1. Киришүү жана коопсуздук маалыматы
Thank you for choosing DUMOS Dining Chairs. This manual provides essential information for the safe assembly, operation, and maintenance of your new chairs. Please read all instructions carefully before beginning assembly and retain this manual for future reference.
Маанилүү коопсуздук эскертүүлөрү:
- Always read and follow the user manual for safe assembly and use.
- Do not exceed the maximum weight capacity of 250 lbs (113 kg) to ensure stability and prevent accidents.
- Колдонуудан мурун бардык болттор жана бурамалар бекем бекемделгенин текшериңиз. Мезгил-мезгили менен текшерип, зарыл болсо, кайра бекемдөө.
- Кичинекей бөлүктөрүн жана таңгактоочу материалдарды муунуп калуу коркунучун болтурбоо үчүн балдардан алыс кармаңыз.
- Assemble the chairs on a soft, clean surface to prevent scratching.
2. Пакеттин мазмуну
Before assembly, please verify that all components listed below are present and undamaged. If any parts are missing or damaged, please contact DUMOS customer support.
- (A) Backrest: 1 unit
- (B) Seat Cushion: 1 unit
- (C) Chair Legs: 2 units
- Hardware Pack: Includes Bolts (E), Bolts (F), Washers (H), Washers (I), and Allen Wrench.
Image: All components of the DUMOS Dining Chair laid out for assembly, including the backrest, seat cushion, two legs, and a hardware pack.
3. Монтаждоо боюнча нускамалар
Follow these steps to assemble your DUMOS Dining Chairs. It is recommended to have a second person assist with assembly for easier handling.
Video: Full assembly guide for the DUMOS Dining Chair, demonstrating each step from unpacking to final tightening.
Кадам-кадам колдонмо:
1-кадам: Компоненттерди таңгактан чыгаруу
Carefully lift the non-woven fabric cover at the bottom of the Seat Cushion (B) and remove the chair legs and hardware pack stored inside. Lay out all parts on a soft, clean surface.
Image: A person lifting the fabric cover from the underside of the seat cushion to reveal the stored chair legs and hardware.
Step 2: Attach Backrest to Seat Cushion (Partial Tightening)
Insert one Washer (H) and one Washer (I) onto a Bolt (F). Align the Backrest (A) with the Seat Cushion (B) and insert the Bolt (F) into the middle connection point. Tighten this bolt only 50% to allow for adjustment in the next step.
Step 3: Secure Backrest to Seat Cushion (Full Tightening)
Insert Washers (H) and (I) onto four Bolts (E). Attach the Seat Cushion (B) to the Backrest (A) using these four Bolts (E) on both sides. Once all four Bolts (E) are in place, tighten them 100%. Then, fully tighten the middle Bolt (F) from Step 2.
Image: Detail of the backrest and seat cushion connection, showing the secure attachment points with bolts.
Step 4: Attach Chair Legs
Tip the partially assembled chair over. Insert Washers (H) and (I) onto four Bolts (F). Attach each Chair Leg (C) to the designated corners of the Seat Cushion (B) using two Bolts (F) per leg. Ensure all four bolts for the legs are tightened 100% for stability.
Step 5: Seal Seat Bottom Cover
Once all legs are securely attached, seal the non-woven fabric cover back into place at the bottom of the Seat Cushion (B). This covers the internal components and gives a finished look.
4. Иштөө нускамалары
Your DUMOS Dining Chairs are designed for comfortable seating in dining rooms, kitchens, living rooms, or other suitable areas. To use, simply place the chair on a flat, stable surface and sit. Ensure the chair is not placed on uneven ground to prevent tipping.
Image: A person sitting comfortably on a DUMOS Dining Chair, demonstrating proper use.
5. Кароо жана тейлөө
Proper care will extend the life and appearance of your DUMOS Dining Chairs.
- Тазалоо: жумшак менен тазалап, damp cloth. Avoid harsh chemicals or abrasive cleaners that may damage the fabric or wood finish.
- Төгүлүүлөр: Төгүлгөн жерлерди дароо таза, кургак чүпүрөк менен сүртүңүз. сүртпө.
- Текшерүү: Бардык болтторду жана туташтыргычтарды бекем кармап туруу үчүн мезгил-мезгили менен текшерип туруңуз. Туруктуулукту сактоо үчүн зарылчылыкка жараша кайра бекемдеңиз.
- Жайгашкан жери: Avoid prolonged exposure to direct sunlight or extreme temperatures, which can cause fading or damage to the materials.
- Пол коргоо: The chair legs are equipped with rubber pads to prevent floor scratching. Ensure these pads are intact and replace if worn.
6. Кыйынчылыктарды
If you encounter any issues with your DUMOS Dining Chairs, please refer to the following common solutions:
- Тербелүүчү кресло:
- Бардык чогултуучу болттордун толугу менен бекем тартылганын текшериңиз.
- Check if the chair is placed on an even surface.
- Verify that the rubber pads on the chair legs are evenly distributed and not missing.
- Бош бөлүктөрү:
- Re-tighten any loose bolts or screws using the provided Allen wrench.
- Чогултуу кыйынчылыгы:
- Review the assembly video and step-by-step instructions carefully.
- Ensure parts are correctly oriented before tightening bolts.
- Do not fully tighten all bolts until the chair is mostly assembled, allowing for minor adjustments.
If problems persist, please contact DUMOS customer support for assistance.
7. Продукттун спецификациялары
| Өзгөчөлүк | Деталь |
|---|---|
| Бренд | DUMOS |
| Модель номери (ASIN) | B0CHRYL3NG |
| Түс | Беж |
| Материал | Жыгач, кездеме |
| Жалпы бийиктиги | 39.1 дюйм (100 см) |
| Seat Length | 16.34 дюйм |
| Орундуктун кеңдиги | 24.2 дюйм |
| Орундуктун бийиктиги | 17.71 дюйм |
| Элемент Салмагы | 15 Kilograms (approx. 33 lbs) per chair |
| Сунушталган максималдуу жүк | 113.4 кг (250 фунт) |
| Ассамблея талап кылынат | Ооба |
| Камтылган компоненттер | Assembly Tools, Dining Chair components, Instruction Manual |
Image: A diagram illustrating the key dimensions of the DUMOS Dining Chair, including height, width, and depth.
8. Кепилдик жана Кардарларды колдоо
DUMOS provides a 12-month insurance (warranty) for your dining chairs, covering manufacturing defects from the date of purchase. Please retain your proof of purchase for warranty claims.
For any questions, missing parts, or warranty claims, please contact DUMOS customer support through the retailer where you purchased the product. Please have your model number (B0CHRYL3NG) and purchase details ready.
