inquiries, please contact Godox customer support or your authorized retailer. You can find contact information on the official Godox webсайт (www.godox.com).
