OREI UHDS-104A 1x4 HDMI 2.0 сплиттери, масштабдоочу жана аудио чыгаргыч менен колдонуучунун колдонмосу

1. Киришүү

The OREI UHDS-104A is a 1x4 HDMI 2.0 Splitter designed to distribute a single HDMI input signal to four identical HDMI output signals. This device supports resolutions up to 4K x 2K at 60Hz and includes a built-in scaler to match resolutions across different displays. It also features an audio extractor, providing both analog and optical audio outputs. The UHDS-104A is compliant with HDMI 2.0b and HDCP 2.2 standards, ensuring compatibility with a wide range of modern media devices.

Figure 1: OREI UHDS-104A 1x4 HDMI Splitter with Scaler and Audio Extractor.

2. Пакеттин мазмуну

Пакетте бардык буюмдар бар экенин текшериңиз:

• 1 x OREI UHDS-104A 1x4 HDMI 2.0 Splitter
• 1 x DC 5V Power Adapter (100-240V, US Plug)
• 1 x User Manual

Эскертүү: HDMI кабелдери комплектке кирбейт жана өзүнчө сатып алынышы керек.

Figure 2: Visual representation of the OREI UHDS-104A package contents, including the splitter, power adapter, and user manual.

3. Продукт бүтүп калдыview

Front Panel

• POWER LED: Түзмөк күйгүзүлгөндө жарык берет.
• IN LED: Illuminates when an active HDMI input signal is detected.
• OUT 1-4 LEDs: Illuminate when an active HDMI output connection is established for each respective port.
• КЫЗМАТ порту: Micro USB port for firmware updates.
• EDID которгуч: Allows selection of EDID modes (AUTO, COPY, 5.1CH, 7.1CH) to optimize compatibility between source and displays.
• 4K->1080P Switches (1-4): Individual switches for each output to enable or disable 4K to 1080P downscaling.

Арткы панель

• HDMI OUT 1-4: HDMI 2.0 output ports for connecting to displays.
• ОПТИКАЛЫК ЧЫГЫШ: Optical audio output (SPDIF) for connecting to audio receivers or soundbars.
• L/R OUT: 3.5mm analog stereo audio output for connecting to external ampкөтөргүчтөр же спикерлер.
• HDMI IN: HDMI 2.0 input port for connecting to the source device.
• DC 5V: Power input port for the included 5V DC power adapter.

3-сүрөт: алдыңкы панел view of the OREI UHDS-104A, highlighting LED indicators and control switches.

Сүрөт 4: Арткы панель view of the OREI UHDS-104A, showing HDMI input/output, audio outputs, and power input.

4. Орнотуу нускамалары

Follow these steps to set up your OREI UHDS-104A HDMI Splitter:

1. HDMI булагын туташтырыңыз: Connect your HDMI source device (e.g., Blu-ray player, game console, PC) to the HDMI-IN port on the splitter using a high-quality HDMI cable (recommended 30 feet or shorter).
2. HDMI дисплейлерин туташтыруу: Connect up to four HDMI displays (e.g., TVs, monitors, projectors) to the HDMI OUT 1-4 ports on the splitter using high-quality HDMI cables.
3. Аудио чыгарууну туташтыруу (милдеттүү эмес): If you wish to extract audio, connect your audio receiver or soundbar to either the ОПТИКАЛЫК ЧЫГУУ port (for digital audio) or the L/R OUT port (for analog stereo audio).
4. Туташуу кубаты: Кошумча 5V DC кубат адаптерин туташтырыңыз DC 5V port on the splitter, then plug the adapter into a power outlet. The POWER LED on the front panel will illuminate.
5. Түзмөктөрдү күйгүзүү: Power on your HDMI source device and all connected displays.

Figure 5: Diagram illustrating the typical connection setup for the OREI UHDS-104A, showing source, splitter, displays, and audio output.

5. Иштөө нускамалары

EDID башкаруу

The EDID (Extended Display Identification Data) switch on the front panel allows you to manage the communication between the source and displays for optimal compatibility. Adjust the switch based on your setup requirements:

• АВТО: The splitter automatically detects the best EDID settings from the connected displays.
• КӨЧҮРҮҮ: The splitter copies the EDID from Output 1 to all other outputs. This is useful when all displays are identical or when you want to force a specific resolution/audio format.
• 5.1CH / 7.1CH: Forces the audio output to 5.1 channel or 7.1 channel, respectively, for compatible audio systems.

4K to 1080P Downscaling

The UHDS-104A features individual switches for each output (1-4) to enable or disable 4K to 1080P downscaling. This is particularly useful when connecting a 4K source to a mix of 4K and 1080P displays. By enabling downscaling for 1080P displays, you can ensure they receive a compatible signal while 4K displays receive the full 4K resolution.

• КҮЙҮК: Enables 4K to 1080P downscaling for the respective output.
• ӨЧҮК: Disables 4K to 1080P downscaling for the respective output (passes through original resolution).

Figure 6: Close-up of the front panel showing the EDID control switch and individual 4K to 1080P downscaling switches for each output.

6. Техникалык тейлөө

To ensure optimal performance and longevity of your OREI UHDS-104A, follow these maintenance guidelines:

• Түзмөктү салкын, кургак жана жакшы желдетилген жерде сактаңыз.
• Avoid exposing the device to direct sunlight, high temperatures, or humidity.
• Түзмөктү жумшак, кургак чүпүрөк менен тазалаңыз. Суюк же аэрозоль тазалагычтарды колдонбоңуз.
• Ensure all cables are securely connected to prevent signal loss or intermittent issues.

7. Кыйынчылыктарды

If you encounter issues with your OREI UHDS-104A, refer to the following common troubleshooting steps:

• Сүрөт жок/сигнал:
  • Ensure all HDMI cables are securely connected and are of good quality (recommended 30 feet or shorter).
  • Verify that the power adapter is correctly connected and the POWER LED is illuminated.
  • Check the EDID switch settings. Try setting it to 'AUTO' or 'COPY' from a working display.
  • If using a 4K source with 1080P displays, ensure the 4K->1080P downscaling switch is set to 'ON' for the respective outputs.
  • Try connecting the HDMI source directly to a display to confirm the source and display are working correctly.
• Аудио жок:
  • Ensure your audio system is correctly connected to either the OPTICAL OUT or L/R OUT ports.
  • Check the audio settings on your source device to ensure it's outputting a compatible audio format.
  • Adjust the EDID switch to a setting that supports the desired audio channels (e.g., 5.1CH, 7.1CH).
• Picture Quality Issues (Flickering, Distortion):
  • Use high-quality, certified HDMI 2.0 cables.
  • Мүмкүн болсо, кабелдин узундугун кыскартыңыз.
  • Ensure the 4K->1080P downscaling is correctly configured for your displays.

8. Техникалык шарттар

9. Кепилдик жана колдоо

The OREI UHDS-104A comes with a 1-Year OREI Warranty жана Өмүр бою колдоо. For technical assistance, troubleshooting, or warranty claims, please contact OREI customer support through their official channels.
