BORA CT15 жумушчу стенди + 4 даана 20 мм үстөл үстүнкү беттери колдонуучунун колдонмосу

Introduction

This manual provides essential information for the safe and effective use of your BORA CT15 Work Stand and accompanying 20mm Table Tops. Please read this manual thoroughly before assembly and operation to ensure proper setup, maintenance, and to understand the full capabilities of your product.

Коопсуздук маалыматы

Ар дайым төмөнкү коопсуздук чараларын сактаңыз:

• Ensure the work stand is placed on a stable, level surface before use.
• 2000 фунттан (907 кг) ашпаңыз.
• Distribute weight evenly across the tabletop surface.
• Keep hands and fingers clear of moving parts during setup and folding.
• Inspect the stand and tabletop for any damage before each use. Do not use if damaged.
• Store the unit in a dry, secure location when not in use.

Пакеттин мазмуну

Бардык компоненттер бар экендигин текшериңиз:

• 1 x BORA CT15 Centipede Work Stand
• 4 x 20mm Table Tops (CK22TM)
• Ыкчам Clamps (quantity as supplied)
• X-Cups (quantity as supplied)

Жайгашуу

Follow these steps to set up your CT15 Work Stand and Table Tops:

1. Unfold the Centipede Work Stand: Place the folded Centipede stand on a flat surface. Gently pull the legs outwards from the center until the stand fully expands into its open position. Ensure all legs are locked into place and the stand is stable. The stand will expand to a 4-foot by 8-foot footprint, providing a large support area.
2. Position the Table Tops: Place the four CK22TM table tops onto the expanded Centipede stand. The table tops are designed to fit securely on the stand's support points. Each tabletop measures 24" x 48" (610 mm x 1200 mm).
3. Secure the Table Tops (Optional but Recommended): Use the provided quick clamps or X-cups to secure the table tops to the Centipede stand for added stability, especially when working with heavy materials or performing tasks that involve significant force.

Image: The BORA CT15 Centipede Work Stand in its fully expanded configuration, alongside the four 20mm table tops. This illustrates the primary components ready for assembly and use.

Иштөө нускамалары

The BORA CT15 Work Stand and Table Tops provide a versatile and robust workstation:

• Иш бийиктиги: The stand provides a comfortable working height of 36 inches, suitable for various tasks and users.
• Жүктөө жөндөмдүүлүгү: The system is designed to support up to 2000 pounds (907 kg). Always distribute the load evenly across the tabletop surface to prevent stress points.
• Dog Holes: The table tops feature 20mm dog holes spaced at 96mm on center. These holes are compatible with a wide range of 20mm dog hole accessories, allowing for versatile clamping and jig setups.
• Көчүрүү мүмкүнчүлүгү: The Centipede stand folds compactly for easy transport and storage. The table tops can also be stored flat.

Техникалык тейлөө

Proper maintenance ensures the longevity and performance of your work stand:

• Тазалоо: Wipe down the metal frame and table tops with a damp cloth after use to remove dust, debris, and spills. Avoid harsh chemicals that may damage the finish.
• Текшерүү: Periodically inspect all joints, fasteners, and the overall structure for any signs of wear, damage, or loose components. Tighten any loose screws or bolts.
• Сактагыч: When not in use, fold the Centipede stand and store it in a dry, protected area. Store the table tops flat to prevent warping.

Проблемаларды чечүү

Эгер көйгөйлөргө туш болсоңуз, төмөнкү жалпы көйгөйлөрдү жана чечимдерди караңыз:

• Стенд титиреп турат:
  • Ensure the stand is fully expanded and all leg joints are locked.
  • Verify it is placed on a level surface.
  • Check for any bent or damaged frame components.
• Table tops do not sit flat:
  • Ensure the Centipede stand is fully and correctly expanded.
  • Check if the table tops are warped. Store them flat when not in use.
• Бүктөө/ачуу кыйынчылыгы:
  • Ensure no debris is obstructing the joints.
  • Apply a small amount of silicone lubricant to the pivot points if necessary.

Техникалык шарттар

Кепилдик жана колдоо

BORA products are manufactured to high-quality standards. For information regarding warranty coverage, please refer to the warranty card included with your product or visit the official BORA website. For technical support, replacement parts, or any inquiries not covered in this manual, please contact BORA customer service through their official channels.

BORA Official Webсайт: www.boratool.com
