Monodeal DV68 Bone Conduction Headphones User Manual

Introduction

Thank you for choosing Monodeal DV68 Bone Conduction Headphones. These open-ear headphones are designed to provide high-quality audio while keeping you aware of your surroundings, making them ideal for sports and daily activities. Featuring Bluetooth 5.3 connectivity and IP67 waterproofing, they offer a comfortable and durable listening experience.

Продукт бүттүview

1-сүрөт: Monodeal DV68 Bone Conduction Headphones. This image shows the overall design of the headphones, highlighting their sleek, lightweight structure and the bone conduction transducers.

2-сүрөт: Key Features of Monodeal DV68 Headphones. This image illustrates the main features including Open-Ear design, IP67 Waterproof rating, 500mAh Battery, Bluetooth V5.3, Lightweight build, HD Microphone, Multipoint Pairing, and RGB Light.

Негизги өзгөчөлүктөрү:

• Сөөк өткөргүч технологиясы: Delivers high-quality sound through your cheekbones, ensuring clear audio while keeping your ears open to ambient sounds.
• Bluetooth 5.3: Provides a faster and more stable wireless connection.
• Батареянын узак иштөө мөөнөтү: Equipped with a 500mAh battery, offering up to 15 hours of continuous music playback or call time.
• Ачык кулак дизайны: Ensures comfort and awareness of surroundings, promoting safety during outdoor activities.
• Жеңил жана ийкемдүү: Weighing only 34 grams with a memory titanium frame for durability and a secure fit.
• IP67 Суу өткөрбөйт: Resistant to sweat, rain, and splashes, suitable for various sports and weather conditions.
• Камтылган микрофон: Колсуз так чалуулар үчүн.
• Smart LED жарык: Enhances safety during night sports.

Пакеттин мазмуну

Сураныч, пакетте төмөнкү нерселерди текшериңиз:

• Monodeal DV68 Bone Conduction Headphones
• Заряддоо кабели
• Колдонуучунун Колдонмосу (бул документ)

Жайгашуу

1. Наушниктерди заряддоо

Before first use, fully charge your headphones. The DV68 features fast charging capabilities.

• Берилген заряддоо кабелин гарнитурадагы заряддоо портуна туташтырыңыз.
• Кабелдин экинчи учун USB кубат адаптерине (кошумча эмес) же компьютердин USB портуна туташтырыңыз.
• The LED indicator on the headphones will show the charging status. It typically takes approximately 2 hours for a full charge.
• 10 мүнөттүк кубаттоо 2 саатка чейин ойноо убактысын камсыздай алат.

3-сүрөт: Battery Life and Charging. This image illustrates the 20-hour playtime and the fast charging capability, where 10 minutes of charging provides 2 hours of playtime.

2. Bluetooth түзмөгү менен жупташуу

The Monodeal DV68 headphones use Bluetooth 5.3 for wireless connection.

1. Наушниктердин өчүрүлгөнүн текшериңиз.
2. Жупташтыруу режимин көрсөткөн LED индикатору кызыл жана көк түстө күйүп-өчкөнгө чейин кубат баскычын басып туруңуз.
3. Түзмөгүңүздө (смартфон, планшет, компьютер) Bluetooth иштетип, жеткиликтүү түзмөктөрдү издеңиз.
4. Select "Monodeal DV68" from the list of found devices.
5. Once connected, the LED indicator will turn solid blue or stop flashing.
6. The headphones support multipoint pairing, allowing connection to two devices simultaneously. Refer to your device's Bluetooth settings for managing multiple connections.

Иштөө нускамалары

Күйгүзүү/өчүрүү

• Күйгүзүү: Кубат баскычын 3 секунд басып туруңуз.
• Өчүрүү: Кубат баскычын 5 секунд басып туруңуз.

Музыканы ойнотуу

• Ойнотуу/тындыруу: Көп функциялуу баскычты бир жолу басыңыз.
• Кийинки трек: Көп функциялуу баскычты эки жолу басыңыз.
• Мурунку трек: Көп функциялуу баскычты үч жолу басыңыз.
• Көлөмү: Көлөм + баскычын басыңыз.
• Үнүн азайтуу: Үн көлөмү - баскычын басыңыз.

Чалууларды башкаруу

• Чалууга жооп берүү/аяктоо: Көп функциялуу баскычты бир жолу басыңыз.
• Чакырууну четке кагуу: Көп функциялуу баскычты 2 секунд басып туруңуз.
• Үн жардамчысы: Press the multi-function button twice (when not on a call).

Smart LED жарык

The integrated Smart LED Light enhances visibility during night activities.

• Activate/Deactivate LED: Refer to the specific button combination in the quick start guide (usually a dedicated button or a long press of a volume button).
• The LED light can display different colors (blue, green, red) for various indications or safety.

4-сүрөт: Smart LED Light. This image shows a runner at night, highlighting the smart LED light feature for enhanced safety and visibility.

Техникалык тейлөө

Proper maintenance ensures the longevity and optimal performance of your Monodeal DV68 headphones.

• Тазалоо: After sweating during exercise, wipe the headphones with a damp cloth to remove sweat and dirt. Do not use harsh chemicals or abrasive cleaners.
• Сактагыч: Store the headphones in a cool, dry place when not in use. Avoid extreme temperatures.
• Суу каршылык: While IP67 rated for sweat, rain, and splashes, avoid submerging the headphones in water for extended periods. Ensure the charging port is dry before charging.
• Заряддоо: Use only the provided charging cable. Do not overcharge the battery.

5-сүрөт: IP67 Waterproof Feature. This image shows a person exercising, emphasizing the headphones' resistance to sweat and rain, making them suitable for active use.

Проблемаларды чечүү

Техникалык шарттар

Кепилдик жана колдоо

Monodeal offers a 2 жылдык кепилдик for the DV68 Bone Conduction Headphones, ensuring peace of mind with your purchase.

For any product inquiries, technical support, or warranty claims, please contact the Monodeal service team. Contact information can typically be found on the product packaging or the official Monodeal webсайт.

Кеңеш: After sweating during exercise, wipe the headphones with a damp cloth and put them back in the box. This keeps your headphones clean and like new, helping to maintain their condition for the warranty period and beyond.
