TechniSat TECHNIRADIO SOLAR 2 Колдонуучунун колдонмосу

Introduction

The TechniSat TECHNIRADIO SOLAR 2 is a versatile and environmentally conscious portable radio designed for reliable performance in various conditions. Featuring DAB+ and FM radio reception, multiple charging options including solar and crank power, an integrated LED flashlight, and a power bank function, this device is an ideal companion for outdoor adventures, emergencies, or everyday use. Its robust, splash-proof design (IPX4) and construction from 87% marine plastic underscore its commitment to durability and sustainability.

Коопсуздук нускамалары

• Do not expose the device to extreme temperatures, direct sunlight for prolonged periods (beyond charging), or high humidity.
• Аппаратты түшүрүүдөн же катуу таасирлерден сактаныңыз.
• Аппаратты өзүңүз ажыратпаңыз же оңдоого аракет кылбаңыз. Бардык тейлөөлөрдү квалификациялуу кызматкерлерге тапшырыңыз.
• Keep the device away from water sources, despite its splash-proof rating (IPX4). It is not designed for submersion.
• Ensure the USB ports are dry before connecting any cables.
• When using the power bank function, ensure the connected device is compatible and that the charging cable is in good condition.
• Dispose of the battery and device responsibly according to local regulations.

Продукт бүттүview

Familiarize yourself with the components and controls of your TECHNIRADIO SOLAR 2.

1-сүрөт: Фронт view of the TechniSat TECHNIRADIO SOLAR 2, showing the speaker grille, digital display, and control buttons for volume, info/menu, mode, and OK/scan. The flashlight is visible on the left side.

2-сүрөт: Жогорку view of the radio highlighting the integrated solar panel. The rear view shows the foldable hand crank for manual power generation.

3-сүрөт: Side view of the radio with the protective cover open, revealing the DC OUT (USB-A) port for power bank function, DC IN (USB-C) port for charging the radio, and a 3.5mm headphone jack.

Башкаруу каражаттары жана порттор:

• Дисплей: Shows station information, time, battery status, and menu options.
• Кубат баскычы: Радиону күйгүзөт/өчөт.
• VOL +/- баскычтары: Үн көлөмүн тууралайт.
• МААЛЫМАТ/МЕНЮ баскычы: Accesses information display and menu settings.
• MODE баскычы: DAB+ жана FM радио режимдерин которушат.
• OK/SCAN Button: Confirms selections or initiates station scans.
• Алдын ала коюлган баскычтар (1-5+): Сакталган сүйүктүү станцияларга тез жетүү.
• Кол чырак баскычы: LED кол чырагын иштетет.
• Күн панели: Located on top for solar charging.
• Кол бурчу: Foldable crank on the rear for manual power generation.
• USB-C Input (DC IN 5V 2.3A): For charging the radio's internal battery.
• USB-A Output (DC OUT 5V 1A): Тышкы түзмөктөрдү кубаттоо үчүн (кубат банк функциясы).
• 3.5 мм гарнитура уячасы: Жеке угуу үчүн.
• Телескопиялык антенна: Оптималдуу радио кабыл алуу үчүн кеңейтүү.

Жайгашуу

Баштапкы заряддоо

Before first use, it is recommended to fully charge the internal battery. The radio offers multiple charging methods:

• USB-C заряддоо: Connect the included USB-C cable to the DC IN port on the side of the radio and to a standard USB power adapter (not included) or a computer USB port. A full charge takes approximately 4 hours.
• Күн кубаты: Place the radio with the solar panel facing direct sunlight. The solar panel will slowly charge the internal battery. This method is ideal for maintaining charge or for emergency charging in daylight.
• Кол менен заряддоо: Unfold the hand crank on the rear of the radio. Rotate the crank clockwise or counter-clockwise at a steady pace. Approximately 1 minute of cranking can provide enough power for a few minutes of radio playback or flashlight use. This method is for emergency power generation.

4-сүрөт: The solar panel on top and the hand crank on the rear are primary methods for sustainable charging.

The battery indicator on the display will show the charging status. A fully charged battery provides up to 25 hours of playback time.

Иштөө нускамалары

Turning On/Off and Volume

• басыңыз Кубат баскычы to turn the radio on or off.
• колдонуу VOL+ жана VOL - угуу үнүн тууралоо үчүн баскычтар.

Радио операциясы (DAB+/FM)

Оптималдуу кабыл алуу үчүн телескоптук антеннаны узартыңыз.

5-сүрөт: The TECHNIRADIO SOLAR 2 supports both DAB+ and FM radio for a wide range of listening options.

• басыңыз РЕЖИМ DAB+ жана FM радио режимдери ортосунда которулуу үчүн баскыч.
• Автоматтык станцияны сканерлөө: In either mode, press and hold the OK/СКАНДОО button to initiate an automatic scan for available stations. The radio will store found stations.
• Manual Tuning (FM): In FM mode, short press the OK/СКАНДОО button to manually tune frequencies.
• Станцияларды тандоо: колдонуу VOL+ жана VOL - buttons (or dedicated tuning buttons if available) to navigate through the scanned stations.
• Saving Favorite Stations:
  1. Каалаган станцияга коюңуз.
  2. Press and hold one of the numbered preset buttons (1-5+). The display will confirm the station has been saved.
  3. To recall a favorite station, simply short press the corresponding numbered preset button. The radio supports 10 favorite stations for DAB+ and 10 for FM.
• INFO/MENU: басыңыз INFO / MENU button to cycle through different information displays (e.g., program type, signal strength, time) or to access the radio's settings menu.

Кол чырак функциясы

The integrated LED flashlight provides illumination in two brightness levels.

6-сүрөт: The powerful LED flashlight offers two brightness settings for various lighting needs.

• арналган баскычын басыңыз Кол чырак баскычы (located near the flashlight lens) once for the first brightness level.
• Press it again for the second, brighter level.
• Кол чыракты өчүрүү үчүн үчүнчү жолу басыңыз.

Power Bank функциясы

The TECHNIRADIO SOLAR 2 can charge external devices like smartphones via its USB-A output port.

7-сүрөт: Use the power bank function to charge your mobile devices on the go, ensuring you stay connected.

• Open the protective cover on the side of the radio to access the USB-A output port (DC OUT 5V 1A).
• Түзмөгүңүздүн кубаттоочу кабелин ушул портко туташтырыңыз.
• Charging will begin automatically if the radio has sufficient battery power.
• Close the protective cover when not in use to maintain IPX4 splash protection.

Техникалык тейлөө

• Тазалоо: Wipe the device with a soft, dry cloth. For stubborn dirt, use a slightly damp cloth and mild detergent, then dry thoroughly. Do not use abrasive cleaners or solvents.
• Сактагыч: When not in use for extended periods, store the radio in a cool, dry place. It is advisable to charge the battery fully every few months to maintain its lifespan.
• Экологиялык жоопкерчилик: The radio's housing is made from 87% marine plastic, and its packaging is 100% plastic-free, reflecting an eco-friendly design.

8-сүрөт: The TECHNIRADIO SOLAR 2 is designed with environmental sustainability in mind, utilizing recycled marine plastic for its casing.

Проблемаларды чечүү

Техникалык шарттар

9-сүрөт: Dimensions of the TechniSat TECHNIRADIO SOLAR 2.

Кепилдик жана колдоо

Кепилдик жөнүндө маалымат жана техникалык колдоо алуу үчүн, расмий TechniSat компаниясына кайрылыңыз. webсайтына кириңиз же жергиликтүү сатуучуңузга кайрылыңыз. Кепилдик талаптары үчүн сатып алганыңызды тастыктаган документти сактап коюңуз.
