1. Продукт бүтүп калдыview
The Parkside Performance® PTMI 180 A1 is a powerful professional inverter welding machine designed for both MMA (Manual Metal Arc) and TIG (Tungsten Inert Gas) welding processes. Its compact design and light weight make it ideal for mobile use. This machine offers advanced features for optimal welding performance and user comfort.
Image 1: The Parkside Performance PTMI 180 A1 Inverter Welding Machine, showcasing анын компакттуу дизайны жана бренди.
Негизги өзгөчөлүктөрү:
- Dual Welding Processes: Supports both MMA (stick electrode) and TIG (tungsten inert gas) welding.
- Компакт жана жеңил: Designed for portability and ease of use in various environments.
- Hot Start функциясы: Ensures perfect arc ignition without the electrode sticking.
- Anti-Stick Function: Facilitates easy release of a stuck electrode by automatically reducing the welding current.
- Lift Arc Function: Provides comfortable arc ignition during TIG welding by lifting the electrode from the workpiece.
- Stable Welding Arc: Electronically controlled, quiet, and uniform arc with high tolerance for position changes.
- Санариптик дисплей: Innovative front screen with simple rotary knob control and digital display for precise parameter adjustment.
- Ашыкча жүктөн коргоо: Equipped with thermal control to prevent damage from overheating.
2. Коопсуздук нускамалары
Ширетүүчү жабдууларды иштетүүдө коопсуздукту ар дайым биринчи орунга коюңуз. Бул көрсөтмөлөрдү аткарбоо олуттуу жаракат же өлүмгө алып келиши мүмкүн.
- Жеке коргонуу каражаттары (ЖКК): Always wear a welding helmet with appropriate shade, flame-resistant clothing, welding gloves, and safety shoes.
- Вентиляция: Ensure adequate ventilation to remove welding fumes, which can be hazardous to health.
- Өрт коркунучу: Тез күйүүчү материалдарды ширетүү аймагынан алыс кармаңыз. Өрт өчүргүчтү оңой эле жаныңызда кармаңыз.
- Электр коопсуздугу: Do not operate the machine in wet conditions. Ensure all cables are in good condition and properly connected. Never touch live electrical parts.
- Арк нурлары: Protect eyes and skin from arc rays, which can cause burns and eye damage.
- Иш чөйрөсү: Жумуш аймагын таза жана башаламандыктан сактаңыз. Туруктуу бутту камсыз кылуу.
- Балдар жана байкоочулар: Keep children and unauthorized persons away from the welding area.
3. Пакеттин мазмуну
Please check the package contents upon unpacking to ensure all components are present and undamaged:
- 1 x Parkside Performance® PTMI 180 A1 Inverter Welding Machine
- 1 x TIG Torch
- 2 x MMA Stick Electrodes (2 x 2.5 mm)
- 1 x Tungsten Electrode (1.6 mm)
- 1 x 2m Welding Cable with Electrode Holder
- 1 x 2m Earth Cable with Galvanized Clamp
- 1 x Ташуу боосу
4. Орнотуу
Follow these steps to set up your welding machine:
- Жайгашкан жери: Place the welding machine on a stable, level, and non-flammable surface. Ensure adequate air circulation around the machine for cooling.
- Connect Earth Cable: Connect the earth cable's clamp to a clean, bare metal section of your workpiece or welding table. Ensure a good electrical connection.
- Connect Electrode Holder (MMA): For MMA welding, connect the welding cable with the electrode holder to the appropriate terminal on the machine (usually positive for most electrodes). Insert the desired MMA electrode into the holder.
- Connect TIG Torch (TIG): For TIG welding, connect the TIG torch to the designated TIG terminal. Connect the gas hose from the TIG torch to your protective gas cylinder (e.g., Argon) via a pressure regulator. Ensure the gas connection (¼" internal thread) is secure.
- Кубат туташуу: Connect the machine's power cable to a suitable 230V AC power outlet.
- Күйгүзүү: Turn on the machine using the On/Off switch. The power indicator light will illuminate.
5. Иштөө нускамалары
This section details the operation of your PTMI 180 A1 welding machine for both MMA and TIG processes.
5.1. Selecting Welding Process
Use the controls on the innovative front screen to select between MMA and TIG welding modes. The digital display will show the selected mode.
5.2. Adjusting Welding Current
Use the rotary knob control on the front panel to adjust the welding current. The digital display will show the precise current setting (10-180 A). Adjust the current according to the material thickness and electrode/tungsten size.
5.3. MMA Welding (Stick Electrode)
- Ensure the correct electrode is inserted into the holder and the earth clamp коопсуз тиркелет.
- Select MMA mode.
- Ширетүүчү токту тууралаңыз.
- колдонуу Hot Start function for easy arc ignition.
- If the electrode sticks, the Anti-Stick function will automatically reduce the current, allowing for easy release.
- Maintain a consistent arc length and travel speed for optimal results.
5.4. TIG Welding (Tungsten Inert Gas)
- Ensure the tungsten electrode is properly installed in the TIG torch and the protective gas is connected and flowing.
- Select TIG mode.
- Ширетүүчү токту тууралаңыз.
- колдонуу Lift Arc function for comfortable arc ignition by gently touching the tungsten to the workpiece and then lifting it slightly to initiate the arc.
- Maintain a consistent torch angle and distance from the workpiece.
6. Техникалык тейлөө
Үзгүлтүксүз техникалык тейлөө ширетүүчү машинаңыздын узак мөөнөттүү иштешин жана оптималдуу иштешин камсыз кылат.
- Тазалоо: Regularly clean the exterior of the machine with a dry, soft cloth. Do not use solvents or abrasive cleaners.
- Вентиляция тешиктери: Keep the ventilation openings clear of dust and debris to ensure proper cooling. Use compressed air to gently blow out dust if necessary.
- Кабелдик текшерүү: Periodically inspect all cables (welding, earth, power) for signs of damage, cuts, or fraying. Replace damaged cables immediately.
- Байланыштары: Бардык электр байланыштары бекем жана коопсуз экендигин текшериңиз.
- Electrode Holder/TIG Torch: Clean the electrode holder and TIG torch regularly to remove spatter and ensure good electrical contact.
- Сактагыч: Машинаны колдонбогондо кургак, чаңсыз жерде сактаңыз.
7. Кыйынчылыктарды
Бул бөлүмдө сиз кабылышы мүмкүн болгон жалпы маселелерди чечүү жолдору каралган.
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Машина иштебейт. | No power supply; Faulty power cable; Machine switch off. | Check power outlet and circuit breaker; Inspect power cable for damage; Ensure On/Off switch is in 'On' position. |
| No welding arc. | Poor earth connection; Incorrect current setting; Electrode/tungsten issue; Overload protection activated. | Жерди камсыз кылуу clamp has good contact; Adjust current; Check electrode/tungsten for damage or proper insertion; Allow machine to cool down if overload indicator is on. |
| Arc is unstable or difficult to maintain. | Incorrect current; Improper arc length; Contaminated workpiece; Incorrect gas flow (TIG). | Adjust current; Maintain proper arc length; Clean workpiece surface; Check gas cylinder and flow rate (TIG). |
| Machine overheats and shuts down. | Жумуш цикли ашып кетти; желдетүүнүн тыгылып калышы; айлана-чөйрөнүн жогорку температурасы. | Машинаны муздатыңыз; желдетүү тешиктерин тазалаңыз; салкын чөйрөдө иштетиңиз. |
8. Техникалык шарттар
| Модель номери | PARKSIDE PERFORMANCE® PTMI 180 A1 |
| Ширетүү процесстери | TIG / MMA |
| Ширетүү ток | 10-180 А. |
| Киргизүү көлөмүtage | 230 вольт (AC) |
| Электр кабелинин узундугу | 2 м |
| Материал | Steel sheet, Plastic |
| Өлчөмдөрү (L x W x Y) | Болжол менен 27.5 см x 10.5 см x 22 см |
| Салмагы | Болжол менен 5 кг |
| Түс | Кара |
| Камтылган компоненттер | 1 tungsten electrode (1.6 mm), 2 MMA stick electrodes (2 x 2.5 mm), TIG torch |
9. Кепилдик жана колдоо
For warranty claims, technical support, or spare parts inquiries, please contact your retailer or the manufacturer directly. Information regarding spare parts availability is currently unavailable.
Сураныч, кепилдик максаттары үчүн сатып алганыңыздын далилин сактап коюңуз.
