ORICO MetaBox Mini NAS Storage User Manual

1. Киришүү

The ORICO MetaBox Mini NAS Storage (Model CD3520) is a personal media center designed for centralized storage and management of your digital content. It supports up to 22TB of storage, allowing you to consolidate videos, audio, and photos from various devices like smartphones, tablets, and computers. This device offers remote access via the Weline APP, supports Samba and DLNA protocols for seamless sharing, and provides a secure private cloud environment for your data.

Figure 1: The ORICO MetaBox Mini NAS Storage device.

2. Пакеттин мазмуну

Төмөнкү нерселердин баары пакетиңизге камтылганын текшериңиз:

• ORICO MetaBox Mini NAS Storage Unit (CD3520)
• Кубат адаптери (DC 12V 3A)
• USB-A - USB-C 3.2 кабели
• Ethernet Cable (Cat 6E)
• Резина буттар (2 даана)
• Screwdriver
• Mounting Screws (for 2.5-inch and 3.5-inch drives)
• User Manual

Figure 2: All components included in the ORICO MetaBox Mini NAS package.

3. Орнотуу

3.1. Аппараттык камсыздоону орнотуу

1. Драйверди даярдаңыз: The MetaBox Mini NAS supports both 2.5-inch and 3.5-inch SATA hard drives or SSDs. Ensure your drive is compatible.
2. Корпусун ачыңыз: Gently remove the front cover of the NAS unit. It is held by magnets.
3. Slide Out the Drive Tray: Locate the small tab at the bottom of the drive bay. Pull this tab to release and slide out the internal drive tray.
4. Дискти орнотуу: Secure your 2.5-inch or 3.5-inch drive into the tray using the provided screws and screwdriver. Ensure the SATA connectors align correctly.
5. Insert the Drive Tray: Slide the loaded drive tray back into the NAS enclosure until it clicks securely into place.
6. Replace the Front Cover: Reattach the magnetic front cover.
7. Резина буттарын бекитүү: Place the two rubber feet onto the designated slots on the bottom of the NAS unit to ensure stability.

3.2. Initial Connection and App Setup

1. Туташуу кубаты: Plug the power adapter into the DC 12V 3A port on the back of the NAS unit and then into a power outlet.
2. Тармакка туташуу: Connect one end of the Ethernet cable to the Gigabit Ethernet port on the NAS and the other end to your router or network switch.
3. Күйгүзүү: Press the power button on the back of the NAS unit. The status indicator lights on top should illuminate.
4. Download Weline App: Издөө "Weline" in your mobile device's app store (Google Play Store for Android or Apple App Store for iOS) and install the application.
5. Катталуу/Кирүү: Open the Weline App and follow the on-screen instructions to register a new account or log in if you already have one.
6. Түзмөк кошуу: Within the Weline App, select the option to add a new device. You may be prompted to scan a QR code located on the NAS unit or its packaging, or to search for the device on your local network.
7. Формат Drive: Once connected, the app may prompt you to format the newly installed drive. Confirm to proceed with formatting, which will prepare the drive for use with the NAS.

Figure 3: The ORICO MetaBox Mini NAS supports up to 22TB storage expansion and centralized management from various devices.

Figure 4: Step-by-step guide for Weline App setup, from hard drive installation to app connection.

4. Operating the MetaBox Mini NAS

4.1. Weline App Features

The Weline App serves as your primary interface for managing the MetaBox Mini NAS. It allows you to:

• Personal Media Center: Centralize and categorize videos, audio, and photos from all your devices.
• Алыстан кирүү: Access your stored media remotely via the Weline App, enabling 4K experience on the go.
• Бөлүшүү: Бөлүшүү files with friends and family by setting up personal, public, and group spaces.
• Автоматтык камдык көчүрмө: Configure automatic backups from your connected devices to the NAS.
• File Башкаруу: Browse, upload, download, and organize files and folders directly within the app.

Figure 5: Enjoy remote access to your media library through the Weline App, even while traveling.

Figure 6: The Weline App facilitates instant sharing of media with friends and family.

4.2. Samba and DLNA Protocols

The MetaBox Mini NAS supports Samba and DLNA protocols, allowing for broader compatibility and access from various devices on your network.

• Samba (SMB/CIFS): Тармакты иштетет file sharing with Windows, macOS, and Linux computers. You can map the NAS as a network drive for easy access.
• DLNA: Allows you to stream media content from the NAS to DLNA-compatible devices such as smart TVs, gaming consoles, and media players.

Figure 7: Steps 1-3 for mapping a network drive in Windows using the Samba function.

Figure 8: Steps 4-6 for mapping a network drive in Windows using the Samba function.

Figure 9: Steps 1-4 for mapping a network drive in macOS using the Samba function.

10-сүрөт: Альтернатива view of steps for mapping a network drive in macOS using the Samba function.

5. Техникалык тейлөө

5.1. Cooling and Heat Dissipation

The ORICO MetaBox Mini NAS is designed with a cooling fan and an aluminum alloy casing to ensure efficient heat dissipation, maintaining optimal operating temperatures for your hard drive and the device itself.

Figure 11: Internal cooling fan and aluminum alloy design for effective heat dissipation.

5.2. Индикатор жарыктары

The NAS unit features indicator lights on its top surface to provide status information:

• Көк жарык: Indicates online status and normal operation.
• Кызыл жарык: Indicates offline status or a potential issue.

Figure 12: Disk and Status indicator lights, along with the rear panel ports (USB 3.2 Gen1 Type-C, Reset, DC 12V 3A, 1 Gigabit Ethernet, Power Start).

6. Кыйынчылыктарды

If you encounter issues with your ORICO MetaBox Mini NAS, consider the following common troubleshooting steps:

• Орнотуудагы кыйынчылыктар: Ensure all cables (power, Ethernet) are securely connected. Verify that the hard drive is correctly installed and seated in the tray. If the drive is new, it must be formatted via the Weline App.
• Тармакка туташуу: Check your router's status and ensure the NAS is receiving an IP address. Confirm that your mobile device or computer is on the same local network as the NAS for initial setup and local access.
• Алыстан кирүү маселелери: Cross-region transmission speeds can vary (typically 1-2MB/s). If you experience slow speeds, ensure your internet connection is stable. The Weline App may offer accelerated traffic options for purchase if needed.
• Колдонмонун иштеши: If the Weline App is not recognizing the device or showing incorrect status, try restarting the app, restarting the NAS unit, or checking for app updates.
• Samba/DLNA Access: Ensure the Samba or DLNA service is enabled within the Weline App settings. Verify correct network path or device discovery settings on your computer or media player.
• Data Security Concerns: The device uses SDVN technology for encrypted direct transmission between your devices and the NAS, bypassing cloud servers for enhanced privacy.
• Аткаруу: The NAS is equipped with a quad-core CPU and DDR4 memory for fast decoding and file operations. If performance is slow, check your network speed and ensure the NAS is not under heavy load.

7. Техникалык шарттар

8. Кепилдик жана колдоо

Кепилдик жөнүндө маалымат жана техникалык колдоо алуу үчүн, расмий ORICO сайтына кайрылыңыз website or contact ORICO customer service directly. Details regarding warranty periods and support channels are typically provided with your product documentation or on the manufacturer's webсайт.

You can visit the ORICO Store on Amazon for more information: ORICO Store
